FontanaShowers
FontanaShowers
©
©
Product code: FS214CSB
FONTANA YVELINES SQUARE SHOWER HEAD WITH
MASSAGE JETS INSTALLATION INSTRUCTIONS
PRIOR TO INSTALLATION
Please read installation instructions below. All plumbing should be
installed in accordance with applicable building codes and regulations.
Unpack and inspect the items for any shipping damages. If you find
damages, do not install.
All products must be installed by a professional and certified plumber
otherwise warranty may be voided.
POSSIBLE TOOLS REQUIRED*
Level
Plumbers Tape
Tape Measure
Adjustable Wrench
Hex Wrench
Thread Sealant
Pencil or Marker
Screwdriver
Drill
*not included
fontanashowers.com
FontanaShowers
FontanaShowers
1
Customer Service: 800-684-4489
Advertisement
Related Manuals for Fontana Showers YVELINES FS214CSB
Summary of Contents for Fontana Showers YVELINES FS214CSB
- Page 1 FontanaShowers FontanaShowers © © Product code: FS214CSB FONTANA YVELINES SQUARE SHOWER HEAD WITH MASSAGE JETS INSTALLATION INSTRUCTIONS PRIOR TO INSTALLATION Please read installation instructions below. All plumbing should be installed in accordance with applicable building codes and regulations. Unpack and inspect the items for any shipping damages. If you find damages, do not install.
- Page 2 FontanaShowers FontanaShowers © © Ceiling Mount Shower Installations Instructions Step 1: Step 2: Step 3: Step 4: Step 5: fontanashowers.com FontanaShowers FontanaShowers Customer Service: 800-684-4489...
- Page 3 FontanaShowers FontanaShowers © © Step 1: Take Out the Old Shower Head You can easily remove it by hand, but depending on how long the rain showerhead has been installed, you might need to use an adjustable wrench. Hence, if you find it difficult to remove, rotate the showerhead with an adjustable wrench in a counterclockwise direction to unscrew it.
- Page 4 FontanaShowers FontanaShowers © © Hand Shower Installations Instruction Step 1: Step 2: 0.19” (4.8mm) Max 1. SUPPLY ELBOW INSTALLATION Apply plumber tape to threaded ends of 1/2" (13 mm) 2. Mark the place for drilling the hole for the lower iron pipe nipple (not supplied) and thread into post.
- Page 5 FontanaShowers FontanaShowers © © Step 4: 5. Slide the slide mechanism (1) and elbow (2) onto the wall bar (3). Slide wall bar over bracket tabs (4) and secure the wall bar unit with screws (5) provided. Install caps (6) into ends of wallbar. Lower elbow (7) &...
- Page 6 FontanaShowers FontanaShowers © © Body Jets Spray Installations Instruction Step 1: Attach the escutcheon to the Step 2: Apply teflon tape to threaded body spray. tail pipe of the body spray Step 3: Press the escutcheon against Step 4: Screw the Body spray tightly the finished wall into the female of water Supply Pressure Balancing Loop:...
- Page 7 FontanaShowers FontanaShowers © © Mixer Installations Instructions Step 1 Step 2 Anchor Positioning Tapping Screw 1 Tapping Screw 2 Button Cover Screw 1 Diverter Handle Temp. Handle Rough-in Body On/Off Plate Handle Hex Wrench Step 3 ( Connection) Function 1 Function 2 Hot water Cold water...
-
Page 8: General Information
FontanaShowers FontanaShowers © © General Information All products manufactured and supplied by Fontana are safe and comply to legislative requirements. Providing they are installed correctly and receive regular maintenance in accordance with these instructions your user experience will not be affected Care &...
