TPS-1 Low-cost
Solution Kit
TPS-1 Low-cost Solution Kit - Hardware Manual
YCONNECT-IT-TPS-1L
All information contained in these materials, including products and product specifications,
represents information on the product at the time of publication and is subject to change by
Renesas Electronics Corp. without notice. Please review the latest information published by
Renesas Electronics Corp. through various means, including the Renesas Technology Corp.
website (http://www.renesas.com).
www.renesas.com
R21UT0239ED0103, Rev. 1.03
September 12, 2023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TPS-1 and is the answer not in the manual?

Questions and answers

Related Manuals for Renesas TPS-1

Summary of Contents for Renesas TPS-1

  • Page 1 All information contained in these materials, including products and product specifications, represents information on the product at the time of publication and is subject to change by Renesas Electronics Corp. without notice. Please review the latest information published by Renesas Electronics Corp. through various means, including the Renesas Technology Corp.
  • Page 2 Renesas Electronics. Renesas Electronics shall not be in any way liable for any damages or losses incurred by you or third parties arising from the use of any Renesas Electronics product for an application categorized as “Specific” or for which the product is not intended where you have failed to obtain the prior written consent of Renesas Electronics.
  • Page 3 Renesas Electronics product, such as safety design for hardware and software including but not limited to redundancy, fire control and malfunction prevention, appropriate treatment for aging degradation or any other appropriate measures.
  • Page 4 General Precautions in the Handling of MPU/MCU Products The following usage notes are applicable to all MPU/MCU products from Renesas. For detailed usage notes on the products covered by this manual, refer to the relevant sections of the manual. If the descriptions under General Precautions in the Handling of MPU/MCU Products and in the body of the manual differ from each other, the description in the body of the manual takes precedence.
  • Page 5 Some information contained in this document may vary from country to country. Before using any Renesas Electronics product in your application, please contact the Renesas Electronics office in your country to obtain a list of authorized representatives and distributors. They will verify: •...
  • Page 6 Preface Readers This manual is intended for users who want to understand the functions of the concerned microcontrollers. Purpose This manual presents the hardware manual for the concerned microcontrollers. Organisation This system specification describes the following sections: • Pin function •...
  • Page 7 The revision history summarizes the locations of revisions and additions. It does not list all revisions. Refer to the text of the manual for details. The following documents apply to the TPS-1 Group. Make sure to refer to the latest versions of these documents. The newest versions of the documents listed may be obtained from the Renesas Electronics Web site.
  • Page 8 TPS_Update_Manual_EN.pdf Application Note for TPS-1 firmware update PROFINET Configurator - Quick start guide for the PROFINET Quick Start Guide.pdf Configurator tool User Manual TPS-1 Low-cost Solution Kit (this R21UT0239ED0103 manual) Getting started for TPS-1 Low-cost Solution Kit R21UT0236ED0106 with RX630...

  • Page 9: Table Of Contents

    Functional Specifications ................11 Environmental Specifications and Weight ..........12 Communication Specifications ..............12 Chapter 3 TPS-1 Board Blocks and Descriptions ......13 TPS-1 Board Block Diagram ................. 13 TPS-1 System Clock ..................13 External Memory (Serial Flash Memory) ............. 14 Power Supply ....................

  • Page 10: Chapter 1 Introduction

    TPS-1 device with individual target host CPUs. The TPS-1 Low-cost Solution Kit is made up of two boards shown in. The TPS-1 main board can be connected to an adapter board used to evaluate parallel I/O operation, as well as CPU parallel and serial host communication.

  • Page 11: Chapter 2 General Specifications

    Table 2-1: Electrical specifications Item Specification Rated voltage 5V DC Power supply Current app. 300 mA (only TPS-1 board) Status LED(PWR) 2.2 Functional Specifications Table 2-2: Functional specifications Item Specification Main LSI TPS-1 (Operating frequency 100MHz) RJ-45(w/ built-in pulse-...

  • Page 12: Environmental Specifications And Weight

    TPS-1 Low-cost Solution Kit General Specifications 2.3 Environmental Specifications and Weight Table 2-3: Environmental Specifications Item Specification Ambient operating 0 to +55℃ temperature Ambient storage temperature -25 to +70℃ Physical environment Ambient operating humidity 30 to 90%RH (no condensation) Ambient storage humidity...

  • Page 13: Chapter 3 Tps-1 Board Blocks And Descriptions

    3.1 TPS-1 Board Block Diagram Figure 3-1: TPS-1 board block diagram 3.2 TPS-1 System Clock An oscillator supplies 25 MHz as the TPS-1 standard clock. This clock is internally quadrupled to the system clock of 100 MHz. Clock circuit Figure 3-2:...

  • Page 14: External Memory (Serial Flash Memory)

    Macronix MX25L8006EM1I-12G or equivalent 3.4 Power Supply A 5V DC power supply can be input through the DC jack J7 to power the TPS-1 board; alternatively 5V can as be supplied with the USB micro-B connector CN1. The power LED LD5 (red) lights up when 5.0V is supplied. The DC jack is a HEC0470-01-630 from Hosiden and +5V is supplied on the center pin (see Figure 3-4).

  • Page 15: Profinet Io

    TPS-1 Board Blocks and Descriptions 3.5 PROFINET IO PROFINET IO communication from the TPS-1 is carried out via a built-in PHY. The link and activity status are visualized with LEDs in the connectors, while the PROFINET status is indicated with four LEDs on the board.

  • Page 16: Uart Connector Cn1

    75Ω resistor 3.6 UART connector CN1 A UART to USB conversion LSI (FT 232 RQ) is provided on the TPS-1 board and so the TPS-1 board performs asynchronous communication with a PC by connecting a USB connector. The board is equipped with a USB micro-B connector CN1.

  • Page 17: Jtag Connector J1

    TeraTerm serial port setup 3.7 JTAG Connector J1 For the connection of a JTAG tool an access to the TPS-1 JTAG interface is provided through 10-pin connector J1. Note that this connector is not assembled, as access to the JTAG interface is normally not required. The connector used here, is a standard 1-row, 10-pin, 1.27mm pitch connector from HARWIN (M52-...

  • Page 18: Reset Circuit

    IC. The output of the reset-IC is made available on connector J4 so that external hardware is aware that TPS-1 is reset. On the other hand the TPS-1 can as well be reset by the external hardware. Figure 3-10: Reset circuit Board Rev.

  • Page 19: Leds

    Part Model No.: BR1111C-TR, PG1111C-11-TR, FY1111C-TR These are red, green and yellow LEDs used to check PROFINET operations. They are directly connected to the respective TPS-1 outputs. Table 3-4 shows the details; shows the position of the LEDs on the TPS-1 board.

  • Page 20: Configuration Jumpers

    This is the switching jumper for the JTAG interface. Set Jumper J2 to position 2-3 because the JTAG interface is not used with this board. In position 2-3 the TRSTN input of the TPS-1 is permanently kept active and thus the JTAG interface is kept in reset.

  • Page 21: Boot Mode Switching Jumper J6

    TPS-1 starts up in UART mode regardless of the boot mode setting. Switch to the UART mode (position 2-3) in order to force TPS-1 to boot in UART mode even when there is data in the flash. This may be needed for example to erase the flash memory.

  • Page 22: Multi-Board Interface J4

    3.11 Multi-board Interface J4 The 68-pin connector in Figure 3-13 enables connection to I/O and CPU boards. It provides access to all GPIO pins of the TPS-1, to reset, interrupt and watchdog signals, to the IRT synchronization signals and power (3.3V) and GND.
  • Page 23 TPS-1 Low-cost Solution Kit TPS-1 Board Blocks and Descriptions Table 3-7: Multi-board connector J4 pin assignment J4 pin/ TPS-1 Adapter J4 pin Adapter TPS-1 board CN1 pin board board CN1 pin board GPIO0 GPIO0 GPIO34 GPIO34 GPIO1 GPIO1 GPIO35 GPIO35...

  • Page 24: Chapter 4 Adapter Board Description

    There are two use cases for this board: 1. If TPS-1 is operated in parallel IO mode, the level of 8 GPIOs of the TPS- 1 can visualized with a set of 8 green LEDs. On the other hand 8 other GPIOs can be pulled to GND or 3.3V.
  • Page 25 TPS-1 Low-cost Solution Kit Adapter Board Description Table 4-1: CPU board connector CN2 pin assignment J4 pin TPS-1 signal CN2 pin TPS-1 signal J4 pin GPIO34 GPIO35 GPIO36 GPIO37 GPIO38 GPIO39 GPIO40 GPIO41 GPIO42 GPIO43 GPIO44 GPIO45 GPIO46 GPIO47 INT_OUT...

  • Page 26: Led Connector Cn5

    The separation of the CN5-related circuit of the rest allows a more flexible usage of the limited number of LEDs. If you want to check TPS-1 output data in a simple parallel IO-mode application, you can wire the 8 LEDs with the jumper cables in the kit between CN5 and CN2/3 to arbitrary GPIOs of TPS-1 according to Table 4-1 andTable 4-2.

  • Page 27: Pull Resistor Connector Cn4

    Table 4-4 shows the pin assignment for CN4. Note: If you draw current from connector CN4, please make sure that the power supply circuitry on the TPS-1 main board is not overloaded. Pull resistor connector CN4 pin assignment Table 4-4:...
  • Page 28 TPS-1 Low-cost Solution Kit Adapter Board Description Revision History Revision Issue Date Major changes R21UT0239ED0100 May 31 2017 Initial release added operating current to Table 2-1 R21UT0239ED0101 August 3 , 2018 rearranged table in chapter 2.4 clarified power supply alternatives in chapter 3.4 Table 3-1: cleaned up clarified wording in chapter 3.10.2...
  • Page 29 YCONNECT-IT-TPS-1L...
