Haws RIVIVE HYDRATION STATION 2000HSSM Installation, Operation & Maintenance Instructions Manual

Surface mount architectural bottle filler

Advertisement

Quick Links

1455 Kleppe Lane Sparks, NV 89431-6467 (775) 359-4712 Fax (775) 359-7424
E-mail:
ARCHITECTURAL BOTTLE FILLER
NOTE TO INSTALLER: Please leave this information with the Maintenance Department.
HAWS warrants that all of its products are guaranteed against defective material or poor workmanship for
a period of one year from the date of shipment. The foregoing notwithstanding, HAWS warrants certain
specific products or components thereof for an adjusted period. A list of these excepted products and
components
and
a
www.hawsco.com/warranty. HAWS' liability under this warranty shall be discharged by furnishing without
charge F.O.B. HAWS factory any goods, or part thereof, which shall appear to the Company upon
inspection to be of defective material or not of first-class workmanship, provided that a claim is made in
writing to Company within a reasonable period after receipt of the product. Where claims for defects are
made, the defective part or parts shall be delivered to the Company, prepaid, for inspection. HAWS shall
not be liable for the cost of repairs, alterations or replacements, or the labor required to implement them,
or for any expense connected therewith made by the owner or owner's agents, except upon written
authority from HAWS. HAWS shall not be liable for any damages caused by defective materials or poor
workmanship, except for replacements, as provided above. Buyer agrees that HAWS has made no other
warranties either express or implied in addition to those above stated, except that of title with respect to
any of the products or equipment sold hereunder and that HAWS shall not be liable for general, special,
incidental, or consequential damages claimed to arise under the contract of sale.
Equipment manufactured by HAWS is warranted to function if installation and maintenance instructions
provided are adhered to. The units also must be used for the purpose for which they were intended. Any
HAWS emergency equipment is intended to supplement first-aid treatment. Due to widely varying
conditions, HAWS cannot guarantee that the use of this emergency equipment will prevent serious injury
or the aggravation of existing or prior injuries.
EXCEPT AS EXPRESSLY STATED HEREIN, HAWS HEREBY DISCLAIMS ALL WARRANTIES,
WHETHER EXPRESS OR IMPLIED, ARISING BY LAW OR OTHERWISE, INCLUDING WITHOUT
LIMITATION, ANY IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. THIS WARRANTY MAY NOT BE MODIFIED OR EXTENDED WITHOUT THE
WRITTEN CONSENT OF HAWS. REMEDIES AND REPLACEMENTS STATED HEREIN ARE
EXCLUSIVE. IN NO EVENT SHALL HAWS BE LIABLE FOR ANY SPECIAL, PUNITIVE,
CONSEQUENTIAL OR INCIDENTAL DAMAGES TO ANY PERSON INCLUDING BUT NOT LIMITED
TO DAMAGES FOR LOSS OF USE OR PROFITS, SUBSTITUTE PRODUCTS OR COSTS, PROPERTY
DAMAGE, OR OTHER MONETARY LOSS.
SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS
MODEL PLEASE CALL:
TECHNICAL SUPPORT:
FOR CUSTOMER SERVICE:
7/24 2000HSSM Surface Mount Architectural Bottle Filler
haws@hawsco.com
SURFACE MOUNT
MODEL 2000HSSM
LIMITED WARRANTY
description
of
their
respective
1-800-766-5612
1-888-640-4297
 website:
www.hawsco.com
warranty
terms
No. 0510002226 (1)
may
be
found
here:
Page 1 of 16

Advertisement

loading
Need help?

Need help?

Do you have a question about the RIVIVE HYDRATION STATION 2000HSSM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Haws RIVIVE HYDRATION STATION 2000HSSM

  • Page 1 HAWS shall not be liable for general, special, incidental, or consequential damages claimed to arise under the contract of sale.
  • Page 2: Safety Precautions

    SAFETY PRECAUTIONS CAUTION: Disconnect electrical power to outlet before installing or servicing. NOTICE: A. The electrical receptacle must have code-approved ground-fault circuit interrupter (GFCI) protection for personnel. B. Care should be taken not to damage electrical wires during installation. C. Installation must conform to all applicable codes and standards. D.
  • Page 3: Installation

    C. OPTIONAL PROGRAMMING INSTRUCTIONS To enter programming mode, press and hold the Haws logo button on the bottle filler display until the up/down arrow keys and “select” appear. Programming mode enters at the top-level menu. In general, the up/down arrows and select keys work as follows.
  • Page 4 Bottle Filler Programming Table Top-Level Arrows (cycle through…) Select Default Menu Backlight 100%, 75%, 50%, 25%, Percentage Value - programs brightness 100% Cancel – returns to main menu Cancel Sensor Range (rng) from 1 to 10, Range 1 to 10 - programs range Rng 5 Cancel –...
  • Page 5: Maintenance

    Fuse Required 5mm X 20mm, 10A, 250V, SLOW BLOW / TIME DELAY, GLASS REF HAWS PN: 0210001120 Replace main board cover, reconnect water lines and electrical wire harnesses, replace alcove mounting screws & molded corner covers, turn on water, reconnect power.
  • Page 6: General Operation

    All DIP switches are configured from the factory in the OFF (down) position. See Figure 4. DIP Switch #1 – Switch to ON to Disable Haws logo Figure 4: DIP Switch on programming button, to prevent inadvertent user access Backside of Display DIP Switch #2 –...
  • Page 7: Troubleshooting

    H. TROUBLESHOOTING TROUBLESHOOTING Note: If the suggested items in the checklist fail to solve the problem, contact Haws Technical Support at 1-800-766-5612. Please have available the model number, serial number, detailed description of the problem, bottle count, and specific error messages (if applicable).
  • Page 8 © 2024 Haws ® HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation. 1455 Kleppe Lane, Sparks, Nevada 89431 – 800.766.5612 – www.hawsco.com 7/24 2000HSSM Surface Mount Architectural Bottle Filler Page 8 of 16...
  • Page 9 APPROVED: DATE: SCALE: DRAWING TYPE: PARTS BREAKDOWN SIZE: A SHEET 1 OF 1 © 2024 Haws Corporation - All Rights Reserved. HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation. PAGE 9 OF 16...
  • Page 10 DATE: CHK'D.: REVISION 08/16/23 APPROVED: DATE: SCALE: 1:20 DRAWING TYPE: INSTALLATION SIZE: A SHEET 1 OF 7 © 2024 Haws Corporation - All Rights Reserved. HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation.
  • Page 11 DATE: CHK'D.: REVISION 08/16/23 APPROVED: DATE: SCALE: 1:20 DRAWING TYPE: INSTALLATION SIZE: A SHEET 2 OF 7 © 2024 Haws Corporation - All Rights Reserved. HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation.
  • Page 12 DATE: CHK'D.: REVISION 08/16/23 APPROVED: DATE: SCALE: 1:15 DRAWING TYPE: INSTALLATION SIZE: A SHEET 3 OF 7 © 2024 Haws Corporation - All Rights Reserved. HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation.
  • Page 13 (DRAIN AND WATER SUPPLY COMPONENTS HIDDEN FOR CLARITY) REVISION 08/16/23 APPROVED: DATE: SCALE: 1:15 DRAWING TYPE: INSTALLATION SIZE: A SHEET 4 OF 7 © 2024 Haws Corporation - All Rights Reserved. HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation.
  • Page 14 1-1/2" NUT (NOT SUPPLIED) APPROVED: DATE: SCALE: 1:15 DRAWING TYPE: INSTALLATION SIZE: A SHEET 5 OF 7 © 2024 Haws Corporation - All Rights Reserved. HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation.
  • Page 15 CHK'D.: CONNECTION REVISION 08/16/23 APPROVED: DATE: SCALE: 1:15 DRAWING TYPE: INSTALLATION SIZE: A SHEET 6 OF 7 © 2024 Haws Corporation - All Rights Reserved. HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation.
  • Page 16: Connect Power Cord

    DATE: CHK'D.: REVISION 08/16/23 APPROVED: DATE: SCALE: 1:15 DRAWING TYPE: INSTALLATION SIZE: A SHEET 7 OF 7 © 2024 Haws Corporation - All Rights Reserved. HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation.

This manual is also suitable for:

Rivive hydration station 2000hs
