V-TAC VT-44031 Instruction Manual

TECHNICAL DATA
BEAM LIFE
MODEL SKU WATTS LUMENS DF CRI
ANGLE SPAN
VT-44031 10353 Sphere
30W 4800
23691 360°
Sphere
VT-44051 10354 50W 8000
360°
Sphere
100W
VT-44106 10355 16000
360°
Sphere
10362
VT-44160 150W 24000
360°
10363 Sphere
VT-44206 200W 32000
10365
360°
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions carefully
before starting the installing and keep this manual handy for future reference. If you have any another query, please
contact our dealer or local vendor from whom you have purchased the product. They are trained and ready to serve you
at the best. The warranty is valid for 2 years from the date of purchase. The warranty does not apply to damage caused by
incorrect installation or abnormal wear and tear. The company gives no warranty against damage to any surface due to
incorrect removal and installation of the product. The products are suitable for 10-12 Hours Daily operation. Usage of
product for 24 Hours a day would void the warranty. This product is warranted for manufacturing defects only.
02
SPHERE
360°
WARRANTY*
MAX
INPUT OPERATION N.W.
DIMENSION MOUNTING
VOLTAGE TEMPERATURE (KGS)
HEIGHT
164.5x34x153mm
0.41 <5M
0.56 <5M
183.5x34x169mm
253.5x40x242.5mm 1.1 <5M
328.5x43x295mm 1.78 <5M
402.5x44x349.5mm
2.8 <5M
C C
SUPER BRIGHT
160
+
LM/WATT EFFICIENCY
WARNING
• Please make sure to turn o the power before starting the installation.
• Installation must be performed by a qualified electrician.
• The light source contained in this luminaire shall only be replaced by the manufacturer or his
service agent or a similar qualified person.
• The external flexible cable or cord of this luminaire cannot be replaced; if the cord is damaged,
the luminaire shall be destroyed.
• Replace any cracked protective shield.
• Terminal block not included.
• Proper grounding should be ensured throughout the installation.
• Minimum distance from lighted objects 1m.
• For outdoor use.
NOTE: To reduce the risk of strangulation the flexible wiring connected to this
luminaire shall be e ectively fixed to the wall if the wiring is within arm's reach.
INSTALLATION DIAGRAM
PROJECTED WIRE
AREA(MM²) LENGTH
25168.5 150 mm
31011.5 150 mm
61473.75 1 M
96907.5 1 M
140673.75 1 M
