UltraLux Water Machine Installation Manual page 18

Connecting the UltraLux Water Machine
When connecting each PEX Pipe, use maximum force to push the tubes into each
port in the back of the Water Machine.
A
3"
Cut a small section,
about 3 inches, off of
each of the PEX pipes.
• Connect the 3/8-in.
1
the Diverter Valve, into the Source Water Port of the
Machine.
• Connect the 1/4-in.
2
drain line, into the Drain Water Port of the Machine.
• Connect the 3/8-in. White PEX Pipe into the Filtered
3
Water Port of the Machine.
• Connect the 1/4-in.
4
Water Port of the Machine.
• Plug the Power Cord into the Power Supply Port. (do
5
not plug the other end into your power outlet yet,
wait for further steps)
To begin connecting your Water Machine to your
sink, follow steps A-C to save space and prevent
leaks.
Although optional, these steps are recommended.
B
Connect the Union Elbow
Quick Connect pieces to
each of the correct pipes
1/4 inch = Red
3/8 inch = White
White PEX Pipe, coming out of
Red PEX Pipe, coming out of the
Yellow PEX Pipe into the UltraLux
INSTALLING THE ULTRALUX WATER MACHINE
C
Connect the smaller
section that was cut off
into the other end of the
elbow, making an 'L'
& Yellow
shape.
1
3"
5
4
3
2
17
