1.1

Specifications

System
Form Factor
CPU
Chipset
Memory
Onboard Storage
BIOS
Wake on LAN
Watchdog Timer
Dimension (L x W)
Security
Power
Power Requirement
Power Type
Power Consumption
(Typical)
Display
Graphics Controller
Video Output
Chapter 1 – Product Specifications
SMARC Module
Intel® Core™ i3-N305 Processor (8C/8T, up to 3.8 GHz,
15W)
Intel Atom® x7425E Processor (4C, up to 3.4 GHz, 12W)
Intel® Processor N97 (4C, up to 3.6 GHz, 12W)
Integrated with Intel® SoC
Onboard LPDDR5x 4800MHz, up to 8GB
eMMC, up to 64GB
AMI UEFI
Yes
255 Levels
3.23" x 1.97" (82mm x 50mm)
TPM 2.0
+5V for ATX / AT
AT (default)/ATX, switch by BIOS
Intel® Core™ i3-N305, 4.23A @+5V
Intel® UHD Graphics
DP++ x 2, up to 3840 x 2160
eDP x 1, up to 3840 x 2160
2
