Technical data

Technical data
MODEL: SURFOX BASIC
PART NUMBER: 54–D 046
INPUT AMPERAGE: 220V, 50/60 Hz
OUTPUT AMPERAGE: 12-30 V, AC
INPUT CURRENT: 2 Amps
OUTPUT CURRENT: MAX 20 Amps
12
9

Safety features

Safety features

A) Sparks on the tip/work piece

To avoid short circuits (arcing), the machine automatically
stops when the insert touches the work piece (metal to
metal contact). There is an inverter board that monitors
the amperage every millisecond. If the amperage sharply
increases creating a short, the system will automatically cut
the power to the tip to avoid any damage to the equipment.

B) Internal temperature

To protect the internal components of the machine, there
are temperature sensors inside the machine. If the operat-
ing temperature is too high, the machine will shut down and
restart by itself when the temperature reaches an
acceptable level.
WARNING!
The inside temperature can increase for
many reasons: high ambient temperature, lack of
proper air circulation around the machine, fluctuations
in amperage, electrical set-up in the shop, etc.
