Anywhere along the Red Drain Pipe, use the Pipe Cutter to cut the tube and insert each end into
the Quick Connect Check Valve. Ensure the arrow is pointing towards the drain.
FInished image of Drain Clamp Assembly as described above.
14
PEX Pipe
Straight Cut
Push the 1/4-in. Red PEX Pipe from the Drain
Water Port into the 1/4-in. Quick Connect end
of the Drain Clamp. Gently tug on the end of
the Red Pipe to ensure it's properly connected.
Drain
DRAIN SET UP OPTION 1
