By Date: System will wake on the day with hr::min::sec specified.
By Weekday: System will wake on the enabled weekday with hr::min::sec specified.
Bypass: BIOS will not control RTC wake function.
3.4.13
GPIO Port Configuration
Options Summary
GPIO Port 7 - 12
Set GPIO as Input or Output.
GPIO Port 13
Set GPIO as Input or Output.
Output Level
Set output level when GPIO pin is output.
Chapter 3 – AMI BIOS Setup
Input
Output
Input
Output
Low
High
Optimal Default, Failsafe Default
Optimal Default, Failsafe Default
Optimal Default, Failsafe Default
