KA01680P/00/EN/01.23-00
71654585
2024-03-29
Products
Brief Operating Instructions
Deltabar PMD50
Differential pressure measurement
HART
These Instructions are Brief Operating Instructions; they are
not a substitute for the Operating Instructions pertaining to
the device.
Detailed information about the device can be found in the
Operating Instructions and the other documentation:
Available for all device versions via:
• Internet:
www.endress.com/deviceviewer
• Smart phone/tablet: Endress+Hauser Operations App
Solutions
Services
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Endress+Hauser Deltabar PMD50
Summary of Contents for Endress+Hauser Deltabar PMD50
- Page 1 Operating Instructions pertaining to the device. Detailed information about the device can be found in the Operating Instructions and the other documentation: Available for all device versions via: • Internet: www.endress.com/deviceviewer • Smart phone/tablet: Endress+Hauser Operations App...
-
Page 2: Associated Documentation
Associated documentation Deltabar PMD50 HART Associated documentation Order code: XXXXX-XXXXXX Ser. no.: XXXXXXXXXXXX Ext. ord. cd.: XXX.XXXX.XX Serial number www.endress.com/deviceviewer A0054002 About this document Document function The Brief Operating Instructions contain all the essential information from incoming acceptance to initial commissioning. - Page 3 Deltabar PMD50 HART About this document This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in serious or fatal injury. WARNING This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in serious or fatal injury.
-
Page 4: Basic Safety Instructions
The manufacturer is not liable for damage caused by improper or non-intended use. Verification for borderline cases: ‣ For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in verifying the corrosion resistance of fluid-wetted materials, but does not accept any warranty or liability. -
Page 5: Operational Safety
IT security Endress+Hauser can only provide a warranty if the device is installed and used as described in the Operating Instructions. The device is equipped with security mechanisms to protect it against any inadvertent changes to the device settings. IT security measures in line with operators' security standards and designed to provide additional protection for the device and device data transfer must be implemented by the operators themselves. -
Page 6: Device-Specific It Security
• Do the data on the nameplate correspond to the order specifications and the delivery note? • Is the documentation available? • If required (see nameplate): are the Safety Instructions (XA) provided? If you can answer "no" to any of these questions, please contact Endress+Hauser. Storage and transport 4.2.1 Storage conditions •... -
Page 7: Mounting Requirements
• To ensure optimum readability of the onsite display, align the housing and local display • Endress+Hauser offers a mounting bracket for installing the device on pipes or walls • For measurements in media containing solids (e.g. dirty liquids), it makes sense to install separators and drain valves. -
Page 8: Mounting The Device
Mounting Deltabar PMD50 HART 5.1.3 Installing pressure piping • For recommendations for routing pressure piping, refer to DIN 19210 "Differential pressure piping for flow measurement devices" or the corresponding national or international standards • When routing the pressure piping outdoors, ensure sufficient anti-freeze protection, e.g. by using pipe heat tracing •... - Page 9 Deltabar PMD50 HART Mounting Level measurement in a closed vessel with superimposed vapor • Mount the device below the lower measuring connection so that the impulse lines are always filled with liquid. • Always connect the low-pressure side above the maximum level •...
-
Page 10: Electrical Connection
Electrical connection Deltabar PMD50 HART Electrical connection Connecting requirements 6.1.1 Potential equalization The protective ground on the device must not be connected. If necessary, the potential matching line can be connected to the outer ground terminal of the device before the device is connected. -
Page 11: Connecting The Device
Deltabar PMD50 HART Electrical connection Connecting the device A0054035 Connection compartment cover Housing thread The threads of the electronics and connection compartment can be coated with an anti- friction coating. The following applies for all housing materials: Do not lubricate the housing threads. - Page 12 6.2.6 Overvoltage protection Devices without optional overvoltage protection Equipment from Endress+Hauser fulfills the requirements of the product standard IEC/DIN EN 61326-1 (Table 2 Industrial Environment). Depending on the type of port (DC power supply, input/output port) different testing levels according to IEC/DIN EN 61326-1 against transient overvoltages (Surge) are applied (IEC/DIN...
- Page 13 Deltabar PMD50 HART Electrical connection 6.2.7 Wiring WARNING Supply voltage might be connected! Risk of electric shock and/or explosion! ‣ When operating the device in hazardous areas, ensure compliance with national standards and the specifications outlined in the Safety Instructions (XAs). Use the specified cable gland.
- Page 14 Electrical connection Deltabar PMD50 HART 6.2.8 Terminal assignment Dual-compartment housing A0054036 Internal ground terminal Positive terminal Negative terminal Interlock diode: An interlock diode is used for uninterrupted measurement of the output signal. 6.2.9 Cable entries A0054037 Cable entry Dummy plug The type of cable entry depends on the device version ordered.
-
Page 15: Ensuring The Degree Of Protection
Deltabar PMD50 HART Operation options Ensuring the degree of protection 6.3.1 Cable entries • Gland M20, plastic, IP66/68 TYPE 4X/6P • Gland M20, brass nickel plated, IP66/68 TYPE 4X/6P • Gland M20, 316L, IP66/68 TYPE 4X/6P • Thread M20, IP66/68 TYPE 4X/6P •... - Page 16 Commissioning Deltabar PMD50 HART Access via color display (optional) and magnetic button Functions that can be executed with the magnetic button: • Zero point and span • Turning the display • Position adjustment • Resetting user role password • Device reset The brightness of the color display is adjusted depending on the supply voltage and the current consumption.
-
Page 17: Setting The Operating Language
Deltabar PMD50 HART Commissioning WARNING Process pressure above or below permitted maximum/minimum! Risk of injury if parts burst! Warnings are displayed if the pressure is too high. ‣ If a pressure smaller than the minimum permitted pressure or greater than the maximum permitted pressure is present at the device, a message is output. - Page 18 Commissioning Deltabar PMD50 HART Setting the lower range value (pressure or scaled variable) The desired pressure for the lower range value is present at the device. Press "Zero" for at least 3 seconds. After "done" appears on the color display, the applied pressure is accepted for the lower range value.
- Page 19 Perform a position adjustment if necessary. • In the Assign PV parameter, the Pressure option must be selected (factory setting). DeviceCare is available for download at www.software-products.endress.com. To download the software, it is necessary to register on the Endress+Hauser software portal. Endress+Hauser...
- Page 20 Commissioning Deltabar PMD50 HART – [mA] 450 mbar 20 mA 50 mbar 4 mA [mbar] A0054186 Lower range value output Upper range value output Adjustment: Enter the pressure value for the 4 mA current via the Lower range value output parameter (50 mbar (0.75 psi)).
- Page 21 Deltabar PMD50 HART Commissioning 8.3.3 Commissioning without the commissioning wizard Example: Commissioning a volume measurement in the tank Pressure and temperature units are converted automatically. Other units are not converted. In the following example, the volume in a tank should be measured in liters. The maximum volume of 1 000 l (264 gal) corresponds to a pressure of 450 mbar (6.75 psi).
- Page 22 Commissioning Deltabar PMD50 HART Enter the pressure value for the upper calibration point via the Pressure value 2 parameter: 450 mbar (6.75 psi) Menu path: Application → Sensor → Scaled variable → Pressure value 2 Enter the volume value for the upper calibration point via the Scaled variable value 2 parameter: 1 000 l (264 gal) ...
- Page 24 *71654585* 71654585 www.addresses.endress.com...
