Summary of Contents for Bauhn ASBBS-0922
- Page 1 2.1 Channel Soundbar with Built-In Subwoofer MODEL: ASBBS-0922 User Manual AFTER SALES SUPPORT tempo.org/support 1300 002 534 MODEL: ASBBS-0922 PRODUCT CODE: 709821 09/2022...
-
Page 2: Welcome
Welcome Congratulations on your purchase! This manual tells you all you need to know about using your new BAUHN product. ® Please take special note of any important safety and usage information presented with the symbol. All products brought to you by BAUHN are manufactured to the highest standards of performance and safety and, ®... -
Page 3: Table Of Contents
Contents Welcome Operation General Operation Unpack and Prepare Input Modes What's in the Box Bluetooth ® Wall Mount Installation Kit Installation Pairing Bluetooth Devices ® Wall Mounting Instructions Bluetooth Playback ® Connect to Power Troubleshooting Controls and Connections Specifications Get to know your Soundbar Compliance and Responsible Disposal Buttons on the Soundbar Rear Ports on the Soundbar... -
Page 4: Unpack And Prepare
Unpack and Prepare What's in the Box Before setting up your new Soundbar, check you have everything: A. 2.1 Channel Soundbar B. Remote Control C. AAA Activ Energy Batteries (2) D. 3.5mm Audio Cable E. Optical Cable F. Wall Mount Installation Kit G. -
Page 5: Wall Mount Installation Kit
Wall Mount Installation Kit The illustration below shows the contents of the wall mount installation kit. These are the parts you will need if wall mounting your soundbar. • Place the Soundbar on a level surface. • Place the Soundbar away from any source that may generate heat or vibrations. -
Page 6: Installation
Installation This soundbar can sit free-standing on a surface, or it can be mounted to a wall. Place on a secure, flat surface. Make sure the soundbar is standing on its rubber pads (on the left and right sides on the bottom of the soundbar) and no other area of the bottom of soundbar is touching the surface. - Page 7 Wall mounting instructions are on the following pages. • Wall-mounted installation must be carried out by qualified personnel only. Incorrect assembly can result in severe personal injury and property damage! If you intend to install this product yourself, you must check for installations such as electrical wiring and plumbing, which may be hidden inside or behind the wall.
-
Page 8: Wall Mounting Instructions
Wall Mounting Instructions Use a pencil to make drill hole marks on the wall for the anchors. Make sure the marks are level before drilling. Use a 6mm bit and power drill (not supplied) to drill holes on the marks. 8 | UNPACK AND PREPARE... - Page 9 Insert plastic anchors into the holes and push in until they are flush with the wall. Drive the screws into the plastic anchors and tighten until the screw head is approximately 3mm from the wall. Slide the soundbar onto the screws which are fixed to the wall.
-
Page 10: Connect To Power
Connect to Power Make sure the soundbar is switched off at the power outlet until you have finished connecting your cables. Don't forget to plug in the soundbar to the power outlet. Leave the power switched off until installation is finished. 10 | UNPACK AND PREPARE... -
Page 11: Controls And Connections
Controls and Connections Get to know your Soundbar Front LED display Good to know: The LED display on the soundbar will turn off automatically after 5 minutes of no operation. Buttons on the Soundbar : Decrease the volume level. (Power button/Mode): Press to turn on. Press to select your preferred input source. -
Page 12: Rear Ports On The Soundbar
Rear Ports on the Soundbar Connect an optical cable (included) to the OPTICAL OUT socket OPTICAL SOUND of your device (e.g. TV, DVD player) and the OPTICAL socket on the soundbar. Connect a coaxial cable (not included) to the COAXIAL OUT COAXIAL SOUND socket of your device (e.g. - Page 13 Play your stored media files (supported file codecs and STORAGE extensions may vary). Before connecting the AC adaptor, ensure you have completed DC IN all other connections. POWER Connect the adaptor to the soundbar's DC IN socket first, then plug in the adaptor to the mains supply socket. TO TV (ARC) The ARC (Audio Return Channel) function allows you to send audio input from an ARC-compliant TV to an ARC-compliant...
- Page 14 Rear Ports on the Soundbar HDMI (ARC) To use the ARC function, make sure the soundbar's TO TV (ARC) socket is connected via HDMI cable (not included) to the HDMI (ARC) socket of your ARC compliant TV. Then just use your TV remote control to adjust the volume output (VOL +/–...
-
Page 15: Remote Control
Remote Control Setup Insert two AAA size batteries according to the polarity markings (+ / -) inside the compartment. Make sure the batteries are correctly aligned and properly pushed into AAA size place. batteries included Precautions When Using Batteries • Do not use old and new batteries together. •... -
Page 16: Using The Remote Control
Using the Remote Control To use the remote, point it towards the remote sensor at the front of the soundbar. The remote will not operate if its path is blocked. The remote has a range of up to about 6 metres from the soundbar at an angle of up to 30 degrees to either side of the sensor, as illustrated below. -
Page 17: Remote Overview
Remote Overview MODE (POWER): Switch the soundbar on or standby. : Mute the sound. MODE: Switch between the input : Skip to the next track. sources. : Start or pause playback. : Increase the volume level. TREBLE +: Increase the treble. TREBLE : Skip to the previous track BASS +: Increase the bass. -
Page 18: Operation
Operation General Operation Input Modes Function Action Input Display Press the button on the HDMI (ARC) right side of the soundbar, or Turn the soundbar ON press the (POWER) button on Bluetooth ® the remote control to switch the soundbar on. Optical Press and hold the button... -
Page 19: Bluetooth
® it to search for compatible devices. Select the speaker name: 'BAUHN ASBBS-0922' from the list of found devices. If a mobile phone on which you are playing music Note: Only one playback soundbar can be connected receives a call, the music will be interrupted. -
Page 20: Bluetooth ® Playback
Bluetooth Playback ® Function Action Increase the Volume Press the button on the soundbar or on the remote. Decrease the Volume Press the button on the soundbar or on the remote. Play/Pause Press on the remote. Skip/Rewind Press on the remote to skip/rewind tracks. Un-pair a Bluetooth ®... -
Page 21: Troubleshooting
Troubleshooting If you have problems with the soundbar, check below for advice. If you don't find a solution here, contact After Sales Support on 1300 002 534. Problem Solution • Ensure that the power adaptor is properly connected. No power •... - Page 22 Problem Solution • Make sure the input source is set to ARC; the LED will display 'ARC'. • Make sure your TV or external device supports ARC function and connect the HDMI cable to the ARC port of the TV or external device. •...
-
Page 23: Specifications
Bluetooth pairing operation range tempo.org/support Up to 10 metres – distance Distributed by Tempo (Aust) Pty Ltd, Bluetooth pairing name BAUHN ASBBS-0922 PO Box 132, Frenchs Forest NSW 1640 Bluetooth pairing password 0000 Bluetooth version DC 5V, 200mA (for USB output... -
Page 24: Compliance And Responsible Disposal
Compliance and Responsible Disposal Packaging Compliance The packaging of your product has been This product complies with the Australian Safety selected from environmentally friendly Standard AS/NZS 62368.1 to ensure the safety of the materials and can usually be recycled. Please ensure product. -
Page 25: Warranty Information
Warranty Information The product is guaranteed to be free from defects in workmanship and parts for a period of 12 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion, solely at our option with no charge for parts and labour. -
Page 26: Repair And Refurbished Goods Or Parts Notice
Repair and Refurbished Goods or Parts Notice Unfortunately, sometimes faulty products are manufactured, which need to be returned to the supplier for repair. Please be aware that if your product is capable of retaining user-generated data (such as files stored on a computer hard drive, telephone numbers stored on a mobile telephone, songs stored on a portable media player, games saved on a games console or files stored on a USB memory stick) during the process of repair, some or all of your stored data may be lost. - Page 27 Notes...
- Page 28 Online support Visit bauhn.com.au for software updates to keep your soundbar up-to-date, as well as the latest User Manual for information on the updated features. Warranty returns tempo.org/support Should you for any reason need to return this product for a warranty claim, make sure to include all accessories with the product.
