  • Page 1 AT-LP70X Automatic Belt-Drive Turntable User Manual English...
  • Page 2 Introduction This product can be used only in the countries where the product is sold. Make sure that the operating voltage and the plug of AC adapter of the product are correct for the country you live in.

  • Page 3: Safety Precautions

    Safety precautions Although this product was designed to be used safely, failing to use it correctly may result in an accident. To ensure safety, observe all warnings and cautions while using the product. Important information Warning To prevent fire or shock hazard, do not expose this apparatus to rain or moisture. Caution Do not expose this apparatus to drips or splashes.

  • Page 4: For Customers In Canada

    Safety precautions Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 5: Notes On Use

    Notes on use Turntable body Do not set and use the product in locations that are considerably hot or humid, dirty, or subject to extreme vibrations. The product should be positioned on a flat, level surface. When opening or closing the dust cover, do so slowly. When closing the dust cover, close it completely. Replacement stylus The stylus is extremely delicate.

  • Page 6: Package Contents

    Package contents Make sure that you have all the included items before using this product. If some items are missing or damaged, contact your local Audio-Technica dealer. After purchase, we suggest that you save all packaging materials for possible future storage, moving, or shipping. Turntable body Platter Drive belt...

  • Page 7: Part Names And Functions

    Part names and functions Top view Felt mat Platter Spindle Drive belt Motor pulley (brass-colored) Tonearm Platter speed button Select the platter speed (33-1/3 or 45 RPM). STOP button Returns the tonearm to its original position and stops the platter. START button Spins the platter and moves the tonearm.

  • Page 8: Rear View

    Part names and functions Rear view Dust cover hinge holders Attachment points for dust cover hinges. Feet Pre-amplifier selector switch If connecting to an amplifier's PHONO input jack, set this switch to the PHONO position. If connecting to the LINE/AUX jack of an amplifier, set this switch to the LINE position. Stereo output terminals Connect the RCA audio cable.
  • Page 9 Part names and functions Tonearm Size selector Switch between 12" and 7", according to the size of the record. Tonearm lift control lever Operates the tonearm lift. Tonearm lift Moves the tonearm vertically to and from the face of the record. Tonearm rest with clamp Use the clamp to secure the tonearm so that it does not move.
  • Page 10 Part names and functions Stylus The stylus is extremely delicate. Handle with care. Replacement stylus...

  • Page 11: Preparation For Use

    Preparation for use Setting up the turntable Position the product on a level surface. To avoid the effects of vibrations and acoustic pressure, do not mount the product next to such items as speakers. The product may pick up radio static if placed next to a radio. Therefore, try to keep the product away from radios. If the product is near equipment (cell phone, etc.) that emits strong radio waves, noise may occur.
  • Page 12 Preparation for use Align one of the platter openings with the motor pulley (brass-colored), and, while pulling both ends of the red ribbon that comes attached to the drive belt, place the drive belt on the motor pulley (brass-colored), as per the diagram.

  • Page 13: Rotating The Platter

    Preparation for use Rotating the platter Remove the vinyl tie securing the tonearm. Release the tonearm rest clamp and lift the tonearm with the lift control lever. Slowly rotate the turntable ten times by hand in the direction of the arrow. You may want to hold the tonearm to prevent it from moving.

  • Page 14: Using The Product

    Using the product Align the settings for the pre-amplifier selector switch and connect the RCA audio cable to an input jack on the connectable equipment you are using (amplifier, receiver, active speakers, sound card, etc.). Setting pre-amplifier selector switch This product has a built-in phono equalizer function. Even if you do not have a phono amplifier or connectable equipment with a built-in phono amplifier, the product can be used by connecting active speakers, etc.
  • Page 15 Using the product Active speakers Connecting to connectable equipment (amplifiers, etc.) The RCA audio cable's red jack is for the right (R) channel, and the white jack is for the left (L) channel.
  • Page 16 Using the product With PHONO input PHONO Connectable equipment (amplifier, etc.) Without PHONO input LINE / AUX Connectable equipment (amplifier, etc.)

  • Page 17: Before Playing A Record

    Using the product Depending on the equipment you are connecting, a ground (earth) terminal may exist near the PHONO input jack. If this is the case, connect to it using the ground line from the RCA audio cable. This will help prevent a low humming noise that might otherwise be heard during playback.
  • Page 18 Using the product At 33-1/3 RPM At 45 RPM To play a 45 RPM record, attach the 45 RPM adapter. Select the record size with the size selector. Select “12"” for an LP record with a 12" diameter, and “7"” for a 45 RPM record with a 7" diameter. Make sure the platter is stopped before switching the size selector for a different record size.

  • Page 19: Automatic Operation

    Using the product Select “33” to play 33-1/3 RPM records or “45” to play 45 RPM records. Automatic operation Lower the volume of the amplifier, active speakers, etc. sufficiently. Press the START button. Do not subject the product to strong impact during playback. Do not switch the record size selection while the record is playing.
  • Page 20 Using the product Tonearm lift control lever Position the tonearm over the desired location (groove) on the record. Slowly lower the tonearm by moving the tonearm lift control lever to the DOWN position. Alternatively, you can skip steps 1 and 2, and use your fingers to lift the tonearm and move it over the desired location on the record, and then slowly place the tonearm down to begin playing the record.

  • Page 21: Pausing The Record

    Using the product Do not switch the record size selection while the record is playing. Doing so can cause the product to malfunction. The tonearm descends slowly onto the record and play begins. Pausing the record Lower the volume of the amplifier, active speakers, etc. sufficiently. Raise the tonearm lift control lever to lift the tonearm.
  • Page 22 Using the product When the tonearm reaches the end (center) of the record, it will automatically lift and return to the tonearm rest. Do not interfere with its motion. Doing so can cause the product to malfunction. If the tonearm does not lift and return to the tonearm rest, press the STOP button to complete this operation.
  • Page 23 Care Turntable body When the turntable body is dirty or dusty, disconnect the AC adapter, and then wipe off the dirt and dust with a soft, dry cloth. Do not use benzenes, thinners, etc. If the felt mat gets dirty, it can easily scratch the record, so remove the felt mat periodically and wipe off any dust. When storing the product for a long time, disconnect the AC adapter from the outlet and wrap the equipment in plastic;...

  • Page 24: Replacing The Stylus

    Replacing the stylus Removing the stylus In addition to the deterioration of sound quality, records may also be damaged as the stylus tip wears down. As a rule of thumb, replace the stylus after 300 hours of use. Be sure to disconnect the product’s AC adapter from the outlet. When replacing the stylus, hold the tonearm and replacement stylus firmly.

  • Page 25: Replacing The Drive Belt

    Replacing the drive belt The drive belt is a consumable part. Replace the drive belt if the speed of playback slows down or irregular rotation occurs. As a rule of thumb, we suggest replacing the belt once a year. Before replacing the drive belt, first disconnect the product’s AC adapter from the outlet. Remove the felt mat.
  • Page 26 Replacing the drive belt Drive belt Attach the platter. Align one of the openings with the position of the motor pulley (brass-colored). Opening Motor pulley (brass-colored) Place the drive belt on the motor pulley (brass-colored). Grasp the drive belt that was attached in step 3 and, while pulling it, place it on the motor pulley (brass- colored).
  • Page 27 Replacing the drive belt Motor pulley (brass-colored) Drive belt Set the felt mat on the platter. Release the tonearm rest clamp and lift the tonearm with the lift control lever. Slowly rotate the turntable ten times by hand in the direction of the arrow. You may want to hold the tonearm to prevent it from moving.
  • Page 28 Replacing the drive belt...

  • Page 29: When The Turntable Is Moved

    When the turntable is moved Using the product’s original packaging materials, pack the turntable in the reverse order of unpacking it. If you do not have the original packaging materials, take the following measures: After unplugging the AC adapter from the outlet, remove the felt mat and platter, and then wrap them so they do not get damaged.

  • Page 30: Troubleshooting

    Troubleshooting The platter does not spin. Is the AC adapter connected to the outlet? Connect AC adapter to the outlet. Has the drive belt slipped from the platter? Correctly place the drive belt on the platter. Is the drive belt placed on the motor pulley (brass-colored)? Check that the drive belt is placed on the motor pulley (brass-colored) correctly.
  • Page 31 Troubleshooting There is noise when the record is playing. Is there dust on the stylus tip? If dust is stuck to the stylus tip, clean it with a commercially sold brush. The sound when the record is playing is either too fast or too slow. Are the speed settings for the product correct? Use the platter speed button to select the correct speed for the type of record being played.
  • Page 32 Dimensions (Unit: mm)
  • Page 33 Dimensions (Unit: mm)

  • Page 34: Cartridge Specifications

    Specifications Turntable specifications Motor DC motor Drive method Belt drive Speeds 33-1/3 RPM, 45 RPM Turntable platter Die-cast aluminum < 0.25% (WTD) Wow and flutter Signal-to-noise ratio > 55 dB PHONO: 4.0 mV nominal at 1 kHz, 5 cm/sec Output levels LINE: 252 mV nominal at 1 kHz, 5 cm/sec 36 dB nominal, RIAA equalized Phono Pre-amp gain...

  • Page 35: General Specifications

    Dust cover, Felt mat, Platter (with drive belt), Dust cover hinges, 45 RPM Accessories adapter, RCA audio cable (Approx. 1.0 m (3.3')), AC adapter (Approx. 1.5 m (4.9')) Replacement stylus (sold AT-VMN95C separately) Replacement belt (sold AT-LP70X exclusive belt separately) For product improvement, the product is subject to modification without notice.
  • Page 36 株式会社オーディオテクニカ 〒194-8666 東京都町田市西成瀬2-46-1 www.audio-technica.co.jp Audio-Technica Corporation 2-46-1 Nishi-naruse, Machida, Tokyo 194-8666, Japan www.audio-technica.com ©2024 Audio-Technica Corporation Global Support Contact: www.at-globalsupport.com 351709420-02-01 ver.1 2024.07.15...
