- Page 1 2.0 Channel Soundbar MODEL: ASBBT-0724 User Manual AFTER SALES SUPPORT tempo.org/support 1300 002 534 MODEL: ASBBT-0724 PRODUCT CODE: 716651 7/2024...
-
Page 2: Welcome
Welcome Congratulations on your purchase! This manual tells you all you need to know about using your new BAUHN product. ® Please take special note of any important safety and usage information presented with the symbol. All products brought to you by BAUHN are manufactured to the highest standards of performance and safety and, ®... -
Page 3: Table Of Contents
Contents Welcome Operation General Operation Unpack and Prepare Input Modes What's in the box Function Display Wall Mount Installation Kit Pairing Bluetooth® Devices Important Tips Troubleshooting Installation - Free Standing Installation - Wall Mounted Specifications Wall Mounting Instructions Compliance and Responsible Disposal Connect to Power Warranty Information Controls and Connections... -
Page 4: Unpack And Prepare
Unpack and Prepare What's in the box Before setting up your new Soundbar, check you have everything: A. 2.0 Channel Soundbar B. Remote Control C. AAA Activ Energy Batteries D. 3.5mm Audio Cable E. Wall Mount Installation Kit (See next page for more information.) F. -
Page 5: Wall Mount Installation Kit
Wall Mount Installation Kit The illustration below shows the contents of the wall mount installation kit. These are the parts you will need when wall mounting the soundbar. Some parts are not shown at the same scale. Note: If you choose to wall mount the soundbar, it is recommended to use an HDMI adapter in order to fit properly. 1. -
Page 6: Installation - Free Standing
Installation - Free Standing This soundbar can sit free-standing on a surface, or it can be mounted to a wall. Place on a secure, flat surface. Make sure the soundbar is standing on its rubber pads (on the left and right sides of the soundbar) and no other area of the bottom of the soundbar is touching the surface. -
Page 7: Installation - Wall Mounted
Installation - Wall Mounted Wall mounting instructions are on the following pages. • Wall mounted installation must be carried out by qualified personnel only. Incorrect assembly can result in severe personal injury and property damage! If you intend to install this product yourself, you must check for installations such as electrical wiring and plumbing, which may be hidden inside or behind the wall. -
Page 8: Wall Mounting Instructions
Wall Mounting Instructions Keyholes ASBBT-0724 / 716651 PO BOX 6097, North Sydney NSW 2059 Australia PLU 20938 07/2024B arcode 4061463405111 Made in China DANGEROUS VOLTAGE INSIDE CAUTION DO NOT REMOVE THE COVER. INTERNAL ADJUSTMENTS SHOULD ONLY BE MADE BY A QUALIFIED TV TECHNICIAN... -
Page 9: Connect To Power
Connect to Power Make sure the power switch is switched off at the power outlet until you have finished connecting your cables. ASBBT-0724 / 716651 PO BOX 6097, North Sydney NSW 2059 Australia 07/2024B arcode 4061463405111 PLU 20938... -
Page 10: Controls And Connections
Controls and Connections Get to know your Soundbar Front view LED display and remote control sensor Buttons on the Soundbar (POWER/SOURCE): Press and hold the power button about 1.5s to turn on/off the soundbar. Once switched on, press the power button momentarily to switch between input sources. -
Page 11: Rear Ports On The Soundbar
Rear Ports on the Soundbar The ARC (Audio Return Channel) function allows you to send audio HDMI (ARC) input from an ARC-compliant TV to an ARC-compliant audio device SOUND (e.g. soundbar) without the need for an additional audio cable connection. Connect an Optical audio cable (not included) to the OPTICAL OUT OPTICAL SOUND... - Page 12 Rear Ports on the Soundbar HDMI (ARC) To use the ARC function, make sure the soundbar's HDMI (ARC) socket is connected via a HDMI cable (not included) to the HDMI (ARC) socket of your ARC compliant TV. Then just use your TV's remote control to adjust the volume output (VOL +/–...
-
Page 13: Remote Control
Remote Control Setup Insert two AAA size batteries according to the polarity markings (+ / -) inside the compartment. Make sure the batteries are correctly aligned and properly pushed into AAA size place. batteries included Precautions When Using Batteries • Do not use old and new batteries together. •... -
Page 14: Using The Remote Control
Using the Remote Control To use the remote control, point it towards the remote control sensor at the front of the soundbar. The remote control will not operate if its path is blocked. The remote control has a range of up to about 6 metres from the soundbar at an angle of up to 30 degrees to either side of the sensor, as illustrated below. -
Page 15: Remote Control Overview
Remote Control Overview INPUT (POWER): Switch the soundbar on or standby INPUT: Switch between the input sources Mute the sound : Skip to the next track VOL +: Increase the volume level : Start or pause playback : Skip to the previous track News sound effect VOL - : Decrease the volume level USB playback repeat mode... -
Page 16: Operation
Operation General Operation Function Action Press and hold the power button about 1.5s to turn on/off the soundbar. Once switched on, press the power Turn the Soundbar On/ button to switch the input source. Once switched on, press the power button twice to enable/disable sound playback. -
Page 17: Input Modes
Input Modes Function Display Input Display Function Display HDMI ARC Volume Bluetooth Mute LED display flashes ® Optical EQ Music Coaxial EQ Movie EQ News 3D Surround 3D Surround USB repeat mode Note: Press the LED button of the remote USB repeat mode control to switch on/off the display. -
Page 18: Pairing Bluetooth Devices
® mode automatically. it to search for compatible devices. Select 'BAUHN ASBBT-0724' from the list of found devices. If a mobile phone on which you are playing music Note: Only one playback unit can be connected to receives a call, the music will be interrupted. -
Page 19: Troubleshooting
Troubleshooting If you have problems with the soundbar, check below for advice. If you don't find a solution here, contact After Sales Support on 1300 002 534. Problem Solution • Ensure that the AC power is properly connected. No power •... - Page 20 Problem Solution • Make sure the input source is set to ARC. • Make sure your TV or external device supports ARC function and connect the HDMI ARC cable to the ARC port of the TV or external device. No sound in HDMI ARC •...
-
Page 21: Specifications
Speaker output 4 x 15W Bluetooth pairing operation ® Up to 10 metres range – distance Bluetooth pairing name BAUHN ASBBT-0724 ® For Technical Support: DC 5V, 100mA (for 1300 002 534 USB output playback only, not for charging devices) tempo.org/support... -
Page 22: Compliance And Responsible Disposal
Compliance and Responsible Disposal Packaging Compliance The packaging of your product has been This product complies with the Australian Safety selected from environmentally friendly Standard AS/NZS 62368.1 to ensure the safety of the materials and can usually be recycled. Please ensure product. -
Page 23: Warranty Information
Warranty Information The product is guaranteed to be free from defects in workmanship and parts for a period of 12 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion, solely at our option with no charge for parts and labour. -
Page 24: Repair And Refurbished
Repair and Refurbished Goods or Parts Notice Unfortunately, sometimes faulty products are manufactured, which need to be returned to the supplier for repair. Please be aware that if your product is capable of retaining user-generated data (such as files stored on a computer hard drive, telephone numbers stored on a mobile telephone, songs stored on a portable media player, games saved on a games console or files stored on a USB memory stick) during the process of repair, some or all of your stored data may be lost. - Page 25 Notes...
- Page 26 Notes...
- Page 27 Notes...
- Page 28 Online support Visit bauhn.com.au for software updates to keep your soundbar up-to-date, as well as the latest User Manual for information on the updated features. Warranty returns tempo.org/support Should you for any reason need to return this product for a warranty claim, make sure to include all accessories with the product.
