Installation
Flux Power S8
Installation Guide
WARNING – Risk of Fire – No User Serviceable Parts

Advertisement

loading
Need help?

Need help?

Do you have a question about the S8 and is the answer not in the manual?

Questions and answers

Related Manuals for FLUX POWER S8

Summary of Contents for FLUX POWER S8

  • Page 1 Installation Flux Power S8 Installation Guide WARNING – Risk of Fire – No User Serviceable Parts...
  • Page 2 Installation 1 Deliverables Battery Mounting Hardware (varying components if applicable) QTY: 1 Qty: 1...

  • Page 3: Battery Installation

    Installation 2 Battery Installation 2.1 Lifting Points The battery has two slots on the side to be used as lifting points. A set of hooks with proper chains or lifting straps is recommended.
  • Page 4 Installation 2.2 Installing Battery into Truck 2.2.1 Drop-in Lift and align the battery into the truck’s battery compartment by positioning the battery in the center of the battery compartment.
  • Page 5 Installation 2.3 Mounting Hardware The battery may come with some mounting hardware to secure the battery to the inside of the battery compartment. Mounting hardware is shipped with the battery in an accompanying plastic bag. The bag may be stored in the cord box during battery shipment.

  • Page 6: Operation

    Installation 2.4 Inserting Wedges Blue wedges are provided for trucks where the battery compartment is much larger than the battery. If provided, insert the blue wedges tip first downwards into the front face of the battery compartment to secure the battery into the battery compartment.
  • Page 7 Installation 3.1.2 Circuit Breaker The battery is turned ON by the circuit breaker. The circuit breaker is located inside the cord box which is underneath the top face flap. The circuit breaker is composed of a red tab that can be pressed to turn the battery OFF and a second yellow tab that can be pressed counterclockwise to turn the battery ON.
  • Page 8 Flux Power, Inc. All other brands and product names are trademarks or registered trademarks of their respective owners. This information is intended for the use of Flux Power customers only. Any other use without the express written consent of Flux Power, Inc. is strictly prohibited...
