13.2 System impedance overview

NOTICE
In accordance with EN / IEC 61000-3-11
(see table below), the switchgear and pump with a
motor power of ... kW (column 1) are provided for
operation on a mains power supply with a system
impedance of Zmax at the house connection of
max. ... ohm (column 2) for a maximum number
of ... switch connections (column 3).
If the mains impedance and the number of switch-
ing operations per hour are greater than the values
3~400/380 V
2-pole
Direct starting
NOTICE
The maximum number of switching operations per
hour specified in the table for each power is
determined by the pump motor and must not be
exceeded (adjust parameterisation of the control-
ler accordingly; see follow-up times, for example).
