SPECTRA POWERBOX 410‐
SERIES
USER MANUAL
Version 1.2 – May 2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POWERBOX 410 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Spectra POWERBOX 410 Series

Summary of Contents for Spectra POWERBOX 410 Series

  • Page 1 SPECTRA POWERBOX 410‐ SERIES USER MANUAL Version 1.2 – May 2020...

  • Page 2: Table Of Contents

    3.4.4 Installing the CMOS Battery…..………………..…………………….46 3.4.5 Fasten the Cover…..…………………………….. ………………….. 48 3.4.6 Install an External Fan ..……………………………………….……. 48 Wall Mount Brackets………………………….……………..………………. 51 DIN-Rail Mount Brackets…………….…….……………………………….. 52 VESA Mount ……………………………………………..….………………... 53 Side Mount Brackets………..…………………..……..……………………. 55 Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 3 PB-400-IGN Power Ignition Module Switches Definition and Settings..…. 94 Installing a COM Module………………..………….………..….…….………. 95 Installing a DIO Module………………………...……………….….…………. 97 Installing a LAN Module……….………………...…………………………….. 99 Installing a PoE Daughterboard Module……….…...……………………….. 103 Installing a IGN Power Ignition Module……………...………………………..107 Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 4: Revision

    2020/05/25 Copyright Notice © 2020 by Spectra GmbH & Co. KG. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Spectra GmbH &...

  • Page 5: Product Warranty Statement

    (such as a fuse, battery, etc.), are not warranted. Before sending your product in, you will need to fill in a Spectra RMA Request Form and obtain a RMA number from us. Please go to www.spectra.de/RMA...

  • Page 6: Technical Support And Assistance

    This indication alerts operators to an operation that, if not strictly observed, may result in safety hazards to personnel or damage to equipment. This indication provides additional information to complete a task easily. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 7: Safety Precautions

     The equipment has been dropped and damaged.  The equipment has obvious signs of breakage. 14. CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 8: Package Contents

    Package Contents Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty Spectra PowerBox 410 Rugged Workstation CPU Heatsink Pack Utility DVD Driver Screw Pack Wall Mounting Kit Power Terminal Block Connector Remote Power On/Off Terminal Block Connector Fan Terminal Block Connector DVI‐I to VGA Adaptor Note: Notify your sales representative if any of the above items are missing or damaged.

  • Page 9: Optional Modules & Accessories

    Series CMI Module with 2x RS232/422/485 (Support 5V/12V) / 1x Universal Bracket with 2x DB9 Cutout  PB‐400‐COM‐Set for PowerBox 400/410 Series PB‐400‐MEC‐COM‐M212A‐ Mini‐PCIe Module with 2x RS‐232 Serial Ports, 1x Thin DB9 Cable / 1x Universal Bracket with 2x  DB9 Cutout for PowerBox 400/410 Series PB‐400‐MEC‐COM‐M334A‐ Mini‐PCIe Module with 4x RS‐232/422/485  Serial Ports, 2x Thin DB9 Cable / 2x Universal Bracket  with 2x DB9 Cutout for PowerBox 400/410 Series PB‐400‐MEC‐LAN‐M002‐ Mini‐PCIe Module with 2x LAN Ports, 2x 30cm cable / 1x Universal Bracket with 2x RJ45 Cutout for  PowerBox 400/410 Series Netzteil, 120W/24 V.2 Adapter AC/DC 24V 5A 120W, with 3pin Terminal Block Plug 5.0mm Pitch, with TUBES, level VI PoE‐Netzteil 220W/24V V.2 Adapter AC/DC 24V 9.2A 220W with 3pin Terminal Block Plug 5.0mm Pitch, with TUBES, level VI PB‐400 ext. Lüfter Set External Fan with 4pin Terminal Block Plug and Mounting Bracket, 120 mm, max. 2800U/min. PB‐400‐SIDE‐KIT PowerBox 400/410 Series side mount kit PowerBox 400/410 Series DIN‐RAIL mount kit PB‐400‐DIN Rail Kit Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 10: Chapter 1 Product Introductions

    Chapter 1 Product Introductions...

  • Page 11: Overview

    Featuring rugged construction, fanless/cable-less/jumper-less design, wide operating temperature (-40 to +70°C), wide range DC power input (9~48 VDC), high tolerance to vibration and shock (5/50 Grms), the Spectra PowerBox 410 is maintenance-free and ideal to be deployed in harsh environments.

  • Page 12: Product Pictures

    • Supports CMI Interface for I/O Expandability • Supports PoE+ and Power Ignition Sensing (with optional CFM modules) • Wide Operating Temperature -40°C to 70°C • E-Mark (E13), LVD EN60950-1, EN50155 / EN50121-3-2 Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 13: Hardware Specification

    • 2x 2.5" Front Accessable SATA HDD/SSD Bay (SATA 3.0) • Railway: EN50155, EN50121-3-2, • 3x mSATA Socket (SATA 3.0, shared by Mini-PCIe socket) • In-Vehicle: E-Mark (E13, No. 10R-0515210) • Supports S/W RAID 0, 1, 5 & 10 Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 14: System I/O

    AT/ATX Mode Select Switch Universal I/O Bracket Used to select AT or ATX power mode Used to customized I/O output with optional modules Removable 2.5” SATA HDD/SSD Bay Used to inserts a 2.5” HDD/SSD Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 15: Rear

    Used to connect a DVI monitor or connect Used to customized I/O output with optional optional split cable for dual display mode modules DisplayPort Port Used to connect the system with DisplayPort monitor Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 16: Optional Module Configuration

    PB‐400‐DIO DIO Cutout CMI Module with 2x RS232/422/485 (Support 5V/12V) / 1x  － － － Ｖ PB‐400‐COM Universal Bracket with 2x DB9 Cutout Mini‐PCIe Module with 2x RS‐232 Serial Ports, 1x Thin DB9 Cable  Ｖ Ｖ Ｖ Ｖ PB‐400‐MEC‐COM‐M212A / 1x Universal Bracket with 2x DB9 Cutout Mini‐PCIe Module with 2x RS‐232 Serial Ports, 2x Thin DB9 Cable  Ｖ Ｖ PB‐400‐MEC‐COM‐M334A / 2x Universal Bracket with 2x DB9 Cutout  Mini‐PCIe Module with 2x LAN Ports, 2x 30cm cable / 1x  － － Ｖ － PB‐400‐MEC‐LAN‐M002 Universal Bracket with 2x RJ45 Cutout 1.7 Mechanical Dimension Unit: mm Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 17: Chapter 2 System Pin Definitions And Settings

    Chapter 2 System Pin Definitions and Settings...

  • Page 18: Location Of Switches And Connectors

    2.1 Location of the Connectors and Switches 2.1.1 Top View Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 19: Bottom View

    2.1.2 Bottom View Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 20: Switches And Connectors Definition

    CMI Module to Board Connector BTB_FH2, BTB_FH4 POE LAN Module to Board Connectors IGN_PH1 IGN Module to Board Connector Power 1~3 +5V / +12V Power Output Connectors FS_1 Input Power Fuse 15A Connector LED_B1 System LED Connector Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 21: Definition Of Switches

    ON (Default) COM1 Location Function DIP3 DIP4 0V(RI) ON (Default) ON (Default) COM2 Location Function DIP5 DIP6 0V(RI) ON (Default) ON (Default) COM3 Location Function DIP7 DIP8 0V(RI) ON (Default) ON (Default) COM4 Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 22 SW3: Super CAP Switch Switch Function Super CAP Enable (Default) Disable Reset1: System Reset Button Button Definition Push Reset System CLR_CMOS1: Clear BIOS Switch Definition 1-2 (Left) Normal Status (Default) 2-3 (Right) Clear BIOS Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 23: Definition Of Connectors

    CN3: Mini PCI-Express Socket (Support mPCIE, mSATA, and SIM Module) Definition Definition Definition WAKE# +3.3V +3.3V USB_D+ +3.3V PERST# PERXN/SATARXP +3.3V +1.5V +3.3V PERXP/SATARXN SIM_PWR CLINK_CLK SIM_DATA +1.5V REFCLK- CLINK_DATA SIM_CLK SMB_CLK +1.5V REFCLK+ PETXN/SATATXN CLINK_RESET SIM_RESET SMB_DATA PETXP/SATATXP SIM_VPP1 +3.3V USB_D- Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 24 CN4 / CN6 : Mini PCI-Express Socket (Support mPCIE and mSATA) Definition Definition Definition WAKE# +3.3V +3.3V USB_D+ +3.3V PERST# PERXN/SATARXP +3.3V +1.5V +3.3V PERXP/SATARXN +1.5V REFCLK- SMB_CLK +1.5V REFCLK+ PETXN/SATATXN SMB_DATA PETXP/SATATXP +3.3V USB_D- Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 25 PCM_SYNC/LPCRS RBI_DT WGR_D1N PETN0 PCM_IN CLINK_REST REF_CLK WTD0N/PETP1 PCM_OUT CLINK_DATA WGR_D0N PERP0 WTD0P/PERN1 CLINK_CLK WGR_D0P PERN0 COEX3 PEWAKE1# WTCLK/REFCLKP UART_WAKE COEX_TXD +3.3V WTCLK/REFCLKN WGR_CLKN REFCLKP0 BRI_RSP COEX_RXD +3.3V WGR_CLKP REFCLKN0 SUSCLK PETP2 PERST0# Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 26 Link LED Status Definition Steady Green 1Gbps Network Link Steady Orange 100Mbps Network Link 10Mbps Network Link FAN1: External PWM Fan Connector Connector Type: Terminal Block 1X4 4-pin, 3.5mm pitch Definition +12V SENSE Control Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 27 IGN Enabled Blue ACC ON Green System Temp ≤ 65°C 65°C < Colorless 65°C < System Temp ≤ 70°C Blue TEMP LED 70°C < System Temp ≤ 75°C 75°C < System Temp Blinking Red Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 28: Chapter 3 System Setup

    Chapter 3 System Setup...

  • Page 29: Disassembling The System For Installation

    1. Turn over the unit to have the bottom side face up, loosen the 6 screws of bottom cover and place them aside for later use. 2. Remove the bottom cover from the chassis. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 30 3. Loosen the 4 screws. Pull out 4 latches as marked on photo. 4. Hold front and rear panel and lift up the body of unit vertically. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 31 5. Turn over the body of the unit and place it gently. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 32: Installing Components On Top Side

    1. Locate the CPU socket , remove the protection cover on it. 2. Press the CPU socket lever and pull it aside away from the socket to unlock it. Pull back the lever to open the socket. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 33 3. Align the notches on CPU with the alignment post on socket. 4. The notches of socket provide the space for fingers while lowering the CPU, hold the CPU by the edges toward the notches and insert the CPU gently. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 34 5. Place the thermal pad on the CPU heat spreader. Press down the socket lever to lock the CPU. Thermal pad 6. Align mounting holes of heat sink with the four nut studs. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 35 7. Flip the corner of thermal pad and fasten the heat sink with provided 4 screws.(showing as the picture below) Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 36: Installing So-Dimm Memory

    2. Insert a SO-DIMM module at a 45 degree angle until its edge connector is connected to SO-DIMM socket firmly. 45° 45° Lower socket Upper socket 3. Press down the module until the retaining clips snap back in place. Upper socket Lower socket Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 37: Installing A Mini-Pcie/Msata Card

    2. Insert the Mini-PCIe card at a 45 degree angle until its edge connector is connected firmly into slot. For 3G/4G Mini-PCIe card, please install it onto CN3 slot. 45° 45° CN3,4,6 slot CN3 slot 3. Press down the card and fasten two screws to fix it. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 38: Installing Antennas

    For antenna 3, please pull off the rear panel by loosening the 10 D-Sub jack screws on rear panel firstly, and penetrate the antenna jack through the hole at both sides as illustrated. Antenna 1 Antenna 2 Antenna 3 Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 39 For antenna 3, put on rear panel back and fasten 10 D-Sub jack screws on it, and then put on washer and fasten the nut with antenna jack. 4. Assemble the antenna and antenna jack together 5. Attach the RF connector at another end of cable onto the module. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 40: Assembling The System

    3.3 Assembling the System 3.3.1 Installing Thermal Pad The Spectra PowerBox 410 series don’t need additional installation for the PCH thermal Note: Thermal pad 3.3.2 Installing Top Cover the 4 1. Hold front and rear panel and put the body of unit back to chassis and fasten screws as marked on photo.

  • Page 41: Installing Bottom Cover

    3.3.3 Installing Bottom Cover 1. Place the bottom cover back to system. 2. Fasten the bottom cover with 6 screws . Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 42: Installing Components At Front Side

    Note: It’s advised to fasten the 2 screws manually. If fastened with an electrical screw driver, please set the torque of the driver to 2.5 KgF. 3.4.2 Installing a SATA Hard Drive at Front Side 1. Locate the removable HDD bay and loosen the screw. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 43 3. Make the bottom side of the HDD face up, place the HDD bracket on it. Ensure the direction of bracket is correct and use 4 provided screws to assemble HDD and HDD bracket together. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 44 4. Align the HDD bracket assembly with the entrance of removable HDD bay. Holding the rotating arm and insert the HDD bracket until the connector of HDD contact the SATA connector firmly. 5. Place the rotating arm back and fasten the screw. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 45: Installing A Sim Card

    3.4.3 Installing a SIM Card 1. Locate the SIM card slot at front side. 2. Insert a SIM card into SIM slot with the gold contacts facing up. Please pay attention to the insert orientation as illustrated. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 46: Installing The Cmos Battery

    3.4.4 Installing the CMOS Battery 1. Locate the removable CMOS Battery and loosen the screw. 2. Pull out the CMOS battery bracket with assistance of a tweezer. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 47 3. Insert a CMOS battery in the battery slot. 4. Insert the battery bracket firmly and fasten the screw. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 48: Fasten The Cover

    3.4.5 Fasten the Cover 1. Fasten the cover by using the two screws. 3.4.6 Install an External Fan 1. Prepare an external fan. Loosen the 2 screws halfway on mounting frame before attempting to install it. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 49 2. Slide the FAN into the middle groove of chassis as illustrated. Tighten the 2 screws to fix it onto chassis. 3. Move the fan to the center of chassis. Tighten the 2 screws marked on photo to secure it. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 50 4. Connect the FAN cable to external fan power connector at rear panel. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 51: Wall Mount Brackets

    3.5 Wall Mount Brackets Spectra PowerBox 410 series offers wall mount brackets that customers can install system on the wall in convenient and economical ways. 1. The mounting holes are at the bottom side of system. Use provided 8 screws to fasten the bracket on each side.

  • Page 52: Din-Rail Mount Brackets

    3.6 DIN-Rail Mount Brackets Spectra PowerBox 410 series offers DIN-Rail Mount that customer can install system on the DIN Rail. 1. Please refer to section 3.6 Wall Mount Brackets to install mounting bracket at both sides of system. 2. Fasten 2 DIN rail mounting clips to mounting brackets on both sides with provided 4 screws as illustrated.

  • Page 53: Vesa Mount

    DIN rail. 3.7 VESA Mount Spectra PowerBox 410 series supports VESA mounting that customer can mount system with VESA standards of 75 mm or 100 mm for various usages. Blue circles represent the use for VESA 75 mm.
  • Page 54 1. The following picture illustrates the installation of Spectra PowerBox 410 series on a VESA stand. Align the 4 screw holes of VESA stand with the screw holes on bottom side of system. Fasten 4 screws to fix it. 2. Provided below is mounted with VESA stand.

  • Page 55: Side Mount Brackets

    3.8 Side Mount Brackets Spectra PowerBox 410 series offers Side Mount that customer can install system to the right or left side of wall to create effective of space. 1. The mounting holes are at the bottom of system. Fasten the 8 screws to fix the side mount bracket with system together.
  • Page 56 2. Fasten the screws through the bracket mounting hole to mount system on the wall. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 57 Chapter 4 BIOS Setup...

  • Page 58: Chapter 4 Bios Setup

    ( ↑↓ ) to highlight the field and press <Enter> to call up the sub-menu. Then you can use the control keys to enter values and move from field to field within a sub-menu. If you want to return to the main menu, just press the <Esc >. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 59: Main Setup

    Use arrow keys to move among the items and press <Enter> to accept or enter a sub-menu. 4.2.1 System Date Set the date. Please use <Tab> to switch between date elements. 4.2.2 System Time Set the time. Please use <Tab> to switch between time elements. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 60: Advanced Setup

    4.3 Advanced Setup This section allows you to configure and improve your system and allows you to set up some system features according to your preference. 4.3.1 CPU Configuration Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 61: Sata Configuration

    Configuration options: [All] [1]. 4.3.2 SATA Configuration ■ SATA Controller(s) [Enabled] Enables or disables SATA device. ■ SATA Mode Selection [AHCI] Allows you to select which mode SATA controller will operate. Configuration options: [AHCI], [RAID] Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 62 Enables or disables SATA Port 3. ■ Serial ATA Port 4  Port 4 [Enabled] Enables or disables SATA Port 4. ■ Serial ATA Port 5  Port 5 [Enabled] Enables or disables SATA Port 5. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 63: Pch-Fw Configuration

    4.3.3 PCH-FW Configuration ■ Firmware Update Configuration Configure Engine Management Parameters  Me FW Image Re-Flash Enables or disables ME firmware Image Re-Flash function. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 64: Trusted Computing Settings

    Enables or disables Storage Hierarchy function. ■ Endorsement Hierarchy [Enabled] Enables or disables Endorsement Hierarchy function. ■ Physical Presence Spec Version [1.3] Allows you to select which mode Physical Presence Spec Version will operate. Configuration options: [1.2], [1.3] Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 65: Acpi Settings

    Allows users to select the highest Advanced Configuration Power Interface® (ACPI) sleep state that system will enter when suspend button is pressed. [Suspend Disabled]: Disables entering suspend state. [S3 (suspend to RAM)]: Enables suspend to RAM state. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 66: F81866 Super Io Configuration

    4.3.6 F81866 Super IO Configuration Set Parameters of Serial Ports. User can Enable/Disable the serial port and Select an optimal settings for the Super IO Device ■ Serial Port 1~6 Configuration Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 67: Hardware Monitor

    This screen displays the current status of all the monitored hardware devices/components such as voltages, temperatures and all fans’ speeds. ■ External Smart Fan Function [Enabled] Enables or disables External Smart Fan function. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 68 Configure External Smart Fan Parameters.  Smart Fan Mode [Auto] Allows you to select Smart Fan Mode. Configuration options: [Auto] [Manual]  Fan Speed Mode [RPM] Allows you to select Fan Speed Mode. Configuration options: [RPM] [Duty] Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 69: S5 Rtc Wake Settings

    Enables or disables wake system from S5 (soft-off state). [Disabled]: Disables wake system from S5. [Fixed Time]: Sets a fixed time (HH:MM:SS) to wake system from S5. [Dynamic Time]: Sets a increase minute(s) from current time to wake system from Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 70: Serial Port Console Redirection

    Allow users to enable or disable COM0, COM1, COM2, COM3, COM4, COM5 console redirection function. COM0 = Serial Port 1 COM1 = Serial Port 2 COM2 = Serial Port 3 COM3 = Serial Port 4 COM4 = Serial Port 5 COM5 = Serial Port 6 Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 71: Usb Configuration

    Enables or disables XHCI (USB3.0) hand-off function. Use this feature as a workaround for operating systems without XHCI hand-off support. ■ USB Mass Storage Driver Support [Enabled] Enables or disables USB mass storage driver support. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 72: Network Stack Configuration

    4.3.11 Network Stack Configuration ■ Network Stack [Disabled] Enables or disables UEFI Network Stack. 4.3.12 CSM Configuration This option controls legacy/UEFI ROMs priority. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 73 [Legacy]: Enables legacy option ROM only. ■ Other PCI devices [Do not launch] Allows users to determine option ROM execution policy for devise other than network, storage, or video. Configuration options: [Do not launch] [UEFI] [Legacy] Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 74: Chipset Setup

    4.4 Chipset Setup This section allows you to configure chipset related settings according to user’s preference. 4.4.1 System Agent (SA) Configuration Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 75: Pch-Io Configuration

     Internal Graphics [Auto] Allows users to enable or disable Internal Graphics. Configuration options: [Auto] [Disabled] [Enabled] ■ VT-d [Enabled] Enables or disables Intel® Virtualization Technology for Directed I/O (VT-d) capability. 4.4.2 PCH-IO Configuration Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 76 PCI Express Root Port (mPCIe CN6)  PCI Express Root Port [Enabled] Enables or disables PCI Express Root Port.  PCIeSpeed [Auto] Allows you to select PCI Express port speed. Configuration options: [Auto] [Gen1] [Gen2] [Gen3]. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 77 Allows you to specify which power state system will enter when power is resumed after a power failure (G3 state). [Always on]: Enters to power on state. [Always off]: Enters to power off state. [Keep last state]: Enters to the last power state before a power failure. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 78: Security Setup

    Allows you to set Administrator Password to control access to the BIOS Setup utility. 4.5.2 User Password Allows you to set User Password to control access to the system at boot and to the BIOS Setup utility. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 79: Boot Setup

    Allows you to enable or disable Fast Boot function. If enabled, system boots with initialization of a minimal set of devices required to launch active boot option. 4.6.5 Hard Drive BBS Priority Allows you to set the order of the legacy devices in this group. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 80: Save & Exit

    4.7.8 Save as User Defaults This item allows you to save the changes done so far as user defaults. 4.7.9 Restore User Defaults This item allows you to restore the user defaults to all the setup options. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 81: Product Application

    Chapter 5 Product Application (For DIO only)

  • Page 82: Digital I/O (Dio) Application

    To disable configuration, write exit entry key 0xAA to the index port. Following is an example to enable configuration and disable configuration by using debug. -o 4e 87 -o 4e 87 (enable configuration) -o 4e aa (disable configuration) Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 83 5.1.1.3 Relative Registers To program the F81866A configuration registers, the following configuration procedures. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 84 Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 85 //Set (bit 0~7) = 0 to select GP 70~77 as Input mode. <input Value> WriteByte(AddrPort, 0x82) // Select configuration register 82h ReadByte(DataPort, Value) // Read bit 0~7(0xFx)= GP70 ~77 as High. <Leave the Extended Function Mode> WriteByte(AddrPort, 0xAA) Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 86 // Select configuration register 60h (High Byte address) WriteByte(DataPort, ( 0x0A)) WriteByte(AddrPort, 0x61) // Select configuration register 61h (Low Byte address) WriteByte(DataPort, ( 0x00)) <Leave the Extended Function Mode> WriteByte(AddrPort, 0xAA) default DIO Port base address is set to 0x0A00h Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 87 0 1 0 0 0 0 0 0 Value (Base address +3) (0xA03) 7 6 5 4 3 2 1 0 = DI8 1 0 0 0 0 0 0 0 Value (Base address +3) (0xA03) Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 88 0 1 0 0 0 0 0 0 Value (Base address +2) (0xA02) 7 6 5 4 3 2 1 0 = DO8 1 0 0 0 0 0 0 0 Value (Base address +2) (0xA02) Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 89: Dio) Hardware Specification

    - DO Signal have to pull up resistor to XCOM+ for external device, the resistance will affect the pull up current - Signal High Level : Pull up resistor to XCOM+ - Signal Low Level : = XCOM- - Sink Current: 1A (Max) Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 90: Dio Connector Definition

    DIO1: Digital Input Connector Connector Type: Terminal Block 1X10 10-pin, 3.5mm pitch Definition XCOM+ XCOM- Pin 1 DIO2: Digital Output Connector Connector Type: Terminal Block 1X10 10-pin, 3.5mm pitch Definition XCOM+ XCOM- Pin 1 Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 91 Chapter 6 Optional Modules Pin Definitions and Settings...

  • Page 92: Optional Module Pin Definitions And Settings 6.1 Pb-400-Com Module Connector Definition And Settings

    COM5/6 Voltage Function Setting : Pin Define SW2 Switch Location Function DIP1 DIP2 0V(RI) ON (Default) ON (Default) SW2 on COM5 CMI-COM Module Location Function DIP3 DIP4 0V(RI) ON (Default) ON (Default) SW2 on CMI-COM COM6 Module Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 93: Pb-400-Lan/Poe-M12 Module Connector Definition And Settings

    CMI-M12 LAN Module with CFM-PoE Module Pin Definitions Connector Type: M12 A coded 8pin connector POE type: Midspan (B-Type) Definition Definition 2_LAN1_0+ 2_LAN1_0- 2_LAN1_1+ 2_LAN1_2+(Power PIN) 2_LAN1_2-(Power PIN) 2_LAN1_1- 2_LAN1_3+(Power PIN) 2_LAN1_3-(Power PIN) Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 94: Pb-400-Ign Power Ignition Module Switches Definition And Settings

    Reserved (0 second) Default setting of Pin1 to Pin4 is ON/ON/ON/OFF. 24V_12V_1: IGN Module Voltage Mode Setting Switch 12V / 24V Car Battery Switch Definition 24V Car Battery Input (Default) 12V Car Battery Input Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 95: Installing A Com Module

    6.4 Installing a PB-400-COM Module Model No. Description CMI Module with 2x RS232/422/485 (Support 5V/12V) / 1x Universal  PB‐400‐COM Bracket with 2x DB9 Cutout for PowerBox 400/410 Series 1. Locate the connector of CMI-module on the bottom side of system. 2. Loosen the 2 screws on rear bezel to remove the cover plate Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 96 3. Insert the PB-400-COM module carefully into the CMI connector on main board. Fix it with 2 screws. 4. Loosen the 4 D-Sub jack screws as marked on photo. 5. Attach the COM bracket. Fasten 2 screws and 4 D-Sub jack screws to fix it. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 97: Installing A Dio Module

    6.5 Installing a PB-400-DIO Module Model No. Description CMI Module with 16DIO (8in 8out) / 1xUniversal Bracket with DIO Cutout  PB‐400‐DIO for PowerBox 400/410 Series 1. Locate the connector of PB-400-DIOmodule on the bottom side of system. 2. .Loosen the 2 screws on rear bezel to remove the cover plate Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 98 3. Insert the PB-400-DIO module carefully into the CMI connector on main board. Fix it with 2 screws. 4. Attach the DIO bracket, and fasten 2 screws to fix it. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 99: Installing A Lan Module

    The applicable high speed CMI modules for PowerBox 400/410 series are listed in the following table. Model No. Description CMI Module with 4x Intel I210‐AT GbE LAN, RJ45 Port / 1x Universal Bracket  PB‐400‐LAN  with 4x RJ45 Cutout for PowerBox 400/410 Series CMI Module with M12 Connector, 4x Intel I210‐AT GbE LAN / 1x Universal  PB‐400‐LAN‐M12 Bracket with 4x M12 Cutout for PowerBox 400/410 Series Note: The photo example in this section is illustrated by PB-400-LAN-M12 module as shown in the picture below. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 100 2. Remove 4 rubber rings on M12 jacks; Penetrate M12 jacks of CMI module through the accompanying M12 I/O bracket. then fasten 4 ring hexes onto jacks as illustrated in right hand picture below. Rubber rings Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 101 3. Locate the CMI connector on the top side of system. 4. Exchange screw to copper pillar before insert the CMI module . Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 102 5. Insert the CMI module vertically into the female connector on system’s mainboard until it’s connected firmly and fasten 4 screws to fix it. 6. Fasten 2 screws on cover plate. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 103: Installing A Poe Daughterboard Module

    If you use PB-400-LAN-M12 Module please skip this step. (Note: Do not make the tape block the LED.) 2. Insert the CMI-LAN Module for Spectra PowerBox 410 vertically to the female connector (BTB_FH2 or BTB_FH4) on system’s mainboard until it is connected firmly, and fasten 4 copper pillars to fix it.
  • Page 104 3. Insert the PB-400-PoE Daughterboard module vertically into the female connector on the CMI module until it’s connected firmly. 4. Turn over the heatsink of PB-400-PoE Daughterboard and locate the two places marked by red squares. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 105 5. Paste two thermal pads for PB-400-PoE Daughterboard onto the heatsink carefully. 6. Paste the heatsink onto the PB-400-PoE Daughterboard module carefully and connect the PoE module to the PB-400-LAN-M12 module. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 106 7. Fasten 4 screws to fix it. 8. Paste the last thermal pad onto the heatsink carefully. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...

  • Page 107: Installing A Ign Power Ignition Module

    6.8 Installing a PB-400-IGN Power Ignition Module Model No. Description CFM Module with Power Ignition Sensing Control Function, 12V/24V  PB‐400‐IGN V1.5  Selectable 1. Locate the IGN connector on the bottom side of system. 2. Fasten 1 copper pillar before insert IGN module. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 108 3. Insert PB-400-IGN module vertically to the female connector on the system’s mainboard, and fasten 2 screws to fix it. Spectra GmbH & Co. KG User Manual Version 1.2 vertrieb@spectra.de Spectra PowerBox 410  Series May 2020...
  • Page 109 Spectra GmbH & Co. KG Spectra GmbH & Co. KG Spectra (Schweiz) AG Mahdenstr. 3 Gewerbepark Ost 1 Flugplatzstr. 5 72768 Reutlingen 4621 Sipbachzell (Wels) 8404 Winterthur Germany Austria Switzerland Phone Phone +49 (0) 7121 1432-10 +43 (0) 7240 20190...
