- Page 1 User Manual EE776 Flow Sensor for Compressed Air and Gases DN50 - DN700 (2" - 28")
-
Page 2: Table Of Contents
User Manual EE776 Content General Information ............................4 Explanation of Warning Notices and Symbols .................... 4 Safety Instructions ............................. 5 1.2.1. General Safety Instructions ..........................5 1.2.2. Intended Use ..............................5 1.2.3. Mounting, Start-up and Operation ........................5 Environmental Aspects..........................6 Scope of Supply .............................. - Page 3 User Manual EE776 Configuration Software ............................35 11.1 Introduction ...............................35 11.2 Installation ..............................35 11.3 User Interface ............................37 11.4 Menu Toolbar ............................37 11.4.1. File .................................. 37 11.4.2. Transmitter ..............................38 11.4.3. Extras ................................38 11.5 Input Screen .............................38 11.5.1. Output 1, Output 2 ............................38 11.5.2.
-
Page 4: General Information
All rights reserved by E+E Elektronik Ges.m.b.H. No part of this document may be reproduced, published or publicly displayed in any form or by any means, nor may its contents be modified, translated, adapted, sold or disclosed to a third party without prior written permission of E+E Elektronik Ges.m.b.H. -
Page 5: Safety Instructions
The plant operator should authorize qualified personnel to operate on the installation. ▪ The use of the flow sensor EE776 in any other way than described in this manual bears a safety risk for people and the entire measurement installation and is therefore not allowed. -
Page 6: Environmental Aspects
Environmental Aspects PLEASE NOTE Products from E+E Elektronik Ges.m.b.H. are developed and manufactured in compliance with all relevant environmental protection requirements. Please observe local regulations for the disposal of the device. For disposal, the individual components of the device must be separated according to local recycling regulations. -
Page 7: Product Description
3 Product Description General The EE776 flow sensor operates on the thermal mass flow measurement principle and is suitable for measuring the flow of air and gases in pipelines. Gases can be e.g. compressed air, nitrogen, helium, CO or other non- corrosive and non-flammable gases. -
Page 8: Dimensions
User Manual EE776 Dimensions Values in mm (inch) Enclosure Signal conditioning unit 145 (5.7) USB interface Drilling Plan Cross-section bore hole 129 (5.1) 2 (0.1) The bottom part of the enclosure is mounted with 4 screws (not in the scope of supply). Max. screw diameter: 4.5 mm (0.17 inch),... -
Page 9: Display
180 (7.09) Fig. 2 Dimensions Display EE776 is available with an optional 2-line liquid crystal display and soft keys. Please find details on capabilities and operation in chapter 6.3 Display / Indicator with Keypad (Optional). Flow Sensor for Compressed Air and Gases | 9... -
Page 10: Mounting And Installation
4.1.1. Process Pressure Due to its measurement principle, the thermal mass flow sensor EE776 is largely independent of the process pressure and is factory calibrated at a pressure of 9 bar (130.5 psi). In order to achieve the highest measurement accuracy, the slight dependence on process pressure can be compensated for in two ways: ▪... -
Page 11: Installation Position
User Manual EE776 Installation Position The flow sensor has a specified direction of flow. Make sure that the arrow on the tip of the sensing probe is pointing in the direction of the flow. Mounting Recommended Pipeline vertical, sensor horizontal... -
Page 12: Required Length Of Straight Pipe
User Manual EE776 Required Length of Straight Pipe The flow sensor should be installed as far as possible from disturbances of the flow. The causes for disturbance of the flow are for instance reducers, elbows, T-pieces, valves, gate valves, etc. The specified measurement accuracy can be achieved only when the following straight inlet and outlet pipe lengths are installed: ▪... -
Page 13: Installation In The Pipeline
User Manual EE776 Installation in the Pipeline The patented non-return protection device for reliable installation combines three functions in one unit: ▪ Non-return protection The sensor can only be pushed in one direction during installation. The sensor cannot return at all, even if it is released. - Page 14 User Manual EE776 Positioning in the pipeline NOTICE The sensor head must be positioned in the centre of the pipeline to ensure that the accuracy specified in the datasheet is maintained. The scale on the sensor pipe for the immersion depth refers to the centre of the sensor head.
- Page 15 User Manual EE776 If the sensor is immersed too far into the pipeline, it can be retracted again by unlocking the non-return protection device. To do this, the knurled nut is slowly pressed inwards. Similar to the pressure point in a car clutch, the immersion depth can be set to the desired millimetre value.
- Page 16 User Manual EE776 When the measurement sensor is correctly positioned in terms of immersion depth and alignment, tighten the knurled nut with a screw wrench (AF 27). Fig. 10 Tighten the knurled nut To prevent inadvertent twisting of the probe in use, tighten the grub screw.
-
Page 17: Setting The Pipe Diameter
User Manual EE776 Setting the Pipe Diameter The flow sensor is factory-set so that the average corrected flow speed is measured in the pipe. The Standardized volume flow is calculated by the flow sensor as follows: * ��/4 * 3600 ° * di... -
Page 18: Electrical Connection
User Manual EE776 5 Electrical Connection NOTICE The power supply must be switched off before the electrical connection is made. Failure to do so may damage the electronics. Only a qualified electrical engineer may install the device. ▪ Unscrew the four screws and remove the cover of the housing. -
Page 19: Relay And Pulse Output, Internal Switching
User Manual EE776 5.1.1. Relay and Pulse Output, Internal Switching OUT x-1 OUT x-2 The relay switch and pulse outputs are potential free. 5.1.2. Connection with Optional Plug for Power Supply and Outputs (Order Code E4) Assignment OUT 2-2 OUT 1-2... -
Page 20: Usb Configuration Interface
USB cable Fig. 15 USB interface connection D isplay / Indicator with Keypad (Optional) An optional 2-line display is available for the flow sensor EE776. The display is integrated into the enclosure cover and has two softkeys for controlling the display. Line 1 Pushbutton - UP Maximal : 1.3 m... -
Page 21: Indication Of The Analogue And Pulse Output
User Manual EE776 6.3.1. Indication of the Analogue and Pulse Output Line 1 always indicates the configured measurand at output 1. In line 2 the desired measurement value can be displayed using the UP and DOWN keys. Maximal : 1.3 m Maximal : 1.3 m... -
Page 22: Reset Of The Consumption Meter Or The Min / Max Value
User Manual EE776 Maximal : 1.3 m 6.3.4. Reset of the Consumption Meter or the MIN / MAX Value : 323.8 m T : 27.97 °C Keep both the UP and DOWN key pressed for >3 seconds to enter the menu for resetting the consumption meter or the MIN / MAX value. Select the desired menu item by pressing the UP or DOWN key briefly. Maximal Press the push-button UP and DOWN at the same time for >3 s : 323.8 m Rel : 1 Rel : 1 : 1.5 m... - Page 23 User Manual EE776 The table below shows the package structure of the measurement/consumption data sent by the EE77x sensor: Header Data Record 6: Pressure Start of telegram DIF (32 bit Real) 4F 4F L-field (Length) VIF (Pressure in bar) Second starting signal XX XX XX XX Act. measuring value C-field (RSP_UD) Data Record 7: Volume Flow A-field (Address) DIF (32 bit Integer)
-
Page 24: Modbus Rtu Register Map
The measured data is saved as 32 bit floating point values (data type FLOAT32). Depending on the measurement unit selected, measurements are saved in SI or US/GB units. The measurement unit can be changed using the configuration software. For resetting the MIN / MAX values, write 0 to the corresponding write register. For Modbus protocol setting please refer to Application Note AN0103 available at www.epluse.com/ee776. FLOAT32 US/GB Parameter Register number... -
Page 25: Device Address
User Manual EE776 6.4.4. Device Address The DIP switches on the electronics board can be used to set the device address directly on-board or to switch to software configuration. 1 - ON 1 - ON 0 - OFF 0 - OFF The flow sensors are factory-set to address 1. -
Page 26: Repairs
User Manual EE776 Repairs Repairs are to be carried out by the manufacturer only. The attempt of unauthorized repair invalidates any warranty claims. 8 Accessories Adapter BSP - NPT HA074004 Material: brass Values in mm (inch) 16 (0.63) 14 (0.55) 20 (0.79) 19 (0.75) 39 (1.54) -
Page 27: Ball Valve 1/2
User Manual EE776 Ball valve 1/2" HA074002 Material: brass Values in mm (inch) 70 (2.76) Ø 15 (0.6) 82.5 (3.25) Ball valve 1/2" for Bypass Measurement HA074003 Material: brass Values in mm (inch) 70 (2.76) Ø 15 (0.6) 82.5 (3.25) Lateral fitting Rp1/4" for mounting of pressure or dew point sensor Flow Sensor for Compressed Air and Gases | 27... -
Page 28: Tapping Sleeve (Delivery Without Ball Valve)
User Manual EE776 Tapping Sleeve (Delivery without Ball Valve) HA074xxx Material: stainless steel 1.4301 Values in mm (inch) Rubber sleeve Ball valve HA074002 25 (0.98) NBR 70 Shore G 3/4" Threaded nipple 150 (5.91) Pipe Clamping range [mm (inch)] Max. working pressure Order code DN50 (2") HA074050 47 - 67 (1.85 - 2.64) 16 bar (232 psi) DN65 (2 1/2") - Page 29 User Manual EE776 Description Sleeve Seal Threaded pin ® Delrin washer Retainer Bolt yoke Side bracket Sliding plate Fig. 20 Tapping sleeve components Site preparation work The mounting area must be freely accessible, and there must be sufficient working space available in the area around the pipe.
- Page 30 User Manual EE776 Mounting the sleeve The pipe on the sleeve must be completely free of dirt, rust and grease. The preferred option for cleaning is using a soap solution - this also improves the function of the sleeve. Seal material, pins and nuts must not be lubricated...
-
Page 31: Technical Data
User Manual EE776 The following torques are set when using a torque wrench: Thread size Tightening torque 65 Nm 85 Nm 110 Nm Tab. 9 Tightening torque for standard thread in [Nm] Using this method, the Delrin® washers should curve slightly around the nuts. - Page 32 Factory settings 2 400 Baud, parity even, 1 stop bit, M-Bus address 1 Supported Baud rates 600, 1 200, 2 400, 4 800 and 9 600 1) Find more details about communication setting in chapter and the Modbus Application Note at www.epluse.com/ee776. 2) Find more details about communication setting in the User Manual. Input External Dynamic Pressure Compensation Dynamic pressure compensation 4 - 20 mA (2-wire; 15 V) for pressure sensor (relevant for gases other than air and...
-
Page 33: Factory Setting Analogue Output
User Manual EE776 Flow Measuring Range in Dependence on Pipe Diameter Pipe Measuring range in m Inch 0.2...100 m/s (40...19 685 SFPM) 0.2...200 m/s (40...39 370 SFPM) DN50 1.7...839 m /h (0...493.8 SCFM) 1.7...1 679 m /h (1.0...987.6 SCFM) DN65 2 1/2 2.8...1 397 m /h (1.6...821.6 SCFM) 2.8...2 793 m /h (1.6...1 643.2 SCFM) DN80 3.8...1 923 m /h (2.3...1 131.5 SCFM) 3.8...3 847 m /h (2.3...2 263.0 SCFM) DN100 6.5...3 242 m /h (3.8...1 906.9 SCFM) 6.5...6 483 m /h (3.8...3 813.8 SCFM) -
Page 34: Replacement Parts / Accessories
User Manual EE776 10 Replacement Parts / Accessories 10.1 Order Code Replacement Sensor Description Feature Code PE776- Type Remote probe Measuring range HV31 High HV33 Maximum pipe diameter / probe length DN100 (4") / 215 mm (8.46") N100 DN300 (12") / 315 mm (12.4") N300 DN700 (28") / 515 mm (20.28") N700 Pipe diameter presetting DN50 (2") DN50 DN65 (2 1/2") DN65 DN80 (3") DN80 DN100 (4") DN100 DN125 (5") -
Page 35: Configuration Software
.NET Framework 3.5 SP1 can be installed using Windows Update. 11.2 Installation In order to set up a smooth installation of the configuration software of the EE776, admin authorization for the personal computer is required. ▪... - Page 36 User Manual EE776 C onfiguration of the USB Interface (VirtualCOM) After the startup of the software, the correct VirtualCOM interface for the USB driver must be configured. The number for the used USB interface can be found under: Start Settings Control Panel System Hardware Device Manager The setting is done under menu “Extras” and menu item “Optional extras ...”...
-
Page 37: User Interface
User Manual EE776 11.3 User Interface Function Basic information: After retrieving the data from the sensor, the basic information of the device is shown here. Status message: Here the status messages and other information are displayed. Input screen: Input screen for the configuration or adjustment of the flow sensor. -
Page 38: Transmitter
User Manual EE776 11.4.2. Transmitter PLEASE NOTE The term “Transmitter” is used synonymously with “Sensor” in this user manual. Menu Item Description Reads the actual configuration of the Read transmitter. Uploads the “new” configuration to the transmitter. The following settings are uploaded to the transmitter. - Page 39 User Manual EE776 Output Mode – Analogue Menu Description Within the limits of measurement range and the scaling of the output, the analogue output can be freely configured and scaled. Either a standard output signal (0 - 5 V, 0 - 10 V, 0 - 20 mA, 4 - 20 mA) can be selected or a user defined range for the current / voltage output (e.g. 1 - 9 V). PLEASE NOTE In case the analogue output is changed (from current to voltage or vice versa), the jumper J2 on the board of the signal conditioning electronics has to be relocated as well (refer to chapter 6.1 Jumpers for output...
- Page 40 User Manual EE776 Hysteresis set point 1 NO (activate to close) NC (activate to open) When the measurement value reaches set point 1, the relay will be activated. The value at the reset point is the value at set point 1 minus the hysteresis.
-
Page 41: Minimum Flow Shutdown
User Manual EE776 Output Mode – Pulse If output 2 is configured for pulse, the measurand can only be consumption. The duration of the pulse and the pulse value (significance level of the pulse) can be freely configured under “Pulse”. -
Page 42: Display
User Manual EE776 11.5.3. Display If an optional display is installed, at the tab Display the following items can be entered: Drop-down input field “Display-Mode” ▪ Single spaced ▪ Double spaced (default) Checkbox “Backlight” ▪ Checked = ON ▪ Unchecked = OFF In the input field “Description (free text)”,... - Page 43 User Manual EE776 The customer-adjustment results in a slight rotation of the characteristic line, in such a way that the measurement deviation at the upper and lower adjustment points equals zero. Depending on the position, the configuration software determines whether it is an upper or lower adjustment point.
-
Page 44: Measuring Values Overview
User Manual EE776 Lower adjustment point at 10% of measuring range Upper adjustment point at 90% of measuring range Characteristic line before adjustment 100% Characteristic line after adjustment 100% Measuring range Reset to Factory Settings Customer-adjustment can be reset to the factory settings by checking the appropriate checkbox and subsequently clicking the “reset”... -
Page 45: Setting Up Process Parameters
User Manual EE776 11.5.6. Setting up Process Parameters In the tab “Process Parameters” the Process gas (medium) can be changed and the pressure compensation can be set. Change the Process Gas PLEASE NOTE This function is only active if the flow sensor has been ordered for a medium other than air (refer to order code “Medium”... -
Page 46: External Pressure Sensor For Pressure Compensation
User Manual EE776 Setting the Inner Pipe Diameter PLEASE NOTE The actual inner diameter of the pipe must be set here. The “Send” button is only used to send the pipe diameter to the transmitter. 11.5.7. External Pressure Sensor for Pressure Compensation In order to achieve the highest accuracy in case of strongly fluctuating pressure (e.g. -
Page 47: Conformity
User Manual EE776 12 Conformity 12.1 Declarations of Conformity E+E Elektronik Ges.m.b.H. hereby declares that the product complies with the respective regulations listed below: European directives and standards UK statutory instruments and designated standards Please refer to the product page at www.epluse.com/ee776 for the Declarations of Conformity. - Page 48 T +91 990 440 5400 info.in@epluse.com E+E Elektronik Italia S.R.L. T +39 02 2707 86 36 info.it@epluse.com E+E Elektronik Korea Ltd. T +82 31 732 6050 info.kr@epluse.com E+E Elektronik Corporation T +1 847 490 0520 info.us@epluse.com BA_EE776 | Version v2.7 | 05-2024 | 193630 © Copyright E+E Elektronik Ges.m.b.H. | All rights reserved.
