Opening the Front Door Panel (V-Elite Panel) Opening the Front Door Panel (V-Elite Panel)
Some Cal Spa models have an add on option of unique V Elite panels. Each side panel is made of removable
segments, and require different steps to open. When removing the front panel, or any of your side panels,
its necessary to remove the corners of the spa as well. Failure to do so may result in damage to the panel or
wooden frame.
When removing the front panel of your spa (Underneath the main control panel), begin by removing the right
corner, and the right segment of the panel. The black T-bracket is in the middle of the two segments, it is fused
with the right panel being removed. Use a drill to remove the screws supporting the right panel first. If needed
you may remove the left segment of the front panel for better access.
Note: When a spa is designed with the V-Elite panels, each side panel is made of two segments and a black
T-bracket. The front panel is the only panel where the black T-bracket is a part of the right segment.
When reinstalling the front panels, the left segment without the center black T-bracket is installed first.
