- Page 1 4K 1x2 HDMI Extender and Splitter Model 103102 ♦ Extend signal from an HDMI source to 2 remote displays simultaneously User Manual Download the user manual at: • www.cablematters.com/dl/103102 support@cablematters.com...
-
Page 2: Table Of Contents
4K 1x2 HDMI Extender and 4K 1x2 HDMI Extender and Splitter Table of Contents 1. INTRODUCTION ....................1 1.1 Introduction 1.2 Copyright and Trademarks 1.3 FCC Compliance Statement 2. PRODUCT OVERVIEW 2.1 Package Contents 2.2 Product Description ................2 2.3 Product Features 3. -
Page 3: Introduction
Contact support@cablematters.com for questions or product support. 1.2 Copyright and Trademarks Cable Matters is a registered trademark or trademark of Cable Matters Inc. All rights reserved. All other trademarks are the property of their respective owners. Dolby, Dolby Audio and the double-D symbol are trademarks of Dolby Laboratories. -
Page 4: Product Description
4K 1x2 HDMI Extender and Splitter 2.2 Product Description The Cable Matters 4K 1x2 HDMI Extender and Splitter provides the ideal solution for connecting 2 remote displays with 4K@60hz HDMI video and audio up to 115 feet simultaneously (up to 197 feet at 1080p 60Hz). Extend the signal from a computer, video streamer, Blu-ray player or Cable box to 2 remote displays with HDMI. -
Page 5: Connection And Operation
4K 1x2 HDMI Extender and Splitter 3. CONNECTION AND OPERATION 3.1 Installation Checklist Please review this information before installing the 4K 1x2 HDMI Extender and Splitter Installation with a surge protector is recommended to protect the equipment • Power-off the source and display equipment before connecting •... -
Page 6: Receiver Panel Connections
4K 1x2 HDMI Extender and Splitter 1.EDID DIAL Switch: Used to set EDID mode Please refer to “EDID Management” 2.SERVICE Port: Used for firmware update or serial port command control 3.3 Receiver Panel Connections 1. HDMI OUT: Connect to the remote extended display with HDMI 2. -
Page 7: Edid Management
4K 1x2 HDMI Extender and Splitter 3.5 EDID Management This 4K 1x2 HDMI Extender and Splitter can connect HDMI source equipment and output displays with different video resolutions and audio output settings. These settings can be individually programmed using the EDID management function. EDID EDID Description EDID... -
Page 8: Ir Remote Control
4K 1x2 HDMI Extender and Splitter 3.6 IR Remote Control IR Transmitter (Blaster) Cable IR Receiver Cable IR Transmitter Cable: Connect to the IR-T port on the Transmitter box. Requires line-of-sight with the HDMI source equipment IR window. Tip: Shine a light on the source box to reveal the IR window, if it is not labeled. - Page 9 4K 1x2 HDMI Extender and Splitter Test each HDMI cable by connecting it with other equipment. • Recommended maximum total HDMI cable distance In/Out is 25/25ft. • Connecting an HDMI cable with a coupler or wall plate may • degrade the signal transmission. Place the Extender away from fluorescent lighting or equipment •...
-
Page 10: Technical Specifications
4K 1x2 HDMI Extender and Splitter 4. TECHNICAL SPECIFICATIONS Model 103102 Extender and Splitter Ports (Transmitter and Receiver) HDMI Input 1x HDMI Female HDMI Output 3x HDMI Female CAT Ports RJ45 port for Cat 6 cable IR Ports 1x IR out (Transmitter), 2x IR in (Receiver) -
Page 11: Warranty And Support
5.2 Warranty Information This product is backed by a limited one-year warranty. The warranty covers parts and labor costs only. Cable Matters does not warrant its products from defects or damages arising from misuse, abuse, or normal wear. 5.3 Limitation of Liability In no event shall Cable Matters Inc. - Page 12 4K 1x2 HDMI Extender and Splitter View related products at www.cablematters.com Certified Premium HDMI ® Cable Model 300016 150’ Snagless Cat 6 Patch Cable Model 160001 150’ Shielded Cat 6 Patch Cable Model 160012 www.cablematters.com...
