V-TAC VT-4435 Instruction Manual

TECHNICAL DATA
SKU WATTS LUMENS BEAM
MODEL
9255
VT-4435 30W 5550Lm
9891
9892
VT-4456 50W 9250Lm
9893
9894
VT-44105
100W
18500Lm
9895
9896
200W
VT-44205 37000Lm
9897
*This product contains a light source of energy e ciency class<B>,where <B> shall be replaced by the energy class of
the contained light source.
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions carefully
before starting the installing and keep this manual handy for future reference. If you have any another query, please
contact our dealer or local vendor from whom you have purchased the product. They are trained and ready to serve you
at the best. The warranty is valid for 2 years from the date of purchase. The warranty does not apply to damage caused by
incorrect installation or abnormal wear and tear. The company gives no warranty against damage to any surface due to
incorrect removal and installation of the product. The products are suitable for 10-12 Hours Daily operation. Usage of
product for 24 Hours a day would void the warranty. This product is warranted for manufacturing defects only.
This marking indicates that this
product should not be disposed
of with other household wastes
INSTRUCTION MANUAL
LED FLOOD LIGHT
ANGLE LIFE SPAN DF CRI
SPHERE
25000H
>0.9 >70
360°
SPHERE
25000H >0.9
>70
360°
SPHERE
>70
25000H >0.9
360°
SPHERE
25000H
>0.9 >70
360°
INPUT OPERATION
VOLTAGE TEMPERATURE
AC: 220-240V
-20 to +45°C 164.5x153x34mm
50Hz
AC: 220-240V
-20 to +45°C 183.5x169x34mm
50Hz
AC: 220-240V
253.5x242.5x40mm
-20 to +45°C
50Hz
AC: 220-240V
402.5x349.5x44mm
-20 to +45°C
50Hz
SUPER BRIGHT
LM/WATT EFFICIENCY
SPHERE
360°
STAYS BRIGHT
MAX
N.W
DIMENSION MOUNTING
(KGS)
HEIGHT
0.41 <5M
0.56 <5M
1.1 <5M
2.8 <5M
Caution, risk of electric shock
185
+
PROJECTED WIRE
AREA (mm ) LENGTH
2
25168.5 150mm
31011.5 150mm
61473.75 1M
140673.75 1M
