Summary of Contents for Black Box HD6224A-R2
- Page 1 DATA SHEET HD6224A-R2 4K60 HDMI DUAL-HEAD KVM SWITCH 24/7 TECHNICAL SUPPORT AT 877.877.2269 OR VISIT BLACKBOX.COM...
-
Page 2: Table Of Contents
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 TABLE OF CONTENTS TECHNICAL SUPPORT 1.877.877.2269 QUICK START GUIDE....................................3 Hardware Installation ..........................................3 Front-Panel Control..........................................3 Commands..............................................3 1. SPECIFICATIONS....................................4 2. OVERVIEW......................................5 2.1 Introduction........................................5 2.2 Features.........................................5 2.3 What’s Included......................................6 2.4 Hardware Description....................................6 2.4.1 Front Panel..........................................6 2.4.2 Back Panel..........................................7 3. -
Page 3: Quick Start Guide
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 QUICK START GUIDE TECHNICAL SUPPORT 1.877.877.2269 HARDWARE INSTALLATION 1. Ensure that power is disconnected from the 4K60 HDMI Dual-Head KVM Switch. 2. Connect the HDMI cables and USB cables (male-A to male-B) from the computers to the respective ports on the KVM Switch. 3. -
Page 4: Specifications
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 1: SPECIFICATIONS TECHNICAL SUPPORT 1.877.877.2269 SPECIFICATIONS FOR HD6224A-R2 VIDEO LINK RATE 5.4 Gbps/lane INPUT INTERFACE (8) HDMI 2.0 female OUTPUT INTERFACE (2) HDMI 2.0 female RESOLUTION Ultra-HD 4K (3840 x 2160) @ 30/50/60 Hz... -
Page 5: Overview
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 2: OVERVIEW TECHNICAL SUPPORT 1.877.877.2269 2.1 INTRODUCTION The 4K60 HDMI Dual-Head KVM Switch - 4-Port is a dedicated multi-platform KVM switch capable of managing four dual-head 4K computers through a single KVM. Built with ultra-HD ready HDMI outputs, the KVM Switch offers full 4K emulation at 60 Hz directly from the device. -
Page 6: What's Included
Before you install this switch, verify that your package contains the following items: ƒ (1) 4K60 HDMI Dual-Head KVM Switch - 4-Port ƒ (1) 12VDC, 3A power adapter with international clips If anything is missing or damaged, contact Black Box Technical Support at 877-877-2269 or info@blackbox.com. 2.4 HARDWARE DESCRIPTION 2.4.1 FRONT PANEL Figure 2-1 shows the front panel of the HD6224A-R2. -
Page 7: Back Panel
CHAPTER 2: OVERVIEW TECHNICAL SUPPORT 1.877.877.2269 2.4.2 BACK PANEL Figure 2-2 shows the back panel of the HD6224A-R2. Table 2-2 describes its components. FIGURE 2-2. BACK PANEL OF THE HD6224A-R2 TABLE 2-2. HD6224A-R2 BACK-PANEL COMPONENTS NUMBER IN FIGURE 2-2 COMPONENT... -
Page 8: Hardware Installation
7. Optionally connect up to 2 USB peripheral devices such as printers or flash drives. 8. Connect the display monitors to the OUTPUT connectors on the KVM Switch. 9. Power on the KVM Switch. Comput ers Comput ers HD6224A-R2 Print er Laptop for RS-232 control Moni tors... -
Page 9: Front-Panel Control
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 4: FRONT-PANEL CONTROL TECHNICAL SUPPORT 1.877.877.2269 To switch to an input port, simply push the desired input button on the front-panel of the KVM. If an input port is selected, the green LED indicator of that port will turn on. 1.877.877.2269 BLACKBOX.COM... -
Page 10: Hotkey Control
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 5: HOTKEY COMMANDS TECHNICAL SUPPORT 1.877.877.2269 A hotkey command is a keyboard sequence used to trigger an action on the KVM Switch through the use of the keyboard connected on the USB port of the KVM Switch. To activate the hotkey sequence, press the CTRL key twice and then enter the desired hotkey commands. -
Page 11: Rs-232 Control
An example of a straight through cable pinout is shown in Figure 6-1. The standard maximum length for an RS-232 cable is 50 feet (15.2 meters). Contact Black Box Technical Support at 877-877-2269 or info@blackbox.com if you require more information. - Page 12 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 6: RS-232 CONTROL TECHNICAL SUPPORT 1.877.877.2269 FIGURE 6-2. COM PORT NUMBER Run the terminal client of your choice such as HyperTerminal or PuTTY. Select the correct COM port on the computer. Use the following connection settings: 115200, N, 8, 1, no flow control.
-
Page 13: Appendix A. Regulatory Information
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 APPENDIX A: REGULATORY INFORMATION TECHNICAL SUPPORT 1.877.877.2269 A.1 FCC CLASS A STATEMENT This equipment has been found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. -
Page 14: Nom Statement
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 APPENDIX A: REGULATORY INFORMATION TECHNICAL SUPPORT 1.877.877.2269 A.2 NOM STATEMENT Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado. Las instrucciones de seguridad y operación deberán ser guardadas para referencia futura. Todas las advertencias en el aparato eléctrico y en sus instrucciones de operación deben ser respetadas. -
Page 15: Appendix B. Disclaimer/Trademarks
B.1 DISCLAIMER Black Box Corporation shall not be like liable for damages of any kind, including, but not limited to, punitive, consequential or cost of cover damages, resulting from any errors in the product information or specifications set forth in this document and Black Box Corporation may revise this document at any time without notice. - Page 16 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 TECHNICAL SUPPORT 1.877.877.2269 COPYRIGHT 2023. BLACK BOX CORPORATION. ALL RIGHTS RESERVED. ® EN_KVM_Manual_HD6224A-R2_Rev1_ 2307.PDF...
