INSTALLATION INSTRUCTIONS
BEFORE YOU BEGIN
Read these instructions completely
and carefully.
IMPORTANT-
instructions for local inspector s use.
IMPORTANT-
governing codes and ordianaces.
Note to Installer
instructions with the Consumer.
Note to Consumer
instructions for futrue reference.
-
Skill level
Installatio of this appliance
requires basic mechanical skills.
Completion time
We recommend that two people install
this product.
Proper installation is the responsibility
of the installer.
Product failure due to improper installation
is not covered under the Warranty.
You MUST use all supplied parts and use
proper installation procedures as described
in these instructions when installing this air
conditioner.
WINDOW REQUIREMENTS
Your air conditioner is designed to install in
standard double hung windows with opening
widths of 23 to 36 inches(584mm to 914mm) .
6000~8000Btu/h
Model
H
14 (356mm )
Save these
Observe all
-
Be sure to leave these
-
Keep these
-
Approximately 1 hour.
H
10000~12000Btu/h
15-1/2 (394mm)
Table 1
CAUTION
Do not, under any circumstances, cut or
remove the third (ground) prong from the
power cord.
Do not change the plug on the power cord
of the air conditioner.
Aluminum house wiring may present special
problems- consult a qualified electircian.
When handling unit, be careful to avoid cuts from
sharp metal edges and aluminum fins on front and
rear coils.
TOOLS YOU WILL NEED
TOOLS YOU MAY USE
NOTE:
Save Carton and these Installation Instructions
for future reference. The carton is the best way
to store unit during winter, or when not in use.
4
Screwdriver
Level
Screwdriver
Pencil
Ruler or tape measure
Scissors or knife
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Keystone KSTAW12CE
Summary of Contents for Keystone KSTAW12CE
- Page 1 INSTALLATION INSTRUCTIONS CAUTION BEFORE YOU BEGIN Do not, under any circumstances, cut or Read these instructions completely remove the third (ground) prong from the and carefully. power cord. IMPORTANT- Save these Do not change the plug on the power cord instructions for local inspector s use.
- Page 2 INSTALLATION INSTRUCTIONS C: Align the hole in the top rail with those in the top PREPARE THE WINDOW of the unit as shown in Fig.B Lower sash must open sufficiently to allow a clear Fi g.B vertical opening (H) of following size (see Table 1). Side louvers and the rear of the AC must have clear air space to allow enough airflow through the condenser,for heat removal.
- Page 3 INSTALLATION INSTRUCTIONS Ⅰ B. Slide the free end " " section of the panel directly SECURE THE ACCORDION PANE LS into the cabinet as shown in Fig. 2. Slide the panel down. Be sure to leave enough space to slip the A.Keep a firm grip on the air conditioner, carefully top and bottom of the frame into the rails on the place the unit into the window opening so the bottom...
- Page 4 INSTALLATION INSTRUCTIONS B.Drive 3/4" (19mm) or 1/2" (12.7mm) locking If AC is Blocked by Stor m W indow screws through frame holes into window sash (Fig.8). Add wood as shown in Fig.11, or remove storm window before air conditioner is installed. If Storm Window Frame must remain, be sure the drain holes or slots are not caulked or painted shut.
