Haws RIVIVE HYDRATION STATION 2000HSA.8 Installation, Operation & Maintenance Instructions Manual

Haws RIVIVE HYDRATION STATION 2000HSA.8 Installation, Operation & Maintenance Instructions Manual

Single and no fountain architectural bottle filler, chilled

Advertisement

Quick Links

1455 Kleppe Lane Sparks, NV 89431-6467 (775) 359-4712 Fax (775) 359-7424
E-mail:
Model 2000HSA.8, 1001HSA.8, 1107HSA.8, AND 1109HSA.8
SINGLE AND NO FOUNTAIN ARCHITECTURAL BOTTLE FILLER, CHILLED
NOTE TO INSTALLER: Please leave this information with the Maintenance Department.
HAWS warrants that all of its products are guaranteed against defective material or poor workmanship for
a period of one year from the date of shipment. The foregoing notwithstanding, HAWS warrants certain
specific products or components thereof for an adjusted period. A list of these excepted products and
components
and
a
www.hawsco.com/warranty. HAWS' liability under this warranty shall be discharged by furnishing without
charge F.O.B. HAWS factory any goods, or part thereof, which shall appear to the Company upon
inspection to be of defective material or not of first-class workmanship, provided that a claim is made in
writing to Company within a reasonable period after receipt of the product. Where claims for defects are
made, the defective part or parts shall be delivered to the Company, prepaid, for inspection. HAWS shall
not be liable for the cost of repairs, alterations or replacements, or the labor required to implement them,
or for any expense connected therewith made by the owner or owner's agents, except upon written
authority from HAWS. HAWS shall not be liable for any damages caused by defective materials or poor
workmanship, except for replacements, as provided above. Buyer agrees that HAWS has made no other
warranties either express or implied in addition to those above stated, except that of title with respect to
any of the products or equipment sold hereunder and that HAWS shall not be liable for general, special,
incidental, or consequential damages claimed to arise under the contract of sale.
Equipment manufactured by HAWS is warranted to function if installation and maintenance instructions
provided are adhered to. The units also must be used for the purpose for which they were intended. Any
HAWS emergency equipment is intended to supplement first-aid treatment. Due to widely varying
conditions, HAWS cannot guarantee that the use of this emergency equipment will prevent serious injury
or the aggravation of existing or prior injuries.
EXCEPT AS EXPRESSLY STATED HEREIN, HAWS HEREBY DISCLAIMS ALL WARRANTIES,
WHETHER EXPRESS OR IMPLIED, ARISING BY LAW OR OTHERWISE, INCLUDING WITHOUT
LIMITATION, ANY IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. THIS WARRANTY MAY NOT BE MODIFIED OR EXTENDED WITHOUT THE
WRITTEN CONSENT OF HAWS. REMEDIES AND REPLACEMENTS STATED HEREIN ARE
EXCLUSIVE. IN NO EVENT SHALL HAWS BE LIABLE FOR ANY SPECIAL, PUNITIVE,
CONSEQUENTIAL OR INCIDENTAL DAMAGES TO ANY PERSON INCLUDING BUT NOT LIMITED
TO DAMAGES FOR LOSS OF USE OR PROFITS, SUBSTITUTE PRODUCTS OR COSTS, PROPERTY
DAMAGE, OR OTHER MONETARY LOSS.
SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS
MODEL PLEASE CALL:
TECHNICAL SUPPORT:
FOR CUSTOMER SERVICE:
07/02/2024
Models 2000HSA.8, 1001HSA.8, 1107HSA.8, & 1109HSA.8
haws@hawsco.com
LIMITED WARRANTY
description
of
their
respective
1-800-766-5612
1-888-640-4297
 website:
www.hawsco.com
warranty
terms
No. 0510002218 (1)
may
be
found
here:
Page 1 of 22

Advertisement

loading
Need help?

Need help?

Do you have a question about the RIVIVE HYDRATION STATION 2000HSA.8 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Haws RIVIVE HYDRATION STATION 2000HSA.8

  • Page 1 HAWS shall not be liable for general, special, incidental, or consequential damages claimed to arise under the contract of sale.
  • Page 2: Safety Precautions

    SAFETY PRECAUTIONS CAUTION: Disconnect electrical power to unit before installing or servicing. Note that some models have more than one connection to the electrical supply. NOTICE: A. The electrical connection must have code-approved ground-fault circuit interrupter (GFCI) protection for personnel. B.
  • Page 3: Installation Procedure

    C. OPTIONAL PROGRAMMING INSTRUCTIONS: To enter programming mode, press the Haws logo on the display at the front of the unit (Figure 1) until the up/down arrow keys and “select” appear on the bottle filler display. Programming mode enters at the top-level menu. In general, the up/down arrows and select keys work as follows;...
  • Page 4: Maintenance

    Programming Mode Table Top-Level Arrows (cycle through…) Select Default Menu Backlight 100%, 75%, 50%, 25%, Percentage Value - programs brightness 100% Cancel – returns to main menu Cancel Sensor Range (rng) from 1 to 10, Range 1 to 10 - programs range Rng 5 Cancel –...
  • Page 5: Fuse Replacement

    Fuse Required 5mm X 20mm, 10A, 250V, SLOW BLOW / TIME DELAY, GLASS REF HAWS PN: 0210001120 Replace main board cover, reconnect water lines and electrical wire harnesses, replace alcove mounting screws & molded corner covers, reconnect power, turn on water.
  • Page 6 All DIP switches are configured from the factory in the OFF (down) position. See Figure 4. DIP Switch #1 – Switch to ON to Disable Haws logo programming button, to prevent inadvertent user access Figure 4: DIP Switch on DIP Switch #2 –...
  • Page 7: Troubleshooting

    H. TROUBLESHOOTING TROUBLESHOOTING Note: If the suggested items in the checklist fail to solve the problem, contact Haws Technical Support at 1-800-766-5612. Please have available the model number, serial number, detailed description of the problem, bottle count, and specific error messages (if applicable).
  • Page 8 ERROR CODE TABLE TROUBLESHOOTING Note: If the suggested items in the checklist fail to solve the problem, contact Haws Technical Support at 1-800-766-5612. Please have available the model number, serial number, detailed description of the problem, bottle count, and status of the indication lights.
  • Page 9 *For more information about Haws products, see our website: www.hawsco.com Corporation – All Rights Reserved ® © 2024 Haws HAWS ® and other trademarks used in these materials are the exclusive property of Haws Corporation. 07/02/2024 Models 2000HSA.8, 1001HSA.8, 1107HSA.8, & 1109HSA.8 Page 9 of 22...
  • Page 10 07/08/24 SCALE: 1:20 DRAWING TYPE: PARTS BREAKDOWN SIZE: A SHEET 1 OF 2 © 2024 Haws Corporation - All Rights Reserved. HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation. PAGE 10 OF 22...
  • Page 11 07/08/24 SCALE: 1:20 DRAWING TYPE: PARTS BREAKDOWN SIZE: A SHEET 2 OF 2 © 2024 Haws Corporation - All Rights Reserved. HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation. PAGE 11 OF 22...
  • Page 12 MODELS, CHILLED REVISION 12/15/22 APPROVED: DATE: 07/08/24 SCALE: 1:32 DRAWING TYPE: INSTALLATION SIZE: A SHEET 1 OF 11 © 2024 Haws Corporation - All Rights Reserved. HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation.
  • Page 13 MODELS, CHILLED REVISION 12/15/22 APPROVED: DATE: 07/08/24 SCALE: 1:20 DRAWING TYPE: INSTALLATION SIZE: A SHEET 2 OF 11 © 2024 Haws Corporation - All Rights Reserved. HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation.
  • Page 14 MODELS, CHILLED REVISION 12/15/22 APPROVED: DATE: 07/08/24 SCALE: 1:20 DRAWING TYPE: INSTALLATION SIZE: A SHEET 3 OF 11 © 2024 Haws Corporation - All Rights Reserved. HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation.
  • Page 15: Frame Installation

    MODELS, CHILLED REVISION 12/15/22 APPROVED: DATE: 07/08/24 SCALE: 1:20 DRAWING TYPE: INSTALLATION SIZE: A SHEET 4 OF 11 © 2024 Haws Corporation - All Rights Reserved. HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation.
  • Page 16: Rear View

    MODELS, CHILLED REVISION 12/15/22 APPROVED: DATE: 07/08/24 SCALE: 1:20 DRAWING TYPE: INSTALLATION SIZE: A SHEET 5 OF 11 © 2024 Haws Corporation - All Rights Reserved. HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation.
  • Page 17 MODELS, CHILLED REVISION 12/15/22 APPROVED: DATE: 07/08/24 SCALE: 1:14 DRAWING TYPE: INSTALLATION SIZE: A SHEET 6 OF 11 © 2024 Haws Corporation - All Rights Reserved. HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation.
  • Page 18 MODELS, CHILLED REVISION 12/15/22 APPROVED: DATE: 07/08/24 SCALE: 1:20 DRAWING TYPE: INSTALLATION SIZE: A SHEET 7 OF 11 © 2024 Haws Corporation - All Rights Reserved. HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation.
  • Page 19 MODELS, CHILLED REVISION 12/15/22 APPROVED: DATE: 07/08/24 SCALE: 1:20 DRAWING TYPE: INSTALLATION SIZE: A SHEET 8 OF 11 © 2024 Haws Corporation - All Rights Reserved. HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation.
  • Page 20: Front View

    MODELS, CHILLED REVISION 12/15/22 APPROVED: DATE: 07/08/24 SCALE: 1:12 DRAWING TYPE: INSTALLATION SIZE: A SHEET 9 OF 11 © 2024 Haws Corporation - All Rights Reserved. HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation.
  • Page 21: Water Supply Connection

    MODELS, CHILLED REVISION 12/15/22 APPROVED: DATE: 07/08/24 SCALE: 1:16 DRAWING TYPE: INSTALLATION SIZE: A SHEET 10 OF 11 © 2024 Haws Corporation - All Rights Reserved. HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation.
  • Page 22 MODELS, CHILLED REVISION 12/15/22 APPROVED: DATE: 07/08/24 SCALE: 1:12 DRAWING TYPE: INSTALLATION SIZE: A SHEET 11 OF 11 © 2024 Haws Corporation - All Rights Reserved. HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation.
