Summary of Contents for ERNITEC Orion DX 3
- Page 1 Orion DX 3 Network PTZ Camera User’s Manual Ver. 1 Rv01.0.25.07.2018...
-
Page 3: Table Of Contents
Table of Contents Overview ..........................3 Features ........................3 Package Contents ....................... 4 Dimensions ........................5 Connectors ........................6 Camera Cabling ........................7 Power Connection ....................... 8 Ethernet Cable Connection ..................8 Audio / AIarm I/O & RS-485 Connection ..............9 System Requirements ...................... -
Page 4: Overview
Overview Orion DX 3 is a versatile outdoor PTZ camera that comes with 30x optical zoom module. It supports up to 4M real-time video in HDR mode. When the camera is operated in dual stream mode, the primary stream can be set at 720P, 1080P or 2M depending on models, and the secondary stream can be 720P or 1080p at 30 fps. -
Page 5: Package Contents
Please check the box contains the items listed here. If any item is missing or has defects, DO NOT install or operate the product and contact the dealer for assistance. Orion DX 3 Quick Guide Network PTZ Camera 2-Pin Power... -
Page 6: Dimensions
Dimensions... -
Page 7: Connectors
Connectors Refer to the diagrams below for the positions of the reset button and various connectors of the camera. Definition of the reset button and the connectors are given as follow. Connector Definition Power Connector DC12V power connection (DC12V) This connector is used to burn firmware into the camera when the camera is returned for Console Connector repair/maintenance. -
Page 8: Camera Cabling
Camera Cabling The outdoor models are being IP66-rated to prevent water from entering the camera. However, water might still enter the camera if it is being improperly installed. Please make sure the warnings below are strictly followed when installing the camera. NOTE: This camera must be installed by qualified personnel and the installation should conform to all local codes. -
Page 9: Power Connection
Power Connection To power up the camera, connect the DC12V or AC24V power adaptor to the power connector of the camera and the power outlet. Refer to the diagram and pin definition below for AC24V power connection. Definition AC24V L AC24V N Alternatively, users can use an Ethernet cable and connect it to the RJ-45 port of the camera and an IEEE 802.3at (PoE+) 2-Pair 30W switch. -
Page 10: Audio / Aiarm I/O & Rs-485 Connection
Audio / AIarm I/O & RS-485 Connection Please refer to the diagram and pin definition tables below for audio/alarm I/O & RS-485 connection. Definition Definition Definition Definition Alarm Out GND (Alarm Audio Out Alarm In 4 I/O & RS-485) Alarm Out Alarm In 3 Audio In (Audio I/O) -
Page 11: System Requirements
System Requirements To perform the camera via web browser, please ensure the PC is in good network connection, and meet the system requirement as described below. Items System Requirement Minimum : 1. Intel® Core i5-2430M @ 2.4 GHz 2. 4 GB RAM Personal Computer Recommended : 1. -
Page 12: Access Camera
Access Camera For initial access to the camera, users can search the camera through the installer program: DeviceSearch.exe. Accessing the Camera by Device Search Software Step 1: Double click on the program Device Search.exe. Step 2: After its window appears, click on the <Device Search> button on the top. - Page 13 1234 NOTE: ID and password are case sensitive. NOTE: It is strongly advised that administrator’s password be altered for the security concerns. Refer to the Orion DX 3 Network PTZ Camera Menu Tree for further details. Installing DCViewer Software Online For the initial access to the camera, a client program, DCViewer, will be automatically installed to the PC when connecting to the camera.
- Page 14 If zoom or focus is not at the desired position, please use the function buttons on the Home page for adjustment. Refer to the Orion DX 3 Network PTZ Camera Menu Tree for more details about the function buttons.
-
Page 15: Setup Video Resolution
HDR Mode For more details about the combinations of video resolution, please refer to the Orion DX 3 Network PTZ Camera Menu Tree. Configuration Files Export / Import To export / import configuration files, users can access the Maintenance page on... - Page 16 The Maintenance setting can be found under this path: System> Maintenance. Users can export configuration files to a specified location and retrieve data by uploading an existing configuration file to the camera. It is especially convenient to make multiple cameras having the same configuration. Export Users can save the system settings by exporting the configuration file (.bin) to a specified location for future use.
-
Page 17: Tech Support Information
Tech Support Information This chapter will introduce how to delete previously-installed DCViewer in the PC and how to setup the Internet security. Delete the Existing DCViewer For users who have installed the DCViewer in the PC previously, please remove the existing DCViewer from the PC before accessing to the IP camera. Deleting the DCViewer In the Windows <Start Menu>, activate <Control Panel>, and then double click on <Add or Remove Programs>. -
Page 18: Setup Internet Security
Setup Internet Security If ActiveX control installation is blocked, please either set Internet security level to default or change ActiveX controls and plug-ins settings. Internet Security Level: Default Step 1: Start the Internet Explorer (IE). Step 2: Click on the <Tools> tab on the menu bar and select <Internet Options>. Step 3: Click on the <Security>...
