ccei VigiBrio Operating Instructions Manual
ccei VigiBrio Operating Instructions Manual

ccei VigiBrio Operating Instructions Manual

Connected control device for x3 lights

Advertisement

Quick Links

Table of Contents

1. Technical specifications ................................................................................................................... 2
2. Pack contents ............................................................................................................................... 2
3. Description .................................................................................................................................. 2
4. Compatible with the Vigipool environment .......... .................................................................................. 3
4.1. Bluetooth® and Wifi control ................................................................................................... 3
5. Installation ................................................................................................................................... 3
5.1. Wall mounted installation ............................................................................ .......................... 3
5.2. Connectors and wiring .......................................................................................................... 3
6. Start up ....................................................................................................................................... 5
6.1. Powering on ....................................................................................................................... 5
6.2. Choice of the "central unit" device Vigipool ................................................................................ 5
6.3. iOs / Android applications ...................................................................................................... 6
6.4. Adding new devices Vigipool ................................................................................................. 6
7. Thermal protection ........................................................................................................... .............. 6
7.1. Thermal circuit breaker ......................................................................................................... 6
8. Multicolour indicator ...................................................................................................................... 7
9. Colour selection ............................................................................................................................ 8
10. Reset to zero ....................... ........................................................................................................ 8
A. Declaration of conformity .............................................................................................................. 8
Read these instructions carefully before installing, commissioning and using this product.
MPNT05611.0EN (04/07/2024)
VigiBrio

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VigiBrio and is the answer not in the manual?

Questions and answers

Summary of Contents for ccei VigiBrio

  • Page 1: Table Of Contents

    VigiBrio Table of Contents 1. Technical specifications ........................2 2. Pack contents ..........................2 3. Description ..........................2 4. Compatible with the Vigipool environment .................... 3 4.1. Bluetooth® and Wifi control ....................3 5. Installation ........................... 3 5.1. Wall mounted installation ...................... 3 5.2.
  • Page 2: Technical Specifications

    The VigiBrio is compatible with Vigipool and can be interconnected with other devices in the Vigipool range. The VigiBrio is a 12VAC-powered box used to connect up to 8 MiniBrio 2 X3 (100W) lights or 4 MidBrio X3 (100W) lights.
  • Page 3: Compatible With The Vigipool Environment

    4.1. Bluetooth® and Wifi control The VigiBrio has an embedded Bluetooth® and Wifi transmitter used to control your device from a smartphone or tablet. To be able to control the VigiBrio, you need an iOs (Apple®) or Android smartphone or tablet running Bluetooth® Low Energy (v4.x) or Wifi 802.11 b/n/g.
  • Page 4 2. - 1.5m pre-wired cable supplied Connector and connection description The maximum power that can be controlled by the VigiBrio is 100W. If you have a lighting project that exceeds 100W in total power for the lights, contact your sales representative.
  • Page 5: Start Up

    On start up, the multicoloured indicator (A) on the front flashes while the device starts up. When you first start up the VigiBrio you must to choose its running mode: “Central unit” or “Client” (for example: if you already have Vigipool devices in your technical room).
  • Page 6: Ios / Android Applications

    (A) flashes blue quickly. 6.4. Adding new devices Vigipool If the VigiBrio is configured as a “central unit” and you want to add other Vigipool compatible equipment to your installation, the VigiBrio must accept new equipment. There are two possibilities to do that: •...
  • Page 7: Multicolour Indicator

    If the current is too high, the thermal circuit breaker will trip. Check the light installation before pressing the circuit breaker to reset it. The light power connected to a VigiBrio box must be less than 100 W. 8. Multicolour indicator...
  • Page 8: Colour Selection

    DMX output This mode is used by the VigiBrio to control third-party lights in DMX mode (DMX Master mode). To do that, simply connect the DMX light cable to the DMX connector on the VigiBrio box, then configure the corresponding DMX channels using the Vigipool app.

This manual is also suitable for:

Pf10r520

Table of Contents
