- Page 1 INSTALLATION AND OPERATION MANUAL HD -2 80...
-
Page 2: Table Of Contents
Table of contents 1. Safety Instructions and Notes…....................... 2. General Descriptions................……………………………... 3. Supplied Items..................……………………………... 4. Part names…………………………….…...........…………………………... 5. Installation Instructions..................……………………... 6. Setup Menu ……………................…………………………... 7. Specifications ………………………………………………..............8. Dimensional Drawings ……………………………………………............ -
Page 3: Power Source
WARNING To prevent fire or shock hazard, do not expose the unit to rain or moisture. The symbol is intended to alert the user to the presence of important operating and maintenance(servicing) instructions in the literature accompanying the unit. The symbol is intended to alert the user to the presence of uninsulated "dangerous voltage"... -
Page 4: Safety Instructions And Notes
1. Safety Instructions and Notes • Please read this safety and operating instructions before putting the camera into operation. • Keep the manual in a safe place for later reference. • Pay attention to safety when laying the connection cable and observe that the cable is not subjected to heavy loads, kinks or damage and no moisture can get in. -
Page 5: Supplied Items
• Sense Up(~x8) / AGC(0~20) / 3D Noise Reduction • Scale down the image to 720p without loss of field of view • SMART MOTION ZOOM(Automatic Zoom IN/OUT when motion is detected) • Pointing Zoom which enables the flexible zooming at any area. •... -
Page 6: Part Names
① ② ③ ④ ⑤ 4. Part Names 4.1 Front view ⓓ ⓔ ⓐ ⓕ ⓖ ⓑ ⓗ ⓒ ⓘ ⓖ Sunshield panel ⓐ Fixing screw for Sunshield(x2) ⓓ Bracket Foot ⓗ Bracket Lock ⓑ IR LED ⓔ Foot mount Hole(x4) ⓘ... -
Page 7: Installation Instructions
4.3 Easy Bracket ⓛ ⓛ Peg for Easy Bracket Hook(ⓛ) ⓜ Wall Mount hole(x4) ⓝ Bracket foot fixing hole(x4) ⓜ ⓝ CAUTION Easy Bracket can not be installed on the ceiling. When it is installed on the wall, ⓛPeg for Easy bracket Hook must be placed upwardly. 5. - Page 8 5.1 Mounting the camera on wall 5.1.1 Without using an Easy Bracket. 1) Drill the holes on wall or ceiling using a supplied template. 2) Insert the ②anchors to the drilled holes 3) Match ⓔFoot mount Hole(x4) to the drilled position 4) Fix the bracket by using ③Wall fixing screws 5.1.2 With using an Easy Bracket.
- Page 9 5.2. Power Supply Connections Camera can work with either 24AC or 12VDC, dual voltage power. It is strongly required the polarity-matched connection for 12VDC supply, otherwise IR LEDs will not operate at night. Primary and secondary grounds are completely isolated to avoid the possible ground- loop problems.
- Page 10 5.3 Limit of pan and tilt 1. Pan limit Pan is limited to +/- 90°. 2. Tilt limit Tilt is limited to 0°(2°) min ~ 90° max. for wall(ceiling) installation respectively with reference to the ceiling when the inclination of camera module is 0°, that is, the image is aligned horizontally.
-
Page 11: Setup Menu
6. Setup Menu 6.1 In the menu Setup menu can be accessed and controlled by OSD control joy stick on the side of camera. Five commands are available with the joy stick. Picture of OSD may differ by the models. SYMBOL descriptions for joystick operation;... - Page 12 6.2 MAIN menu Press ☟ to enter the setup menu for about 1 second. ↵ MENU V3.07 ↵ 1. ZOOM/FOCUS 2. EXPOSURE 3. SCENE ENHANCE NORMAL 4. 3D-NR ↵ 5. DAY/NIGHT EXT↵ ↵ 6. PICT ADJUST ↵ 7. SPECIAL 8. SYSTEM 9.
- Page 13 MAIN Default Descriptions NORMAL – Optimized for the normal indoor and outdoor in the good lighting condition. WDR – Improves the visibility for the high bright area and the dark area by the double captures of image with LONG and SHORT exposures. With WDR ON, the frame rate becomes half by the double captures.
- Page 14 6.3 ZOOM/FOCUS ZOOM / FOCUS FOCUS MODE ZOOM PUSH D-ZOOM LENS REFRESH LENS INIT. RETURN RET↵ ZOOM / Default Descriptions FOCUS ZOOM PUSH, AUTO and MANUAL modes are available for focusing. ZOOM PUSH – Focusing is activated only when zoom in/out is working. FOCUS ZOOM AUTO –...
- Page 15 6.4 EXPOSURE EXPOSURE MODE AUTO BRIGHTNESS |:::::::|::::::| 10 SENS-UP OFF↵ |::::::::|:::::| 12 MOTION DEBLUR RETURN RET↵ EXPOSURE Default Descriptions Can set EXPOSURE MODE to AUTO, IRIS Priority, SHUT. Priority, MANUAL and Flickerless. AUTO – Optimizes the video level by controlling the iris and the shutter speed automatically.
- Page 16 6.5 PICT ADJUST PICTURE WHITE BAL SHARPNESS |:::::|::::::| 10 COLOR GAIN |:::::|::::::| 10 GAMMA RETURN RET↵ PICTURE Default Descriptions ATW, ATWext, ONE PUSH and MANUAL are available for the white balance modes. ATW – White balance is continuously working along with the color temperature changes in the range of 2,000K~8,500K.
- Page 17 6.6 SPECIAL SPECIAL ↵ MIRROR/FLIP PRIVACY MOTION ↵ PIXEL DEFECT ↵ TITLE SET DISPLAY ↵ DEFOG POINTING ZOOM RETURN RET↵ SPECIAL Default Descriptions Reverses the video left and right and/or up and down by MIRROR/FLIP. OFF - Normal display without mirroring or flipping Hor.
- Page 18 MOTION can detect the changes in the motion window and displays the results in blocks and/or a text message. SENSITIVITY – Adjusts the detection sensitivity for motion. High value increases the sensitivity to detect the small motion easily. Too low sensitivity will cause the erratic detection by the tree leaves or the light level changes.
- Page 19 Enables or disables to display the OSD. ID – ON enables to display the camera ID defined by SYSTEM>COMM. SETUP>CAM ID. TITLE – ON enables to display the camera title(name) set by SPECIAL> TITLE SET. DISPLAY ZOOM RATIO – ON enables to display the zoom ratio on the bottom right corner.
- Page 20 6.6.1 SMART MOTION ZOOM SMART MOTION ZOOM crops and enlarges the certain area defined by a yellow window to the full sized image when the motion is detected in the black window. SMART MOTION ZOOM window can be re-sized by adjusting D-ZOOM RATIO and moved by H-POINTER and V-POINTER.
- Page 21 6.6.2 POINTING ZOOM This camera has a very useful and powerful feature, POINTING ZOOM, which can zoom in/out any area. UNLIKE the conventional zoom which can zoom in/out the center area of image only, by the flexible zoom location and area, POINTING ZOOM differentiate its usefulness from others. That is, a conventional camera installed on the corner of ceiling can zoom the center of the floor in a room and result in losing the image of door on the side wall.
- Page 22 6.7 SYSTEM SYSTEM TV SYSTEM US(60HZ) ↵ RESOLUTION 1080P COMM. SETUP LANGUAGE ☟ FACTORY DEFAULT RETURN RET↵ SYSTEM Default Descriptions Selects HDTV standards for US(60HZ) or EU(50HZ). TV SYSTEM By this selection, 2 analog video output switches to NTSC or PAL accordingly.
-
Page 23: Specifications
. Specifications 207508 HDB-2180Z03IR Imaging Sensor Sony Exmor 1 / 2.9” Progressive Scan CMOS Sensor Effective Pixels 1,936(H) x 1,097(V) Min. Illumination 0.0008 Lux (@AGC MAX, DSS x2) Output Video Resolution 1920x1080(30p/25p), 1280x720(30p/25p) TV system EU(50Hz)(switchable to US(60Hz)) Sync. System Internal Format 16:9 Video format for most popular commercial HDTV monitors HD-SDI Video Output 1.485Gbps HD-SDI (SMPTE 292M), Non-Compression... -
Page 24: Dimensional Drawings
● Design and specifications are subject to change for product improvements without prior notice. 8. Dimensional Drawings (Unit: mm)
