Goodwe GW15K-ET Quick Manual

Commercial & Industrial Smart Inverter Solutions
ET 15-30kW+Lynx C 60kWh
Quick Guide
The information in this user manual is subject to change due to product updates or other reasons. This guide cannot
replace the product labels or the safety precautions in the user manual unless otherwise specified. All descriptions in
the manual are for guidance only.
01 Networking
Product
Model
Type
GW15K-ET
GW20K-ET
Inverter GW25K-ET
GW29.9K-ET
GW30K-ET
Battery GW60KWH-D-10
system GW60KWH-D-10(Extension)
WARNING
Description
A maximum of 4 inverters can be connected in a
parallel system. Inverter firmware requirements
for parallel connections:
• Consistent firmware version
• ARM version: 08(401) or above
• DSP version: 07(7068) or above
A maximum of 3 battery systems can be clustered
in a system.
Product
Model
Type
V1.0-2024-07-10
Smart • GM3000
meter • GM330
• WiFi/LAN Kit-20
Smart
• Wi-Fi Kit
dongle
• Ezlink3000
02 Power On/Off
Power ON/OFF:
1 2 3 4 5
④ : Optional in compliance with local laws and regulations.
1
Description
• GM3000: GM3000 and the CT, which cannot be
replaced, are included in the inverter package.
CT ratio: 120A/40mA.
• GM330: Order the CT for GM330 from GoodWe
or other suppliers. CT ratio: nA/5A.
• nA: CT primary input current, n ranges from
200 to 5000.
• 5A: CT Secondary input current.
• Use WiFi/LAN Kit-20 or Wi-Fi kit for a single
inverter. Upgrade the firmware of the inverter
before replacing the Wi-Fi kit with a WiFi/LAN
Kit-20 dongle.
• In parallel scenarios, the EzLink3000 must
be connected to the master inverter. Do not
connect any communication module to the
slave inverters. The firmware version of EzLink
should be 04 or above.
