FusionModule500 Smart Mini Data Center
User Manual (02116410, 02116411, 021164112)
3.
Step 2 Set the running parameters and control parameters for the FusionCol5000-A0031
on the WebUI.
1.
2.
3.
4.
Issue 04 (2023-10-31)
Table 5-3 Adding a smart cooling product
Path Parameter
Choose Device
System Attribute
Settings >
Device Type
Device
Management
and click Add
Connect To
Device.
Communicati
ons Port
Device
Address
Click Test Connect to check whether the FusionCol5000-A0031 connects to
the ECC800-Pro properly.
– If the connection is normal, click Confirm. The connected devices are
displayed in the Number of connected devices list.
– If the connection is abnormal, check whether the device is properly
connected to the ECC800-Pro, whether the device and the ECC800-Pro are
running properly, and whether the parameter settings are consistent with
the device parameters.
Log in to the ECC800-Pro WebUI as an administrator.
Choose Monitoring > Cooling > FusionCol5000-A0031.
On the Running Parameters tab page, set smart cooling product running
parameters.
NO TE
On the Running Parameters tab page, you are advised to set Temperature setpoint
to 23°C, Humidity setpoint to 50% RH, Control mode to Cold aisle average value
control, and Cold aisle T/H sensor fault enable and Hot aisle T/H sensor fault
enable to Enable.
On the Controls tab page, set the smart cooling product control parameters
(such as on/off control parameters).
Copyright © Huawei Digital Power Technologies Co., Ltd.
5 Power-On Commissioning
Setting
Select Air Conditioner from the drop-
down list.
Select FusionCol-M from the drop-down
list.
Select ECC800 from the drop-down list.
Select COM2 from the drop-down list.
NOTE
The setting example indicates that the
FusionCol5000-A0031 is connected to the
COM2 port on the ECC800-Pro. If the
FusionCol5000-A0031 is connected to another
port, enter the number of the connected port.
Enter the actual device address of the
FusionCol5000-A0031 during operations.
The default address is 1.
