- Page 1 Sigen Hybrid (5.0, 6.0) SP User Manual (Australia) Version: 01 Release date: 2024-10-14 1 / 24...
-
Page 2: Copyright Notice
Therefore, description in this document is provided for reference purpose only and constitutes neither an offer nor an acceptance. Sigenergy Technology Co., Ltd. may change the information at any time without notice. -
Page 3: Table Of Contents
Contents 2.1 Product Model ..................................8 2.2 Appearance Introduction ............................9 2.3 Label Description ................................11 2.4 Supported Power Supply Methods for the Power Grid ..............12 2.5 Introduction to Typical Networking ......................... 13 5.1 LED Indicator State ............................... 18 5.2 mySigen App Query .............................. -
Page 4: Revision History
User Manual Revision History Version Date Description 2024.10.14 First official release. 4 / 24... - Page 5 User Manual Overview Introduction The focus of this document is to provide an overview of the Sigen Sigen Hybrid (5.0, 6.0) SP inverter, including product features, networking, system operation, maintenance, etc. Readers This document is suitable for product users and professionals Sign Definition The following signs may be used in the document to indicate security precautions or key information.
-
Page 6: Safety Precautions
User Manual Safety Precautions Basic Information Before installation, operation, and maintenance of the equipment, familiarize yourself with this document. The "Danger ", "Warning", "Caution" items described in this manual are only supplementary to all precautions. The Company shall not be liable for equipment damage or property loss caused by the following reasons: Failure to obtain approval from the national, regional power authority. -
Page 7: Safety Requirements
User Manual equipment is too high or too low). The equipment was stolen. The equipment is damaged after the warranty period. Safety Requirements Do not expose the device to high temperature or heat sources (such as sunlight, fire, or heaters) around the equipment for a long time. Do not clean or soak the equipment with water, alcohol, or oil to avoid ... -
Page 8: Product Model
Product Model No. Name Function specification code Sigen Hybrid Inverter Inverter; it can be used Sigen Hybrid 5.0 SP 5.0 kW Single Phase in conjunction with PV modules for pure PV applications or in combination with PV Sigen Hybrid modules and SigenStor Sigen Hybrid Inverter Sigen Hybrid 6.0 SP... -
Page 9: Appearance Introduction
User Manual 2.2 Appearance Introduction Appearance and Dimensions 9 / 24... -
Page 10: Port Introduction
User Manual Port Introduction Serial No. Name Marking Dc switch DC SWITCH Decorative cover strip light interface Antenna interface Cable interface RJ45 1/ RJ45 2 AC output interface Ground screw Communication interface Sigen CommMod interface DC input interface PV1+/PV2+/ PV1-/PV2- Switch button ON/OFF 10 / 24... -
Page 11: Label Description
User Manual 2.3 Label Description Symbols Definition Danger! High Voltage High voltage exists inside the equipment when powered on. Do not open the casing when the equipment is running. Any maintenance or servicing operations must be performed by trained and skilled electrical engineers. -
Page 12: Supported Power Supply Methods For The Power Grid
User Manual Supported Power Supply Methods for the Power Grid The grid supply methods supported by Sigen Hybrid include TN-S, TN-C, TN-C-S, and When TT is used as the power supply technique for the power grid, the voltage between N and PE is required to be <... -
Page 13: Introduction To Typical Networking
User Manual Introduction to Typical Networking Sigen Hybrid is designed for grid-connected photovoltaic systems on residential rooftops. The grid-connected system consists of photovoltaic strings, inverters, distribution panels, and other components. A. PV panel B. Sigen Hybrid C. Home loads D. AC distribution panel E. -
Page 14: Site Selection Requirements
User Manual Site Selection Requirements The equipment can be installed indoors and outdoors. Install the equipment in strict accordance with installation instructions given in this section and local laws and regulations. The warranty applies when the equipment has been installed properly for ... -
Page 15: Installation Position Requirements
User Manual Installation Position Requirements Do not tilt or overturn the equipment to ensure that it is installed horizontally. Do not install the equipment in places easily touched by children. Do not install the equipment in places with fire or damp. ... - Page 16 User Manual 16 / 24...
- Page 17 User Manual Equipment Installation and Wiring Only company authorized personnel should install and connect the equipment. For details, see Sigen Hybrid (5.0, 6.0) SP Installation Guide (Australia). Parts and accessories supplied with the packing box are personal assets of the owner and must be kept safe.
-
Page 18: Led Indicator State
User Manual System Operation 5.1 LED Indicator State Indicator Color State Description Always on The DC side is connected but not running. Always on The DC side is running. The DC side is not connected. Flash The DC side is faulty. Always on The inverter is faulty. -
Page 19: Mysigen App Query
User Manual 5.2 mySigen App Query The App can be downloaded in the following two ways. For details, see mySigen App User Manual. 19 / 24... -
Page 20: System Maintenance
User Manual System Maintenance 6.1 Routine Maintenance To ensure the long-term operating of the equipment, you are advised to perform routine maintenance according to this section. Inspection Inspection method Power off Maintenance content or not cycle System Regularly check whether the Once every cleaning decorative cover is covered and... -
Page 21: System Power-On/Power-Off
User Manual 6.2 System Power-on/Power-off High Voltage and Hazards: Wear personal protective equipment such as insulating gloves, insulating shoes, and safety hats while operating the equipment. Do not wear conductive accessories such as metal bracelets, rings, or necklaces. System power-off Power the equipment off in the App. -
Page 22: System Power-On
User Manual power off may lead to electric shock or burns. System power-on Turn DC SWITCH on the equipment to the ON position. 2. Turn on the switch connected to the equipment in the backup power distribution panel. 3. Power the equipment in the App. For details, see Step 1 in System power-off. 22 / 24... -
Page 23: Emergency Treatment
User Manual 6.3 Emergency Treatment Emergency Measures for Fire Please shut down the equipment or disconnect the main power switch when it is safe. If the fire is small, use carbon dioxide or ABC dry powder extinguisher to extinguish the fire. -
Page 24: Technical Parameter
User Manual Appendix 7.1 Technical Parameter Item Sigen Hybrid 5.0 SP Sigen Hybrid 6.0 SP Pollution degree PD2, PD3 Back feed current Inrush current 21.7 A 28.7 A Max. output 32.5 A 43.0 A overcurrent protection Max. output fault 65.0 A 86.0 A...
