E+E Elektronik EEE371 Quick Manual

Quick Guide
EEE371 - Compact Dew Point Sensor
PLEASE NOTE
Find this document and further product information on our website at www.epluse.com/ee371.
Electrical Connection
WARNING
Incorrect installation, wiring or power supply may cause overheating and can therefore lead personal injuries or damage to
property. For correct cabling of the device, always observe the presented wiring diagram for the product version used.
The manufacturer cannot be held responsible for personal injuries or damage to property as a result of incorrect handling,
installation, wiring, power supply or maintenance of the device.
1 V+
2 GND
3 GND
6 1
7
4 OUT1
5 OUT2
2
5
6 NC
4 3
7 NC
Installation
PLEASE NOTE
Remove the protection cap right before installation.
6 1
7
2
5
3
4
OK
7-pole industrial plug:
10 - 30V DC
Cable cross-section:
Cable connection:
V
mA
V
mA
1 V+
10...30V DC
2 GND
3 NC11
4 NC12
5 NC21
Remove protection cap
6 NC22
7 not connected
DIN VDE 0627 / IEC 61984
0.25 - 1 mm²
PG11
NOT OK
