- Page 1 AT-LP60X User Manual Automatic Belt-Drive Turntable...
-
Page 2: Package Contents
Introduction Thank you for purchasing this Audio-Technica product. Read through this user manual before using the product to ensure its correct use. Also, keep this manual for future reference. This product can be used only in the countries where the product is sold. Make sure that the operating voltage and the plug of AC adapter of the product are correct for the country you live in. -
Page 3: Safety Precautions
Safety precautions Safety precautions Although this product was designed to be used safely, failing For customers in Canada to use it correctly may result in an accident. To ensure safety, observe all warnings and cautions while using the product. IC statement: CAN ICES-3 (B)/NMB-3(B) Important information Warning:... -
Page 4: Part Names And Functions
Part names and functions 45 RPM adapter (shown in receptacle) Platter speed button Adapts 7" records with large center holes to fit center Select the platter speed (33-1/3 or 45 RPM). spindle. START button Platter Spins the platter and moves the tonearm. Spindle STOP button Returns the tonearm to its original position and stops the... -
Page 5: Preparation For Use
Preparation for use 2. Place the belt on the motor pulley (brass-colored). Installing the turntable Align one of the platter openings with the brass motor • pulley, and, while pulling both ends of the red ribbon that Mount the product on a level surface. •... -
Page 6: Rotating The Platter
Preparation for use Rotating the platter Connecting the device 1. Using your hands, rotate the platter ten times. Align the settings for the pre-amplifier selector switch and connect the RCA audio cable to an input jack that is compatible Remove the tie that locks the tonearm and press the •... -
Page 7: Playing A Record
Playing a record Before playing a record Manual operation 1. Remove the cartridge’s protector. Lower the volume of the amplifier, speakers, etc. sufficiently. Pull the protector straight forward to remove it. • 1. Press the tonearm lift button. Applying a downward force may cause the stylus to come •... -
Page 8: Pausing The Record
Playing a record Care Pausing the record Turntable body 1. After lowering the volume of the amplifier, speakers, When the turntable body is dirty or dusty, first disconnect the • etc. sufficiently, press the tonearm lift button to lift the AC adapter, and then wipe off the dirt and dust with a soft, tonearm. -
Page 9: Replacing The Stylus
Replacing the stylus Replacing the belt The belt is a consumable part. Replace the belt if the speed of • Removing the stylus playback slows down or irregular rotation occurs. As a rule of thumb, we suggest replacing the belt once a year. In addition to the deterioration of sound quality, records may •... -
Page 10: When The Turntable Is Moved
Replacing the belt When the turntable is moved 5. Place the belt on the motor pulley (brass-colored). Using the product's original packing materials, wrap the turntable in the reverse order from when you unwrapped it. If Grasp the belt that was attached in step 3 and, while •... -
Page 11: Troubleshooting
Troubleshooting Problem Solution The platter does not spin. Is the AC adapter connected to the outlet? Connect the AC adapter to the outlet. • Has the belt slipped from the platter? Correctly place the belt on the platter. • Is the belt placed on the motor pulley? Check that the belt is placed on the motor pulley •... -
Page 12: Specifications
Specifications Type Belt-drive, fully automatic operation Motor DC servo-controlled Speeds 33-1/3 RPM, 45 RPM Turntable platter Aluminum Wow and flutter < 0.25% (WTD) at 3 kHz Signal-to-noise ratio > 50 dB (DIN-B) Cartridge Type Outputs levels “PHONO” 2.5 mV nominal at 1 kHz, 5 cm/sec “LINE”...
