Installation of the UltraLux Water Machine

Now that the Faucet, Drain Process, and Source Water have been set up, it's time to
properly install the UltraLux Water Machine.
• Begin by removing all 4 Quick Connect Port Plugs from the back of the UltraLux Water
1
Machine by using Quick Connect Release Tool. Do so by depressing the colored collars,
ensuring they are depressed all of the way before gently pulling out the Plugs. It is normal
for some water to dribble out in this process.
WARNING: Excessive force can break the seal and cause the Machine to leak. The
breaking of these ports on the Water Machine are not covered under warranty.
NOTE: Save all 4 of these Port Plugs and Quick Connect Release Tool in a bag and tape them to
the back of your Machine for safe keeping. (we suggest placing them in the zip bag containing
the replacement port parts).
• Next, place your UltraLux Water Machine on the edge of your cupboard, or someplace
2
where you can easily access and replace the filters. Measure each of the White, Red, and
Yellow tubes, to ensure they reach the Machine in this position beneath the sink.
3
• If you measure the tubes and find an excessive amount, you can cut the tube with the
included PVC cutter, using caution as they are sharp. The cut should be extremely precise
and straight to prevent leaking.
16
PEX Pipe
INSTALLING THE ULTRALUX WATER MACHINE
Note: You may need to apply significant preassure to the
collar to depress it suffiently before removing the plug.
Perfect Straight Cut
