- Page 1 WATER MACHINE™ USER MANUAL...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Meet the UltraLux Water Machine ............pg 4 What Sets the Water Machine Apart ..........pg 5 Powerful Health Benefits of Hydrogen ..........pg 6 How to Use ..................pg 8 Machine Display Functions ..............pg 10 Faucet Display Functions .............. -
Page 4: Meet The Ultralux Water Machine
Many water companies claim to provide the cleanest, purest water, yet nothing compares to the robust Reverse Osmosis (RO) and UV-C light filtra- tion technology of the Water Machine. It goes beyond filtration by not only removing contaminates, but also enriching the purified water with the power- ful benefits of molecular hydrogen. -
Page 5: What Sets The Water Machine Apart
• Hydrogen Enhancement: In addition to the powerful multi-filtration sys- tem, the UltraLux Water Machine goes one step further by enriching the water with molecular hydrogen. Acting as a smart antioxidant, hydrogen fights off diseases, inflammation, and improves overall cellular health. -
Page 6: Powerful Health Benefits Of Hydrogen
POWERFUL HEALTH BENEFITS OF HYDROGEN Hydrogen has been proven to act as a smart antioxidant, fighting off free radi- cals in the body that cause damage to DNA and trigger diseases. Additionally, 1,200+ clinical and human studies, molecular hydrogen has been shown to: •... -
Page 8: How To Use
The Faucet display will light up and the “UL” will illuminate white, located on the right side of the Faucet display. Note - When UltraLux Water is dispensed, the Water Machine “wakes up”. It may stay on for a few minutes before automatically shutting off. - Page 9 Machine whatsoever. Re-configuring your faucet to accommodate this is not necessary and can be left as is. The sure way to know which water you are getting from your Water Machine is by looking at the clear chamber at the top of the unit. When that illuminates and bubbles rise in the water, then that mode is dispensing UltraLux Water.
-
Page 10: Machine Display Functions
MACHINE DISPLAY FUNCTIONS On the UltraLux Water Machine front display, notice the illuminated letters and buttons. Each have a specific function. • RO Indicator: The white indicator light is “on” • Flush Button: Will flash after pressing the Flush when the Reverse Osmosis Filter is in use (when button to begin a 30-minute flush cycle of the Water dispensing UltraLux Water). - Page 11 CF Indicator Select Button RO Indicator Reset Button Flush Button Select Reset Flush Input TDS Output TDS InletTDS OutputTDS Fault Error UV Sanitation Indicator Error Indicator Hydrogen Indicator Serial Number: Located above the bar code sticker on the back of the Machine.
-
Page 12: Faucet Display Functions
• UL: It will illuminate when the multi-filtered UltraLux Water is being dispensed. • TDS: Similar to the Water Machine display, the number of output Total Dissolved Solids (TDS) will show on the faucet display. (this syncs every 3-5 seconds) -
Page 13: Filter Information
FILTER INFORMATION FUNCTION & LIFETIME OF FILTERS Stage Filter Cartridge Filter Composition Function Lifespan* 1-Year Polypropylene (PP) Filtration accuracy Up to 12 Composite Shell & Activated of 5 μm. Removes months Filter (CF) Carbon Block Filter coarser particles, suspended and organic matter, peculiar smell, color, and some heavy... -
Page 15: Ultralux Filters
ULTRALUX FILTERS FILTER REPLACEMENT REMINDER The UltraLux Water Machine is equipped with a Filter Replacement Reminder. The CF and RO indicators on the front display of the Machine will display the follow codes: • Solid White: Default is “on” and everything is normal. It indicates less than 80% of the filter life has been used. -
Page 16: How To Replace Your Filter
Next, unplug the black power cable from either, the back of the Machine or the plug in the wall power outlet. Pull the Water Machine out from under the sink to better access the Filter Cartridge. Turn the selected Filter Cartridge counterclockwise for 90°... - Page 17 Replace the desired Filter Cartridge with a new one, adjusting it into the Water Machine until it is securely seated. Then turn the new Filter Cartridge clockwise to lock into place. Return the Water Machine to its associated spot underneath the sink. Slowly open the Di- verter Valve and plug back in the power cord.
- Page 18 Initiate a longer 30-minute Flush Cycle by pressing the Flush button on the display panel. *If all steps are completed and the Filter light continues to flash, signaling that it needs to be replaced, repeat step 8 once more. Scan this QR code to access the tutorial on Youtube!
-
Page 19: Troubleshooting
TROUBLESHOOTING In the event of any of these issues regarding the UltraLux Water Ma- chine, follow these solutions to troubleshoot these possible issues. Issue Possible Cause(s) Solution E1 illuminates on the Faucet display Water ran too long; or a minor... - Page 20 Diverter Valve was turned off; Ensure all Diverter and Shut Off or the Filters are not seated Valves are open. Take Filters out, properly in the Water Machine. then place them back into the Water Machine, ensuring they are properly locked into place.
-
Page 21: General Precautions
The UltraLux Water Machine should only be used with source water temperatures of 5 45 ° C (41-113° F). If you live in cold climate, do not install the Water Machine to outdoor areas. To prevent complications in the Water Machine flow rate, avoid direct sunlight on the Machine and drops in temperature. -
Page 22: Product Specifications
PRODUCT SPECIFICATIONS Product Name UltraLux Water Machine™ Water Produced Reverse Osmosis & Hydrogen-Enriched Water (UltraLux Water) Water Filtered Through the Activated Carbon Composite Filter (Filtered Water) Product Dimensions 14 ½ x 6 ¼ x 17 in. Product Weight 21 lbs. 11 oz. -
Page 23: Warranty
Whether or not the item is covered under warranty is under full discretion of UltraLux Health. If the item is covered, a replacement unit will be shipped to the customer at no extra cost. This warranty covers labor, defective parts, and the shipping of the replacement product to the customer. - Page 24 USER HEALTH GUIDE...
-
Page 25: Ultralux User Health Guide
The UltraLux Water Machine is the ultimate filtration system that goes above and beyond, so you can experience clean, hydrating water like never before! This Health Guide will assist you in understanding the benefits of UltraLux Water and customizing your intake, so you can experience true progress in your wellness journey. - Page 26 If you are searching for clean, safe, and hydrating drinking water, then UltraLux Water from the Water Machine is right for you. The Water Machine combines the power of a Tankless Reverse Osmosis (RO) Membrane Filter, UV-C Sanitation, and Molecular Hydrogen to effectively remove all contaminants.
- Page 27 UltraLux Water to make your ice cubes as the water is still extremely pure even after the hydrogen gas escapes! You may add electrolytes, powder packs, or flavoring to the water and they will not have a significant impact on the added hydrogen gas.
-
Page 28: Power Of Hydrogen Water
Alzheimer’s Disease • Heart failure/disease • Ocular diseases The UltraLux Water Machine is IHSA Certified to produce up to 1.8ppm of molecular hydro- REGULAR WATER gen. This is well above the therapeutic grade. You may find the certification on ultralux- health.com and more info on the testing on... -
Page 29: Studies On Hydrogen Water
Studies on Hydrogen Water In a study monitoring the hydrogen water intake in patients, they found that hy- drogen water possessed an ability to cross the blood-brain barrier, offering high potential to reduce oxidative stress in the brain. A study observed two groups of volunteers, to note the significance hydrogen-en- hanced water had on endurance. -
Page 30: Frequently Asked Questions & Contact Assistance
Can I cook with my hydrogen water? Yes, you can cook with UltraLux Water, however, the hydrogen will not stay in the water during cooking but you will have purified RO water to cook with. - Page 31 CONTACT FOR ASSISTANCE Now that you know exactly how to operate and use your UltraLux Water Machine, it’ s time to take full advantage of the amazing benefits!
- Page 32 V 5.0...
Need help?
Do you have a question about the WATER MACHINE and is the answer not in the manual?
Questions and answers
Inserted new filter, machine leaves, can't get filter out to start over.
To remove a stuck filter from an UltraLux Water Machine, unscrew the filter from the top of the machine and lift it out. If it is stuck, ensure the machine is on the edge of a cupboard or in a position where you can easily access and apply enough force. Use caution and pull straight to avoid damage.
This answer is automatically generated
After installing the machine and plugging it in, the initial automatic flush is taking longer than 30 seconds. It was still running at the 3 minute mark. I unplugged it. There are no leaks.
The initial automatic flush of the UltraLux WATER MACHINE should only take approximately 30 seconds. If it is taking longer than 3 minutes, the most likely cause is a problem such as low source water pressure, poor water quality, or a clogged filter, all of which can slow the flow rate and extend the flush time.
This answer is automatically generated
do you change both filters at the same time
No. The carbon composite filter (CBPA) should be replaced every 1 year or after 2000 gallons, while the RO membrane filter (ROCB) should be replaced every 2 years or after 1000 gallons.
This answer is automatically generated
When does the hydrogen light indicator comes on? During flush must the H indicator come on?
