Spectra POWERBOX 100 Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SPECTRA POWERBOX 100‐
SERIES
USER MANUAL
Version 1.32 – June 2023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POWERBOX 100 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Spectra POWERBOX 100 Series

Summary of Contents for Spectra POWERBOX 100 Series

  • Page 1 SPECTRA POWERBOX 100‐ SERIES USER MANUAL Version 1.32 – June 2023...

  • Page 2: Table Of Contents

    1.1.3 Photo of Rear Panel …..……………………………………..14 1.2 Hardware Specification …..…………………………………………… 15 1.3 System I/O ……………………………………………………………… 16 1.3.1 Spectra PowerBox 100…………………………………….…… 16 1.3.2 Spectra PowerBox 100 with modules.. …………………….……18 1.4 Mechanical Dimension …..……………………………………………. 19 Chapter 2 Jumpers and Connectors 2.1 Jumper Setting ………………………………………………………..21 2.2 Location of the Switches and Connectors……..……………………..
  • Page 3 4.3.8 OS Selection……………………..……………………………….. 64 4.3.9 CSM Configuration…..…………………………………………… 65 4.3.10 USB Configuration …………………………………….……….. 67 4.4 Chipset …………………………………………………………………….69 4.4.1 North Bridge……………………………………………………… 69 4.4.2 South Bridge……………………………………………………… 71 4.5 Security……………………………………………………………………. 74 4.5.1 Administrator Password………………………………………….. 74 4.5.2 User Password………….……..…………………………………. 74 Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...
  • Page 4 4.7.4 Save as User Defaults ……………………………………………76 4.7.5 Restore User Defaults ………………………..…………………. 76 Chapter 5 Product Application (For Spectra PowerBox 100 w/ PB-100-DIO modul only) 5.1 Digital I/O (DIO) application……………………….…..….…………….. 78 5.1.1 Digital I/O Programming Guide ………………………………... 78 Digital I/O (DIO) Hardware Specification………………….

  • Page 5: Prefaces Revision

    2023/06/19 Copyright Notice © 2016 by Spectra GmbH & Co. KG. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Spectra GmbH &...

  • Page 6: Product Warranty Statement

    (such as a fuse, battery, etc.), are not warranted. Before sending your product in, you will need to fill in a Spectra RMA Request Form and obtain a RMA number from us. Please go to www.spectra.de/RMA...

  • Page 7: Technical Support And Assistance

    This indication alerts operators to an operation that, if not strictly observed, may result in safety hazards to personnel or damage to equipment. This indication provides additional information to complete a task easily. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 8: Safety Precaution

     The equipment has been dropped and damaged.  The equipment has obvious signs of breakage. 14. CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 9: Package Content

    Prefaces Package Contents Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty Spectra PowerBox 100 Embedded System Utility DVD Driver Power Terminal Block Connector (Male) Screw Pack (for HDD / Mini‐PCIe / Wall & VESA  Mounting) Wall Mount Kit  DVI‐I to VGA  Adapter Remote Power On/Off Terminal Block Connector (Male) Note: Notify your sales representative if any of the above items are missing or damaged.

  • Page 10: Ordering Information

    Prefaces Ordering Information Model Name Product Description Intel® Atom™ Processor E3826 Affordable Fanless Embedded  Spectra PowerBox 100 Computer  Intel® Atom™ Processor E3826 Affordable Fanless Embedded  Spectra PowerBox 100‐WT Computer, Wide Temp. Intel® Atom™ Processor E3845 Affordable Fanless Embedded  Spectra PowerBox 100QC Computer  Intel® Atom™ Processor E3845 Affordable Fanless Embedded  Spectra PowerBox 100QC‐WT Computer, Wide Temp. Spectra PowerBox 100‐J19 Intel® Celeron™ Processor J1900 Affordable Fanless Embedded  Computer Spectra PowerBox 100‐J19‐WT Intel® Celeron™ Processor J1900 Affordable Fanless Embedded  Computer, Wide Temp. Spectra GmbH & Co. KG User Manual Version 1.31...

  • Page 11: Optional Accessory

    Prefaces Optional Accessory Model No. Description PB‐100‐COM‐Modul 2x RS‐232/422/485, incl. Universal Bracket PB‐100‐DIO‐Modul 4x DI/4x DO, incl. Universal Bracket PB‐100‐DP‐Modul 1x Display Port, incl. Universal Bracket PB‐100‐HDMI‐Modul 1x HDMI, incl. Universal Bracket PB‐100‐DVI‐Modul 1x DVI‐D, incl. Universal Bracket PB‐100‐LPT/PS2‐Modul 1x LPT/PS2, incl. Universal Bracket PB‐100‐VGA‐Modul 1x VGA, incl. Universal Bracket PB‐100‐MEC‐LAN 2x GLAN, incl. Universal Bracket Side Mount‐Kit for PB 100 Side‐Mount‐Kit DIN Rail Kit for PB100 DIN Rail Kit  Wall Mount‐Kit for PB100 Wall Mount‐Kit incl. 4x Screw VESA‐Mount for PB100 4x Screw Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 12: Chapter 1 Product Introductions

    Chapter 1 PRODUCT INTRODUCTIONS...

  • Page 13: Overview

    J1900 (2.0GHz) platform; it has integrated HD graphics processor. This can bring economic advantages on budget and also fulfill the needs for industrial computing tasks. The Spectra PowerBox 100 manages to pack a diverse array of I/O into its small form factor, with one DVI-I port, two RS-232/422/485 COM ports, dual Gb LAN ports, four USB ports and one set of Mic-in and Line-out.

  • Page 14: Photo Of Rear Panel

    Chapter 1: Product Introductions 1.1.3 Photo of Rear Panel Spectra PowerBox 100 Spectra PowerBox 100 Spectra PowerBox 100 w/ PB-100-COM Module w/ PB-100-DIO Module Spectra PowerBox 100 Spectra PowerBox 100 w/ PB-100-DP Module w/ PB-100-DVI Module Spectra PowerBox 100 Spectra PowerBox 100...

  • Page 15: Hardware Specification

    • Linux® Ubuntu 14.04 Power Requirement • Support AT/ATX Power Mode • Power Input Voltage 9~48VDC • One 3-pin Terminal Block Connector • Optional Power Adapter AC/DC 12V/5A 60W • Power Consumption Typical 8.3W, Max.15W Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 16: System I/O

    Chapter 1: Product Introductions 1.3 System I/O 1.3.1 Spectra PowerBox 100 Front Panel USB 3.0 Port Power On/Off Switch Used to connect USB 3.0/2.0/1.1 device Press to power-on or power-off the system AT/ATX Mode Select Switch USB 2.0 Port Used to select AT or ATX power mode Used to connect USB 2.0/1.1 device...
  • Page 17 COM / DIO / DisplayPort / DVI / LPT & PS2 / VGA. Do not change the module by yourself, it may cause damage to your Spectra PowerBox 100. Please contact with your regional dealer for more information about it.

  • Page 18: Spectra Powerbox 100 With Modules

    Chapter 1: Product Introductions 1.3.2 Spectra PowerBox 100 Series w/ modules w/ PB-100-COM Front Rear w/ PB-100-DIO Front Rear w/ PB-100-DP Front Rear w/ PB-100-DVI Front Rear PB-100-LPT/PS2 Front Rear w/ PB-100-VGA Front Rear Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series...

  • Page 19: Mechanical Dimension

    Chapter 1: Product Introductions 1.4 Mechanical Dimensions Each of the Spectra PowerBox computers has the same mechanical dimension Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 20: Chapter 2 Jumpers And Connectors

    Chapter 2 JUMPERS AND CONNECTORS...

  • Page 21: Jumper Setting

    Chapter 2: Jumpers and Connectors 2.1 Jumpers Settings The Spectra PowerBox 100 is featured with jumper-free design 2.2 Location of the Jumpers and Connectors 2.2.1 Top View Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 22: Bottom View

    Chapter 2: Jumpers and Connectors 2.2.2 Bottom View Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 23: List Of Switches And Connectors

    Microphone-in Jack MINIPCIE1 Mini PCI-Express Socket PWR_SW2 External Power Connector SATA1 SATA with Power Connector SIM1 SIM Card Socket (apply with MINIPCIE1) USB2_1 / USB2_2 / USB2_3 USB 2.0 Connector USB3_1 USB 3.0 Connector Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 24: Switches Definitions

    2.4 Switches Definitions AT_ATX1：AT / ATX Power Mode Switch Switch Definition Right ATX Power Mode（Default） Left AT Power Mode CLR_CMOS1：Clear CMOS Switch Switch Definition Clear CMOS Normal Status (Default) PWR_SW1：Power Switch Definition Power Button Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 25: Connectors Definitions

    2.5 Connectors Definitions 2.5.1 CN1：Mini PCI-Express / mSATA Socket Definition Definition WAKE# +3.3V +1.5V SMB_CLK MINIPCIE_TXN3/SATA_TXN1 +1.5V SMB_DATA CLKREQ# MINIPCIE_TXP3/SATA_TXP1 USB_6N MINIPCIE_CLKN3 USB_6P MINIPCIE_CLKP3 +3.3V +3.3V +3.3V MINIPCIE RST# +1.5V MINIPCIE_RXN3/SATA_RXP1 +3.3V MINIPCIE_RXP3/SATA_RXN1 +3.3V Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 26: Minipcie1：Mini Pci-Express Socket

    Chapter 2: Jumpers and Connectors 2.5.2 MINIPCIE1：Mini PCI-Express Socket Definition Definition WAKE# +3.3V +1.5V SMB_CLK MINIPCIE_TXN4 +1.5V SMB_DATA CLKREQ# MINIPCIE_TXP4 USB_7N MINIPCIE_CLKN4 USB_7P MINIPCIE_CLKP4 +3.3V +3.3V +3.3V MINIPCIE RST# +1.5V MINIPCIE_RXN4 +3.3V MINIPCIE_RXP4 +3.3V Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 27: Sim1：Sim Card Socket

    Connector Type：Phoenix 1X3 3-pin, 5.0mm pitch Definition +9~48V IN Chassis GND 2.5.5 PWR_SW2：External remote power on/off switch (Note: Please do not apply power to the pins. This port is used to apply a switch.) 1   2 Definition PWR_ON Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 28: Com1_1：Rs232 / Rs422 / Rs485 Connector

    RX2+ DTR2 RX2- GND2 DSR2 RTS2 CTS2 NOTE： (For Spectra PowerBox w/ PB-100-COM Modul only) The optional module 2 COM ports <RS232 / RS422 / RS485> are with +5/ +12VDC for RI pin (Pin 9). Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series...

  • Page 29: Com3 & Com4：Voltage Select

    PIN 3-5, PIN 4-6 PIN 7-9, PIN 8-10 RI (Default) 2.5.9 DVI_I1：DVI-I Connector Definition Definition DVI_TX2- DVI Hot Plug Detect DVI_TX2+ DVI_TX0- DVI_TX0+ DDC_CLOCK DDC_DATA VGA VSYNC DVI_TXCLK+ DVI_TX1- DVI_TXCLK- DVI_TX1+ VGA_RED VGA_GREEN VGA_BLUE VGA_HSYNC Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 30: Lan1：Rj45 With Led Connector

    1Gbps Network Link Steady Amber 100Mbps Network Link 10Mbps Network Link 2.5.12 LED1：Power / HDD Access LED Status Definition HDD LED+ HDD LED- POWER LED+ POWER LED- LED Status LED Color Yellow POWER Green Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 31: Line_Out1: Line-Out Jack (Green)

    2.5.14 MIC1： Line-out Jack (Green) Microphone Jack (Pink) Connector Type：5-pin Phone Jack Connector Type：5-pin Phone Jack Definition Definition OUT_R MIC_R OUT_L MIC_L 2.5.15 SATA1：SATA Connector Definition Definition +3.3V +3.3V +12V +3.3V +12V +12V Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 32: Usb1 & Usb2 & Usb3：Usb2.0 Connector, Type A

    Chapter 2: Jumpers and Connectors 2.5.16 USB1 & USB2 & USB3：USB2.0 Connector, Type A USB1 USB2 USB3 Definition Definition Definition USB_DATA3- USB_DATA2- USB_DATA1- USB_DATA3+ USB_DATA2+ USB_DATA1+ 2.5.17 USB4：USB3.0 Connector, Type A USB4 Definition USB_DATA0- USB_DATA0+ Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 33: Chapter 3 System Setup

    Chapter 3 SYSTEM SETUP...

  • Page 34: Removing The Chassis Bottom Cover

    1. Turn over the unit to have the bottom side face up, loosen the 4 screws of bottom cover and place them aside 2. Remove the cover from the chassis. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 35: Removing The Chassis

    (right picture) as marked on photo and place them aside. 2. Hold front and rear panel and lift up the body of unit vertically. 3. Turn over the body of the unit and place it gently. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 36: Installing The Antennas

    Chapter 3: System Setup 3.3 Installing the Antennas 1. Remove the antenna hole covers at back panel. 2. Have antenna jack penetrate through the hole. 3. Put on washer and fasten the nut with antenna jack. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...
  • Page 37 Chapter 3: System Setup 4. Assemble the antenna and antenna jack together. 5. Attach the RF connector at another end of cable onto the module. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 38: Installing A Full-Size Mini Pcie Card On Bottom Side

    1. Turn over the body of unit. Unscrew the 3 screws on HDD bracket and remove the bracket. Similar illustration 2. Locate the Mini PCIe slots. Please note that the left connector is shared mSATA/Mini-PCIe interface, and right connector (with SIM socket underneath) is Mini-PCIe interface. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...
  • Page 39 4. Press down the module and use the two screws to fix the module. 5. If you have a Half-size Mini-PCIe card, make sure use extender to make it Full-size as shown below. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 40: Installing A Sata Hard Drive

    4 provided screws to assemble HDD and HDD bracket together. 3. Turn over the HDD bracket. Connect the HDD bracket to the SATA connector of the unit and fasten the 3 screws. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 41: Installing A Sodimm

    2. Tilt the SODIMM module at a 45 degree angle and insert it to SODIMM socket until the gold-pated connector of module contacted firmly with the socket. 45° Similar illustration 3. Press the module down until it’s fixed firmly by the two locking latches on the sides. Similar illustration Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 42: Installing The Chassis

    2. Make sure the either sides of front and rear panels are in the chassis grooves and insert the body of unit into Chassis. Use the 3 screws to fasten the body and chassis together. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 43: Installing The Chassis Bottom Cover

    Chapter 3: System Setup 3.8 Installing the Chassis Bottom Cover 1. Level the grooves on bottom cover with front and rear panels. Put on the cover. 2. Fasten the 4 screws to fix the cover. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 44: Installing A Sim Card

    Chapter 3: System Setup 3.9 Installing a SIM Card 1. Locate the SIM card socket. 2. Insert the SIM card. 3. Press down the socket of SIM card to lock the location. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 45: Wall Mount Brackets

    Chapter 3: System Setup 3.10 Wall Mount Brackets The Spectra PowerBox 100 offers Wall Mount that customers can install system on the wall in convenient and economical way. 1. The mounting holes are at the bottom of system. Use provided 4 screws to fasten the bracket with each side of system together.

  • Page 46: Side Mount Bracket

    Chapter 3: System Setup 3.11 Side Mount Bracket The Spectra PowerBox 100 offers Side Mount that customer can install system to the right or left side of wall to create effective of space. 1. The mounting holes are at the bottom of system. Fasten the 4 screws to fix the side mount bracket with system together.

  • Page 47: Vesa Mount Bracket

    Chapter 3: System Setup 3.13 VESA Mount Brackets The Spectra PowerBox 100 offers VESA Mount that customer can mount system with panel complying with VESA 75mm and 100 mm standard for various usage. 2. Provided below is mounted with VESA 1.

  • Page 48: Din-Rail Mount Bracket

    Chapter 3: System Setup 3.14 DIN-Rail Mount Bracket The Spectra PowerBox 100 offers DIN-Rail Mount that customer can install system on the DIN Rail. 1. The mounting holes are at the bottom of system. Fasten the 2 screws to fix the DIN- Rail mount bracket with system together.

  • Page 49: Chapter 4 Bios Setup

    Chapter 4 BIOS SETUP...

  • Page 50: Bios Introduction

    Then you can use the control keys to enter values and move from field to field within a sub-menu. If you want to return to the main menu, just press the <Esc>. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 51: Main Setup

    Use arrow keys to move among the items and press <Enter> to accept or enter a sub-menu 4.2.1 System Date Set the date. Please use <Tab> to switch between date elements. 4.2.2 System Time Set the time. Please use <Tab> to switch between time elements. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 52: Advanced Setup

    You can select any of the items in the left frame of the screen to go to the sub menus. 4.3.1 ACPI Settings ■ Enable ACPI Auto Configuration This enables ACPI power management of the system. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 53: Super I/O Configuration

    ■ Serial Port 4 Configuration This allows you to configure serial port 4. We’ll use serial port 1 configuration as an example in the manual. Similar settings apply to other serial ports configuration. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...
  • Page 54 Entering serial port 1 configuration allows you to enable or disable the port ,and also to configure settings and mode of operations. To avoid conflicted setting with other serial ports, default setting is recommended. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...
  • Page 55 Chapter 4: BIOS Setup Entering parallel port configuration allows you to enable or disable the port ,and also to configure settings and mode of device operation. Default setting is recommended. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...
  • Page 56 This allows you to set the timer unit in seconds or minutes. ■ Watch dog Timer This allows you to set between 0 and 255 in unit that was set in Watch dog Mode. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 57: Hardware Monitor

    Chapter 4: BIOS Setup 4.3.3 Hardware Monitor This allows you to monitor system’s CPU temperature and voltages. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 58: Serial Port Console Redirection

    Chapter 4: BIOS Setup 4.3.4 Serial Port Console Redirection This allows you to enable and disable serial (COM) port(s) for console use. Default setting is disabled. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 59: Cpu Configuration

    This allows you to configure CPU settings such as enabling or disabling of Intel virtualization technology. Use of default setting is recommended in the section. ■ Limit CPUID Maximum Default is Disabled. ■ Execute Disable Bit Default is Enabled. ■ Intel Virtualization Technology Default is Enabled. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...
  • Page 60 Chapter 4: BIOS Setup Entering Socket 0 CPU Information shows CPU hardware details and supported features. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 61: Thermal Configuration

    4.3.6 Thermal Configuration This allows you to configure temperature of ACPI of OS to trip or shut down the system, or to begin throttling CPU. Use of default setting is recommended in the section. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...
  • Page 62 This allows 90C (default), 87C, 85C, 79C, &1C, 63C, 55C, 47C, 39C, 31C, 23C, 15C. ■ Passive Trip Point This allows 90C, 87C, 85C (default), 79C, &1C, 63C, 55C, 47C, 39C, 31C, 23C, 15C. ■ DTS Default is Disabled. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 63: Sata Configuration

    SATA interfaces. Use of default setting is recommended in the section. ■ SATA Mode This allows to set AHCI mode (default) or IDE mode. ■ Serial-ATA Port 0 Default is Enabled. ■ Serial-ATA Port 1 Default is Enabled. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 64: Os Selection

    If you set Windows 8.x and install it or later OS, the Windows OS will easily support USB 3.0 interfaces. ■ OS Selection This allows to set Windows 8.x or Windows 7 (default). Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 65: Csm Configuration

    Chapter 4: BIOS Setup 4.3.9 CSM (Compatibility Support Module) Configuration Following shows default settings. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...
  • Page 66 Allows user to select whether to enable the UEFI or legacy option ROM for the storage device controller. Do not launch: Disables option ROM. UEFI: Enables UEFI option ROM only. Legacy: Enables legacy option ROM only. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 67: Usb Configuration

    Chapter 4: BIOS Setup 4.3.10 USB Configuration Following shows default settings. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...
  • Page 68 XHCI (USB3.0) Hand-off support. ■ EHCI Hand-off Determines whether to enable EHCI Hand-off feature for an operating system without EHCI Hand-off support. ■ USB Mass Storage Driver Support Enables or disables support for USB storage devices. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 69: Chipset

    You can select any of the items in the left frame of the screen to go to the sub menus. 4.4.1 North Bridge This section provides information on the installed memory size and memory/onboard graphics-related configuration options. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...
  • Page 70 This item will allow users to enable or disable DOP CG.  GTT Size GTT size optimal between 1MB or 2MB.  IGD Thermal This item will allow users to enable or disable IGD Thermal. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 71: South Bridge

    Chapter 4: BIOS Setup 4.4.2 South Bridge Following shows default settings. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...
  • Page 72 This item will allow users to enable or disable USB Port 1.  USB Port 2 This item will allow users to enable or disable USB Port 2.  USB Port 3 This item will allow users to enable or disable USB Port 3. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...
  • Page 73  PCI Express Port 3 This item will allow users to enable or disable PCI Express Port 3.  Speed Change the PCI Express interface speed. Select <AUTO> ,<Gen 2> or <Gen 1> Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 74: Security

    4.5.1 Administrator Password Administrator Password controls access to the BIOS Setup utility. 4.5.2 User Password User Password controls access to the system at boot and to the BIOS Setup utility. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 75: Boot

    This item allows user to enable or disable full screen logo show. 4.6.4 Fast Boot This item allows user to enable or disable Fast Boot option. 4.6.5 UEFI Boot This allows to boot device with UEFI-based (not legacy) OS. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 76: Save & Exit

    4.7.4 Save as User Defaults This item allows user to save the changes done so far as user defaults. 4.7.5 Restore User Defaults This item allows user to restore the user defaults to all the options. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 77: Chapter 5 Product Application

    Chapter 5 PRODUCT APPLICATION (for Spectra PowerBox 100 w/ PB-100-DIO Modul only)

  • Page 78: Digital I/O (Dio) Application

    To disable configuration, write exit entry key 0xAA to the index port. Following is an example to enable configuration and to disable configuration by using debug. -o 4e 87 -o 4e 87 (enable configuration) -o 4e aa (disable configuration) Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...
  • Page 79 Chapter 5: Product application 5.1.1.3 Relative Registers To program the F81866A configuration registers, the following configuration procedures. Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...
  • Page 80 // Set (bit 4~7) = 0 to select GP 54~57 as Input mode. <Input Value> WriteByte(AddrPort, 0xA1) // Select configuration register A1h ReadByte(DataPort, Value) // Read bit 4~7 (0xFx)= GP54 ~57 as High. <Leave the Extended Function Mode> WriteByte(AddrPort, 0xAA) Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...
  • Page 81 // Set (bit 0~3) = 1 to select GP 60 ~63 as Output mode. <Output Value> WriteByte(AddrPort, 0x91) // Select configuration register 91h WriteByte(DataPort, Value) // Set bit 0~3=(0/1) to output GP 60~63 as Low or High <Leave the Extended Function Mode> WriteByte(AddrPort, 0xAA) Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...
  • Page 82 7 6 5 4 3 2 1 0 7 6 5 4 3 2 1 0 = DO4 ‐ ‐ ‐ ‐ 1 0 0 0 value 1 0 0 0 ‐ ‐ ‐ ‐ value = DI4 Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...

  • Page 83: Digital I/O (Dio) Hardware Specification

    - Logic 0: Close to GND - Logic 1: Open • Input Voltage: - Logic 0: -3V (Min/D1 to COM+) • 4x Digital Output - Supply Voltage: 5~48V - Sink Current: 1A (Max) - DIO Max: 48V Spectra GmbH & Co. KG User Manual Version 1.31 vertrieb@spectra.de Spectra PowerBox 100  Series November 2020...
  • Page 84 Spectra GmbH & Co. KG Sales Offices Mahdenstr. 3 North PC  06, 10‐31, 38‐39                          Phone +49 (0) 7121 14321‐48 72768 Reutlingen Center PC 32‐37, 40‐54, 56‐59  Phone +49 (0) 7121 14321‐23 Germany Southwest PC 55, 60‐69, 72, 75‐79, 87‐88  Phone +49 (0) 7121 14321‐55 +49 (0) 7121 14321‐0 PC 70‐71, 73‐74, 89 Phone +49 (0) 7121 14321‐80 Phone spectra@spectra.de Southeast PC 01‐04, 07‐09, 80‐86, 90‐99 Phone +49 (0) 7121 14321‐54 E‐Mail www.spectra.de Spectra GmbH & Co. KG Spectra (Schweiz) AG Gewerbepark Ost 1 Flugplatzstr. 5 4621 Sipbachzell (Wels) 8404 Winterthur Austria Switzerland Phone Phone +43 (0) 7240 20190 +41 (0) 43 2771050 E‐Mail E‐Mail info@spectra‐austria.at...
