Risco iWAVE DT Manual page 2

7 8
A
10 10A
DT TOP VIEW
90°
These detection pattern is only assured and approved according to EN50131, INCERT in High sensitivity
EN
settings. For low sensitivity setting, the actual detection pattern must be assured during the installation.
Questo metodo di rilevazione è assicurato e approvato in accordo con la norma EN50131, INCERT solo quando
IT
il rilevatore è in ALTA SENSIBILITA'. Per il settaggio in bassa sensibilità, questo metodo di rilevazione è
assicurato solamente durante l'installazione.
Estos patrones de detección sólo están garantizados y aprobados conforme a EN50131, INCERT en la
ES
configuración de Alta sensibilidad. Para la configuración de Baja sensibilidad, el patrón exacto de detección
debe asegurarse durante la instalación.
Cette couverture de détection n'est assurée et approuvée selon la norme EN50131, INCERT qu'avec un
FR
réglage en Haute Sensibilité. Pour un réglage avec une Faible Sensibilité, la couverture de détection devra
être vérifiée au cours de l'installation.
Este padrão de detecção só é garantido e aprovado de acordo com a EN50131, INCERT com o ajuste
PR
para alta sensibilidade. Para ajuste de baixa sensibilidade, o padrão real de detecção deve ser
certificado durante a instalação.
Deze detectie patroon, in lijn met de EN 50131, INCERT norm, zijn alleen geldig als de parameters op het
NL
maximum gevoeligheid niveau afgesteld zijn. Voor een lager detectie niveau, de detectie patroon zou op het
moment van de installatie moeten afgesteld worden.
Das oben abgebildete Detektionsmuster ist nur bei hohen Empfindlichkeitseinstellungen gegeben, gemäß
DE
EN50131, INCERT Bei niedriger Empfindlichkeitseinstellung, muss die tatsächliche Detektionsfläche bei der
Installation geprüft werden.
0-20Min
5
B C
2 x CR 123, 3V Lithium
PIR: 15 A standby
Pet: 16 A standby
868.65MHz / 433.92MHz
24 GHz (MW)
90°
T 0-255 min.
= 3 Y Typical
DT PET TOP VIEW
67.5mm
(2.6")
-10°C > 55°C
(14°F > 140°F)
APPROVALS
(Models: RWX95DT and RWX95DTP)
EN50131-2-4 Grade 2 Environmental Class II
EN50131-6: Type C
Low Battery Threshold: 2.6V
Power Output (868.65 MHz): 10mW Max.
Power Output (24 GHz): 20dBm Max.
EN
9
Parameters
Sensitivity (PIR)
Sensitivity (MW) 6 Levels
Operation
Supervision
LED
For more information refer to the Installer Guide.
ES
Normal
Parámetros
2.5 min.
Sensibilidad (PIR)
Sensibilidad (MW)
Funcionamiento
Supervisión
LED
PR
Parâmetros
Sensibilidade (PIR)
Sensibilidade (MW)
Operação
Supervisão
*
LED
Para mais informações, consulte o guia de instalação
do sistema.
DE
Parameter
Empfindlichkeit (PIR)
Empfindlichkeit (MW)
Betrieb
Ueberwachung (Supervision)
LED
Raadpleeg de systeeminstallatiehandleiding voor meer informatie.
Standard Limited Product Warranty
RISCO Ltd. ("RISCO") guarantee RISCO's hardware products ("Products") to be free from defects in materials and workmanship when used and stored under normal conditions and in accordance with the instructions for
use supplied by RISCO, for a period of (i) 24 months from the date of delivery of the Product (the "Warranty Period"). This Limited Warranty covers the Product only within the country where the Product was originally
purchased and only covers Products purchased as new.
Contact with customers only. This Limited Warranty is solely for the benefit of customers who purchased the Products directly from RISCO or from an authorized distributor of RISCO. RISCO does not warrant the Product
to consumers and nothing in this Warranty obligates RISCO to accept Product returns directly from end users who purchased the Products for their own use from RISCO's customer or from any installer of RISCO, or
otherwise provide warranty or other services to any such end user directly. RISCO's authorized distributor or installer shall handle all interactions with its end users in connection with this Limited Warranty. RISCO's
authorized distributor or installer shall make no warranties, representations, guarantees or statements to its end users or other third parties that suggest that RISCO has any warranty or service obligation to, or any contractual
privy with, any recipient of a Product.
Remedies. In the event that a material defect in a Product is discovered and reported to RISCO during the Warranty Period, RISCO shall accept return of the defective Product in accordance with the below RMA procedure
and, at its option, either (i) repair or have repaired the defective Product, or (ii) provide a replacement product to the customer.
Return Material Authorization. In the event that you need to return your Product for repair or replacement, RISCO will provide you with a Return Merchandise Authorization Number (RMA#) as well as return instructions.
Do not return your Product without prior approval from RISCO. Any Product returned without a valid, unique RMA# will be refused and returned to the sender at the sender's expense. The returned Product must be
accompanied with a detailed description of the defect discovered ("Defect Description") and must otherwise follow RISCO's then-current RMA procedure published in RISCO's website at
with any such return. If RISCO determines in its reasonable discretion that any Product returned by customer conforms to the applicable warranty ("Non-Defective Product"), RISCO will notify the customer of such
determination and will return the applicable Product to customer at customer's expense. In addition, RISCO may propose and assess customer a charge for testing and examination of Non-Defective Product.
Entire Liability. The repair or replacement of Products in accordance with this Limited Warranty shall be RISCO's entire liability and customer's sole and exclusive remedy in case a material defect in a Product is discovered
and reported as required herein. RISCO's obligation and this Limited Warranty are contingent upon the full payment by customer for such Product and upon a proven weekly testing and examination of the Product
functionality.
Limitations. This Limited Warranty is the only warranty made by RISCO with respect to the Products. The warranty is not transferable to any third party. To the maximum extent permitted by applicable law, this Limited
Warranty shall not apply and will be void if: (i) the conditions set forth above are not met (including, but not limited to, full payment by customer for the Product and a proven weekly testing and examination of the Product
functionality); (ii) if the Products or any part or component thereof: (a) have been subjected to improper operation or installation; (b) have been subject to neglect, abuse, willful damage, abnormal working conditions, failure
to follow RISCO's instructions (whether oral or in writing); (c) have been misused, altered, modified or repaired without RISCO's written approval or combined with, or installed on products, or equipment of the customer or
of any third party; (d) have been damaged by any factor beyond RISCO's reasonable control such as, but not limited to, power failure, electric power surges, or unsuitable third party components and the interaction of
software therewith or (e) any failure or delay in the performance of the Product attributable to any means of communication provided by any third party service provider, including, but not limited to, GSM interruptions, lack
of or internet outage and/or telephony failure. BATTERIES ARE EXPLICITLY EXCLUDED FROM THE WARRANTY AND RISCO SHALL NOT BE HELD RESPONSIBLE OR LIABLE IN RELATION THERETO, AND THE
ONLY WARRANTY APPLICABLE THERETO, IF ANY, IS THE BATTERY MANUFACTURER'S WARRANTY. RISCO does not install or integrate the Product in the end user's security system and is therefore not
responsible for and cannot guarantee the performance of the end user's security system which uses the Product or which the Product is a component of.
56mm This Limited Warranty applies only to Products manufactured by or for RISCO. Further, this Limited Warranty does not apply to any software (including operating system) added to or provided with the Products or any
third-party software, even if packaged or sold with the RISCO Product. Manufacturers, suppliers, or third parties other than RISCO may provide their own warranties, but RISCO, to the extent permitted by law and except as
(2.2")
otherwise specifically set forth herein, provides its Products "AS IS". Software and applications distributed or made available by RISCO in conjunction with the Product (with or without the RISCO brand), including, but not
limited to system software, as well as P2P services or any other service made available by RISCO in relation to the Product, are not covered under this Limited Warranty. Refer to the Terms of Service at:
warranty for details of your rights and obligations with respect to the use of such applications, software or any service. RISCO does not represent that the Product may not be compromised or circumvented; that the Product
will prevent any personal injury or property loss by burglary, robbery, fire or otherwise, or that the Product will in all cases provide adequate warning or protection. A properly installed and maintained alarm may only
reduce the risk of a burglary, robbery or fire without warning, but it is not insurance or a guarantee that such will not occur or will not cause or lead to personal injury or property loss. CONSEQUENTLY, RISCO SHALL
HAVE NO LIABILITY FOR ANY PERSONAL INJURY, PROPERTY DAMAGE OR OTHER LOSS BASED ON ANY CLAIM AT ALL INCLUDING A CLAIM THAT THE PRODUCT FAILED TO GIVE WARNING.
EXCEPT FOR THE WARRANTIES SET FORTH HEREIN, RISCO AND ITS LICENSORS HEREBY DISCLAIM ALL EXPRESS, IMPLIED OR STATUTORY, REPRESENTATIONS, WARRANTIES, GUARANTEES, AND
CONDITIONS WITH REGARD TO THE PRODUCTS, INCLUDING BUT NOT LIMITED TO ANY REPRESENTATIONS, WARRANTIES, GUARANTEES, AND CONDITIONS OF MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE, TITLE AND WARRANTIES AGAINST HIDDEN OR LATENT DEFECTS, TO THE EXTENT PERMITTED BY LAW. WITHOUT LIMITING THE GENERALITY OF THE FOREGOING, RISCO AND
ITS LICENSORS DO NOT REPRESENT OR WARRANT THAT: (I) THE OPERATION OR USE OF THE PRODUCT WILL BE TIMELY, SECURE, UNINTERRUPTED OR ERROR-FREE; (ii) THAT ANY FILES, CONTENT OR
INFORMATION OF ANY KIND THAT MAY BE ACCESSED THROUGH THE PRODUCT SHALL REMAIN SECURED OR NON DAMAGED. CUSTOMER ACKNOWLEDGES THAT NEITHER RISCO NOR ITS
LICENSORS CONTROL THE TRANSFER OF DATA OVER COMMUNICATIONS FACILITIES, INCLUDING THE INTERNET, GSM OR OTHER MEANS OF COMMUNICATIONS AND THAT RISCO'S PRODUCTS, MAY
BE SUBJECT TO LIMITATIONS, DELAYS, AND OTHER PROBLEMS INHERENT IN THE USE OF SUCH MEANS OF COMMUNICATIONS. RISCO IS NOT RESPONSIBLE FOR ANY DELAYS, DELIVERY FAILURES, OR
OTHER DAMAGE RESULTING FROM SUCH PROBLEMS. RISCO WARRANTS THAT ITS PRODUCTS DO NOT, TO THE BEST OF ITS KNOWLEDGE, INFRINGE UPON ANY PATENT, COPYRIGHT, TRADEMARK,
TRADE SECRET OR OTHER INTELLECTUAL PROPERTY RIGHT IN ANY EVENT RISCO SHALL NOT BE LIABLE FOR ANY AMOUNTS REPRESENTING LOST REVENUES OR PROFITS, PUNITIVE DAMAGES, OR
FOR ANY OTHER INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, EVEN IF THEY WERE FORESEEABLE OR RISCO HAS BEEN INFORMED OF THEIR POTENTIAL
Contacting RISCO Group
RISCO Group is committed to customer service and product support. You can contact us through our website www.riscogroup.com or as follows:
United Kingdom Spain
Tel: +34-91-490-2133
Tel: +44-161-655-5500
technical@riscogroup.co.uk support-es@riscogroup.com
Italy France
Tel: +39-02-66590054 Tel: +33-164-73-28-50
support-fr@riscogroup.com
support@riscogroup.it
IT
Parameters set by the system:
Option
Low/High
(min. 25%, 50%, 65%, 85%, max.)
Normal (2.5 min) / Walk Test (0)
0-255 min
Off/On
Per maggiori informazioni vedere la guida di installazione.
FR
Parámetros configurados:
Opción
Baja / Alta
6 Niveles
(min. 25%, 50%, 65%, 85%, max.)
Normal (2,5 min)/Test de Paseo (0)
0-255 min
Apagado / Encendido
Para más información, consulte el manual de instalación. Pour plus d'informations, consultez le manuel d'installation.
Parâmetros do seteo: NL
Opção
Baixa/Alta
6 Níveis *
(min. 25%, 50%, 65%, 85%, max.)
Normal (2.5 min)/Teste de Caminhada (0)
0-255 min
Desativado/Ativado
Raadpleeg de systeeminstallatiehandleiding voor meer
informatie.
UKCA and CE RED Compliance Statement:
iWAVE-Parameter einstellbar über Zentrale:
Hereby, RISCO Group declares that this equipment is in
Funktion
compliance with the essential requirements of the UKCA
Niedrig / Hoch
Radio Equipment Regulations 2017 and CE Directive
6 Stufen (min., 25%, 50%, 65%, 85%, max.)
2014/53/EU.
Normal (2,5min) / Schnell (Gehtest)
For the UKCA and CE Declaration of Conformity please
0-255 min
refer to our website:
Ein / Aus
www.riscogroup.com
Israel
Belgium
Tel: +32-2522 7622 Tel: +972-3963-7777
support-be@riscogroup.com support@riscogroup.com
USA Italy
Tel: +39-02-66590054
Tel: +1-631-719-4400
support-usa@riscogroup.com support@riscogroup.it
Parametri impostati dalla centrale:
Parametri Opzione
Sensibilita' (PIR) Bassa/Alta
Sensibilita' (MW) 6 Livelli (min. 25%, 50%, 65%, 85%, max.)
Modo operativo Normale (2.5 min)/Test Sensore (0)
Supervisione 0-255 min
LED Off/On
Paramètres configurés:
Paramètres Option
Sensibilité (PIR) Faible/Elevé
Sensibilité (MW) 6 Niveaux
(min. 25%, 50%, 65%, 85%, max.)
Operation Normal (2.5 min)/Test de marche (0)
Surveillance 0-255 min
LED Off/On
Geprogrammeerde parameters:
Geprogrammeerde Optie
Gevoeligheid (PIR) Hoog/laag
Gevoeligheid (MW) 6 Niveaus
(min. 25%, 50%, 65%, 85%, max.)
Bedrijfsmodus Normaal (2.5 min)/Looptest (0)
Controletijd 0-255 min
LED Uit/Aan
www.riscogroup.com in connection
www.riscogroup.com/
© RISCO Group 01/2022 5IN2184 C
