2.3

Extra DC 5V Power in (BAT1)

Pin
1
2
2.4

MXM Gold Finger (GF2)

Pin Pin Name
P1 SMB_ALERT#
P2 GND
P3 CSI1_CK+
P4 CSI1_CK-
P5 GBE1_SDP
P6 GBE0_SDP
P7 CSI_B_DP_0
P8 CSI_B_DN_0
P9 GND
P10 CSI_B_DP_1
P11 CSI_B_DN_1
P12 GND
P13 CSI_B_DP_2
P14 CSI_B_DN_2
P15 GND
P16 CSI_B_DP_3
P17 CSI_B_DN_3
P18 GND
P19 GBE0_MDI3-
P20 GBE0_MDI3+
P21 GBE0_LINK1000#
P22 GBE0_LINK2500#
P23 GBE0_MDI2-
P24 GBE0_MDI2+
Chapter 2 – Hardware Information
Pin Name
+5V
GND
Pin Pin Name
S1 CSI1_TX+/I2C_CAM1_CK
S2 CSI1_TX-/I2C_CAM1_DAT
S3 GND
S4 RSVD
S5 CSI0_TX+/I2C_CAM0_CK
S6 CAM_MCK
S7 CSI0_TX1/I2C_CAM0_DAT
S8 CSI0_CK+
S9 CSI0_CK-
S10 GND
S11 CSI_C_DP_0
S12 CSI_C_DN_0
S13 GND
S14 CSI_C_DP_1
S15 CSI_C_DN_1
S16 GND
S17 GBE1_MDI0+
S18 GBE1_MDI0-
S19 GBE1_LINK1000#
S20 GBE1_MDI1+
S21 GBE1_MDI1-
S22 GBE1_LINK2500#
S23 GBE1_MDI2+
S24 GBE1_MDI2-
