- Page 1 The Escape Series ESCAPE & PLATINUM Escape Series Made in USA Cal Spas Home Resorts Owner’s Manual ™...
- Page 2 Contact Information For customer service or service technicians, please contact your authorized dealer immediately. If you need additional information and/or assistance, contact Copyright 2023 Lloyd’s Material Supply Company, Inc. Copyright 2024 Lloyd’s Material Supply Company, Inc. All rights reserved. All rights reserved. Duplication without written consent is Lloyd’s Material Supply Company, Inc.
-
Page 3: Table Of Contents
Table of Contents Important Safety Instructions....Generic Names for Chemicals ....... Preparing for Your Portable Spa ....Troubleshooting Water Clarity ..... Planning the Best Location ......Bather Load & Ozonator ......... Foundation Requirement ....... Common Water Chemistry Questions ..240 Volt Electrical Installation ....... Do’s and Dont’s .......... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY When using and installing this spa, basic safety precautions should always be followed, including. Danger: RISK OF SEVERE INJURY OR DROWNING! • NO DIVING, diving may result in injury or death. •... - Page 5 Warning: REDUCE RISK OF HEAT RELATED INJURY OR DEATH • Prolonged exposure to hot air or water can induce hyperthermia. Hyperthermia occurs when the internal temperature of the body reaches a level between 3°F (2°C) to 6°F (4°C) above the normal body temperature of 98.6°F (37°C).
-
Page 6: Preparing For Your Portable Spa
Preparing for Your New Portable Spa Preparing for Your New Portable Spa Pre-Delivery Checklist � Pre-Delivery Checklist Most cities and counties require permits for Most cities and counties require permits for exterior Before Delivery □ exterior construction and electrical circuits. construction and electrical circuits. -
Page 7: Foundation Requirement
Preparing a Good Foundation Preparing a Good Foundation NOTE: We strongly recommend that a qualified, licensed contractor prepare the foundation for your spa. Note: We strongly recommend that a qualified, licensed contractor prepare the foundation for your spa. Damage caused by inadequate or improper foundation support is not covered by the warranty. It is the Damage caused by inadequate or improper foundation support is not covered in your warranty. -
Page 8: Clearance For Service Access
Clearance for Service Access Clearance for Service Access 3 feet / 1 meter 3 feet / 3 feet / 1 meter 1 meter 3 feet / 1 meter... -
Page 9: Opening The Front Panel
Opening the Front Panel For Electrical Access Opening the Front Panel For Electrical Access panel. Note: The control box inside of your spa may appear different than illustrated above. Different control boxes are used based on options and features within your spa. -
Page 10: Opening V-Elite Panels
Opening the Front Door Panel (V-Elite Panel) Opening the Front Door Panel (V-Elite Panel) Some Cal Spa models have an add on option of unique V Elite panels. Each side panel is made of removable segments, and require different steps to open. When removing the front panel, or any of your side panels, its necessary to remove the corners of the spa as well. -
Page 11: Removing Of Shipping Materials
Removing Shipping Materials Your Cal Spa is wrapped with a white shrink wrap designed to protect the acrylic shell from scratches and damage. Thoroughly inspect the plastic wrapping for any tears and or damage that may have occurred during shipping. It is expected to see some scuffs or small tears at the base and corners of the spa, as the spa is pushed and shifted around in transport. -
Page 12: Gfci Diagram Usa/Canada
GFCI Wiring Diagram for USA and Canada GFCI Wiring Diagram for USA and Canada Testing the GFCI Breaker Testing the GFCI Breaker Test the GFCI breaker prior to first use and periodically when the spa is powered. To test the GFCI breaker. 1- Press the TEST button on the GFCI. -
Page 13: Filling And Powering Up The Spa
Filling and Powering Up the Spa Filling and Powering Up the Spa If the spa is equipped with a 75 sqft filter (color may vary), turn the skimmer component counterclockwise to unlock the skimmer. Pull the skimmer directly upward, after removal the retainer ring and basket are easily removed. - Page 14 Step 3. Fill the Spa Place the water hose inside the filter canister. Fill your spa with regular tap water about six inches from the top. If the water level is too low or too high, your spa will not operate correctly. NOTE: Never fill with soft water.
- Page 15 Step 6. Install filter into the filter canister Note: Make sure you have removed and soaked the spa filter cartridge in a bucket of water for at least 30 minutes. This will remove air pockets inside of the filter. When re installing the filter cartridge, do not over tighten the filter, the threaded bit inside of the filter housing is made of a corrosion resistant ABS plastic.
-
Page 16: Priming The Pump
Priming the Pump Priming the Pump New owners often have difficulty the first time they start their spa and the pumps fail to prime. This can be frustrating but these instructions should help you resolve any issues with air pockets inside of the primary pump or other priming issues. - Page 17 This Page is Intentionally Blank.
-
Page 21: Menu Navigation
Main Screen Menu Navigation The right Navigation arrow (A) on the Main screen indicates a menu. Press the RIGHT navigation button to enter that menu. A selection box (C) indicates that a menu item is selected. When a menu item is selected, its name appears at the top of the screen (B). -
Page 22: Navigate The Main Menu
Main Screen Navigate the Main menu 1 - Start from the Main screen (A), and press the RIGHT navigation button to enter the Main menu. If the Selection box (B) is on the Message icon, you need to press the RIGHT navigation button twice to enter the Main menu. -
Page 23: Set Time-Of-Day
SET TIME-OF-DAY Be sure to set the Time-of-Day Setting the Time-of-Day can be important for determining water filtration times and other background features. Follow these steps to set the time-of-day: 1 - Navigate to Time (A).* 2 - Press the SELECT navigation button, and the Time screen will appear (B). -
Page 24: Set Temperature
Main Screen CHANGE THE SET TEMPERATURE Follow these steps to change the Set Temperature: 1 - Start at the Main screen (A). Press the SELECT navigation button to view the temperature menu (E). 2 - Press the RIGHT and/or LEFT navigation buttons to change the Set Temperature. -
Page 25: Spa Heat Modes
HEAT SETTINGS HEAT MODES Follow these steps to view the current Heat Mode and/or change the Heat Mode: 1 - Navigate to Heat (A).* 2 - Press the SELECT navigation button to view the Heat screen (B). The current Heat Mode will appear here (C). -
Page 26: Operating Temperature Ranges
HEAT SETTINGS TEMPERATURE RANGES Follow these steps to view the current Temperature Range and/or change the Temperature Range: 1 - Navigate to Heat (A).* 2 - Press the SELECT navigation button to view the Heat screen (B). The current Temperature Range will appear here (C). -
Page 27: Restrict Operations (Lock/Unlock)
RESTRICT OPERATIONS The control can be restricted to prevent unwanted use or temperature adjustments. Locking the Panel (D) prevents the controller from being used, but all automatic functions are still active. Locking the Settings (C) allows Jets and other features to be used, but the Set Temperature and other programmed settings cannot be adjusted. -
Page 28: Setting Filter Cycles
SET FILTER CYCLE TIMES Keep your water clean and ready to enjoy! Follow these steps to set the Filter Cycles: 1 - Navigate to Filter (A).* 2 - Press the SELECT navigation button to view the Filter screen (B). 3 - Select the start time for Filter Cycle 1 (C). Press the SELECT navigation button to view the time controls (E). -
Page 29: Spa Features
Spa Features and Operation Spa Features and Operation Jets Jets Almost all of the jets in your spa are adjustable. Rotating the jet face clock- wise will increase water pressure, and counter clockwise to reduce pressure on that specific jet. Neck jets are the opposite, with clockwise movement to decrease force, counter clockwise to increase. -
Page 30: Led Lighting
LED Lighting LED Lighting Press the “Light” button on the topside controller to turn the spa light on. If your spa has optional perimeter LED lights, they will also activate. 1. Cycle: When you press the “Light” button on 3. Fading cycle: The next phase of operation and off repeatedly the LED will cycle between when you push the LIGHT button is a slower a variety of colors that the RGB light can sup-... -
Page 31: Ats Therapy System
ATS Therapy Seat System ATS Therapy Seat System Pump Button (On/Off): Press the “Pump” button to activate the ATS system. The pump will turn on full speed with letter “H” displayed in the LCD pan- el, the pump LED light will turn on. Press the pump button a second time to tun off the ATS system. -
Page 32: Water Clarity
Water Clarity Water Clarity This section is intended for new spa owners who are not familiar with adjusting spa water chem- istry. Everyone’s knowledge with maintaining water quality is different, but there are some general concepts you need to know. Water maintenance is not difficult, however it is something that requires regular attention. -
Page 33: Balancing Water Chemistry
Balancing Water Chemistry Levels Balancing Water Chemistry Levels Maintaining spa water chemistry can be tricky, especially since there are many methods of keeping your water clear and clean. Note: We do not recommend a specific brand of chemicals. See a spa dealer for guidance and recommendations on spa chemicals and supplied needed, as water chemistry varies from region to region. -
Page 34: Sanitation And Shock
Balancing the pH The pH level is the measure of acidity and alkalinity. Values above 7.8 are alkaline; those below 7.2 are acidic. Maintaining the proper pH level is extremely important for optimizing the effectiveness of the sanitizer, maintaining water that is comfortable for the user, and preventing equipment deterioration. If the spas water’s pH level is too low, the following may result: The sanitizer will dissipate rapidly •... - Page 35 Starting & Maintaining Sanitizer Levels After you choose a sanitizer, you will need to establish a baseline and maintain it regularly. Sanitizing your spa with chlorine or bromine is very similar. Each sanitizer has its advantages and disad- vantages. Sanitizer helps neutralize bacteria that can cause illness and other organic matter. Bromine: Creates less odor and skin irritation than chlorine, bromine is less likely to do so.
-
Page 36: Filtration & Cleaning
Shocking the Water In addition to using a chemical sanitizer, you will periodically need to shock the water. Shocking the water helps remove burned-out chemicals, bacteria, and other organic material from your spa’s water and im- proves your sanitizer’s effectiveness. Do not use chlorinating shock, which can damage the spas jets and pump seals. -
Page 37: General Water Care Schedule
General Water Care Schedule General Water Care Schedule Each time you refill the spa Each time you refill the spa Generic Names for Chemicals Generic Names for Chemicals... -
Page 38: Troubleshooting Water Clarity
Troubleshooting Water Clarity Troubleshooting Water Clarity... -
Page 39: Bather Load & Ozonator
Bather Load Bather Load “Bather Load” is the term used to describe the number of people using a spa, combined with the length of usage, and the frequency of usage. All these factors have a great effect on the spa water. The higher the bather load, the more chemicals need the be added and a longer filtration time will be needed. -
Page 40: Common Water Chemistry Questions
Common Water Chemistry Questions Common Water Chemistry Questions Question : Why is the use of a floater not recommended to sanitize my spa water? Answer: We do not recommend the use of a floater for three reasons: • The floater is unable to control the rate at which the sanitizer is dissolved into the water. When a floater is placed into a spa the sanitizer levels inside the spa can be extremely high. -
Page 41: Do's And Dont's
Question : When I open my spa, I smell chlorine. How to I get rid of the smell? Answer: There are two types of chlorine in your spa. the first is “Free Chlorine” which is chlorine molecules that are available to sanitize your spa. This free chlorine does not have an odor. -
Page 42: Chemical Abuse
Chemical Abuse Chemical Abuse Chemical abuse is defined as negligent/careless use of both recommended spa chemicals, and use of prohibited chemicals. The spa shell is designed to last for many years, but when the shell is exposed to excessive chemicals, or improper chemical application; this can cause reactions on the shell that can cause pitting, cracks, bubbling, and other blemishes on the shell. -
Page 44: Cleaning And Maintenance
Cleaning and Maintenance Cleaning and Maintenance Removing and Re-seating Pillows You can remove the pillows for clean- ing and maintenance quickly and easily. This method works for all pillow types. Grab the lower edge of the pillow with both hands and firmly pull up, as you do this the pillows inserts will pop out of the holes. -
Page 45: Spa Cover Locking System Installation
Spa Cover and Locking System Installation Spa Cover and Locking System Installation The spa cover can be considered one of the most important parts of your spa. The spa cover helps retain the heat inside of your spa in all different types of weather. The cover works as a lid on a thermos, when the spa is not in use the cover helps lower the amount of time the spas heater has to run for. - Page 46 Use a screwdriver to finish screwing in the three screws, repeat this process for the remaining Step 4 3 corners. Keep the cover fastened down at all times when not in use, locking hardware may be locked Step 5 with a key (provided in the packaging of the spa cover) The provided key will allow you to Step 6 lock down your spa cover.
-
Page 47: Draining Your Spa
Draining Your Portable Spa Draining Your Portable Spa Your spa should be drained every four to six months for cleaning and maintenance and refilled with fresh tap water. Before you begin turn the power off to the spa at the breaker and remove your filters. Step 1. -
Page 48: Winterization (Cold Climate Draining)
Winterizing (Cold Climate Draining) Winterizing (Cold Climate Draining) Depending on your region in your country, the temperature could drop below 32F(0°C). If you are one of those regions, we recommend that you always have your spa full of water and running at normal spa tem- peratures between 80°F - 100°F (26.7°C - 37.8°C). -
Page 49: Spa Cover And Shell Maintenance
Spa Cover and Shell Maintenance Spa Cover and Shell Maintenance Spa Cover and Pillows Due to constant punishment your spa cover and pillows receive, you should protect them by applying a vinyl and leather cleaner as part of your monthly maintenance plan. Use a product that is specifically designed to protect spa covers and pillows from chemical and ultraviolet light damage without leaving an oily residue behind that is normally associated with common automotive vinyl protectants. - Page 50 This Page is Intentionally Blank...
-
Page 51: Cal Connect Rf Set Up Guide
Cal Connect RF Set Up Guide Congratuations! Welcome to Cal Connect Control My Spa, the smart control system for spa monitoring on the go. With Cal Connect you will be able to control/monitor water temperture, control pump operation, adjust filtration, and monitor/control any activity occuring within your spa. This Quick Start guide will help you with inital set up of your RF module. - Page 52 Download the Control My Spa App To Begin the inital set up of the Cal Connect system, download the “Control My Spa” app by Balboa Water Group from the App Store or Google Play Store. Before starting the app, have your CMS code in hand. This is a unique code provided to you by your dealer.
- Page 53 Control My Spa Set-Up 5- The App will begin scanning for the spas wifi module. within a few seconds the module serial number should appear. 6- Select the “Yes” option once the serial number appears on screen and proceed with the following steps.
- Page 54 This Page is Intentionally Blank.
-
Page 55: Replacement Parts
Replacement Parts Black “Y” Pillow Carbon Fiber Black “Y” Pillow Carbon Fiber Design S-01-4324 Design S-01-4324 ACC01401102 ACC01401102 Black “Y” Pillow Carbon Fiber Design S-01-4324 ACC01401102 PILLOWS Black Cascade Pillow Carbon Fiber Design S-01-4325 ACC01401103 Filter Retainer Ring Retainer ring for filter housings built after 7/2024 Part#: FIL519-2011 Black “Y”... - Page 56 AIR CONTROL CS6603709-CD L Part # "Cal Spas 1” Air Control Complete Assembly, Velocity Style, CDG/HLG Part # PLUCS6054309-CDCL "Cal Spas 1” Air Control Complete Assembly, Velocity Style, CDG/HLG" Part # CS6053309-CD L "Cal Spas 2 ” Top Access Diverter Valve Sub-Assembly, Velocity Style,CDG/HLG“...
- Page 57 CLUSTER JETS Part#: PLUCS2441009S-CDCL Part # Part#: PLUCS2442059S-CDCL CS2441009S-CD L Part # S2442059S-CD L Cluster Storm Internal, Directional, 4’’ Cluster Storm Internal, Directional 3’’ Mini Storm Internal, Multi-massage Mini Storm Internal, Multi-Massage, Velocity Esc., Metal – CDG/HLG Velocity Esc., Metal – CDG/HLG Velocity Metal Velocity Metal Part #...
- Page 58 WHIRLPOOL JETS POWER JETS Part#: PLUCS2394009S-CDCL Part # Part#: PLUCS2444009SS-CDCL CS2444049S-CD L Part # CS2394009S-CD L Part # CS2444009SS CD L Adjustable Whirlpool Pwr. Storm Internal, Metal 5’’ Power Storm, Directional Eyeball Power Storm Internal, Twister, Adjustable Whirlpool Internal, Directional Eyeball, Velocity Velocity Metal Velocity Esc.
-
Page 63: Limited Warranty
LIMITED LIMITED WARRANTY WARRANTY This Limited Warranty is extended to the original purchaser of a spa produced by Lloyd’s Material Supply Company, This Limited Warranty is extended to the original purchaser of the spa produced by Lloyd’s Material Supply company, Inc. Inc. - Page 64 Structural This limited warranty covers defects within the spas fiberglass structural shell. This includes sudden spa shell col- lapse, leaking through the shell, and separation between the spa shell and spa acrylic, caused by faulty bonding. This does not include separation due to micro-abrasions, pin holes in the shell, or warping/bubbling due to sun exposure.
- Page 65 Sanitation This limited warranty covers malfunctions of factory installed Salt Systems and Bromine generators, which are warranted against malfunction due to defects in workmanship or materials. This includes the salt cell, sanitizer control panels, bromine generator, and power supplies for Cal Salt systems. This warranty does not cover negli- gent operation of sanitizer systems, chemical abuse, damage caused by improper water chemistry, or disregard of specified data points for safe operation;...
- Page 66 Performance This warranty begins on the date of delivery of the spa, but in no event later than one year from the date of manufacture. To obtain service in the event of a defect covered by this Limited Warranty, notify your Cal Spas dealer or Cal spas as soon as possible and use all reasonable means to protect the spa from further damage.
- Page 67 Limitations The manufacture disclaims all warranties, expressed or implies, in fact or in law, to the extent allowed by your State’s law, including the warranty of merchantability and fitness for use, except as stated specifically herein. All warranty service must be performed by the manufacture or its designated representative using authorized Cal Spas parts.
- Page 68 Contact Information For customer service or service technicians, please contact your authorized dealer immediately. If you need additional information and/or assistance, contact Lloyd’s Material Supply Company, Inc. Lloyd’s Material Supply Company, Inc. Customer Service Department 1462 East Ninth Street Pomona, CA 91766 LTR.2023.1010, REV.
