Tendercare Snappi Playtray Instructions

6.8: Playtray – not suitable for rearward facing Snappi
The Snappi playtray offers height, depth and
angle adjustment, so that it can be adapted
to suit your needs. It is available in clear or
black. (Clear playtray shown for illustrative
purposes Fig 6.8.1).
The playtray comes supplied with the
following:
• 2 angle adjustable vertical stems
(marked A and B) in the bag.
• 2 depth adjustment brackets and
thumbscrews (fitted to the tray, also
marked A and B).
• 2 additional thumbscrews for the seat
receiver brackets in the bag.
The angle adjustable vertical stems will be in
the bag and need to be fitted. When
attaching the angle adjustable vertical stems
to the depth adjustment brackets, most
people should attach vertical stem A to depth
adjustment bracket A (as illustrated in Fig
6.8.3) and then B to B.
However, if you require more outward
adjustment (i.e. for the playtray to be further
away from the occupant's torso), instead of
attaching A to A and B to B, you can attach
Document No: 053-29 v1
Snappi Playtray Instructions.doc
Snappi Playtray Instructions
Fig 6.8.2
Page 1 of 3
Fig 6.8.1
The playtray is supplied with the
depth adjustment brackets fitted to
the tray (as illustrated in Fig 6.8.2)
These are marked with the letters A
and B. A is one side, B is the other.
Fitted depth adjustment brackets and
thumbscrews
Vertical stem A
Fig 6.8.3
Fitted depth
adjustment
bracket A
January 2024
