2.1 Premium Bluetooth
with Wireless Subwoofer
MODEL: ASBWS-0321-B, ASBWS-0321-S
User Manual
AFTER SALES SUPPORT
1300 886 649
AUS
®
Soundbar
MODEL: ASBWS-0321-B, ASBWS-0321-S PRODUCT CODE: 705271 03/2021
info@tempo.org

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASBWS-0321-B and is the answer not in the manual?

Questions and answers

Summary of Contents for Bauhn ASBWS-0321-B

  • Page 1 ® 2.1 Premium Bluetooth Soundbar with Wireless Subwoofer MODEL: ASBWS-0321-B, ASBWS-0321-S User Manual AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: ASBWS-0321-B, ASBWS-0321-S PRODUCT CODE: 705271 03/2021...
  • Page 2: Welcome

    Welcome Congratulations on your purchase! This manual tells you all you need to know about using your new BAUHN ® product. Please take special note of any important safety and usage information presented with the symbol. All products brought to you by BAUHN ®...
  • Page 3: Table Of Contents

    Contents Welcome Operation General Operation Unpack and Prepare Input Modes What's in the Box Bluetooth ® Wall Mount Installation Kit Installation Pairing Bluetooth ® Devices Wall Mounting Instructions Bluetooth ® Playback Connect to Power Troubleshooting Controls and Connections Specifications Get to know your Soundbar Compliance and Responsible Disposal Buttons on the Soundbar Rear Ports on the Soundbar...
  • Page 4: Unpack And Prepare

    Unpack and Prepare What's in the Box Before setting up your new Soundbar, check you have everything: A. 2.0 Channel Soundbar B. Wireless Subwoofer C. Remote Control D. AAA Activ Energy Batteries (2) E. 3.5mm Audio Cable F. Optical Cable G.
  • Page 5: Wall Mount Installation Kit

    Wall Mount Installation Kit The illustration below shows the contents of the wall mount installation kit. These are the parts you will need if wall mounting your soundbar. • Place the Soundbar on a level surface. • Place the Soundbar away from any source that may generate heat or vibrations.
  • Page 6: Installation

    Installation This soundbar can sit free-standing on a surface, or it can be mounted to a wall. Note: The subwoofer cannot be wall mounted. Place on a secure, flat surface. Make sure the soundbar is standing on its rubber pads (on the left and right sides on the bottom of the soundbar) and no other area of the bottom of soundbar is touching the surface.
  • Page 7 Wall mounting instructions are on the following pages. • Wall-mounted installation must be carried out by qualified personnel only. Incorrect assembly can result in severe personal injury and property damage! If you intend to install this product yourself, you must check for installations such as electrical wiring and plumbing, which may be hidden inside or behind the wall.
  • Page 8: Wall Mounting Instructions

    Wall Mounting Instructions Fix the supplied wall-mounting brackets (marked with "S") to the bracket fixing holes on the back of the soundbar with the supplied short screws. Affix the brackets as shown in the illustration (left). 350mm Use a pencil to make drill hole marks on the wall for the anchors.
  • Page 9 Insert the included plastic anchors into the holes and push in until they are flush with the wall. Secure the supplied metal brackets (marked with "W") to the wall by screwing the included long screws into the anchors and tighten until the screw head is fully inserted and flush with the metal bracket.
  • Page 10: Connect To Power

    Connect to Power Make sure the power switch is switched off at the power outlet until you have finished connecting your cables. Don't forget to plug in the soundbar to the power outlet. Leave the power switched off until installation is finished. 10 | UNPACK AND PREPARE...
  • Page 11: Controls And Connections

    Controls and Connections Get to know your Soundbar Front Remote control sensor LED display Good to know: The LED display on the soundbar will turn off automatically after 5 minutes of no operation. Buttons on the Soundbar : Decrease the volume level. (Power button/Mode): Press to turn on.
  • Page 12: Rear Ports On The Soundbar

    Rear Ports on the Soundbar The ARC (Audio Return Channel) function allows you to send audio HDMI OUT input from an ARC-compliant TV to an ARC-compliant audio device SOUND TO TV (ARC) (e.g. soundbar) without the need for an additional 3.5mm audio cable connection.
  • Page 13 Rear Ports on the Soundbar HDMI (ARC) To use the ARC function, make sure the soundbar's HDMI (ARC) socket is connected via a HDMI cable (not included) to the HDMI (ARC) socket of your ARC compliant TV. Then just use your TV's remote control to adjust the volume output (VOL +/–...
  • Page 14: Wireless Subwoofer

    Wireless Subwoofer 1. Connection indicator 2. Power button: Turn subwoofer on/off by flicking the button 3. Power cord: Connect to power Pairing the Wireless Subwoofer With the Soundbar Automatically • The subwoofer and soundbar will automatically pair when they are both plugged into the mains sockets and turned on.
  • Page 15 Pairing the Wireless Subwoofer With the Soundbar Manually • If the subwoofer cannot connect to the soundbar automatically on first time use, please manually pair through the following steps below: 1. Ensure the soundbar is powered on and the subwoofer is off. Press and hold the MODE button on the remote control for 5 seconds until "PAIR"...
  • Page 16: Remote Control

    Remote Control Setup Insert two AAA size batteries according to the polarity markings (+ / -) inside the compartment. Make sure the batteries are correctly aligned and properly pushed into AAA size place. batteries included Precautions When Using Batteries • Do not use old and new batteries together. •...
  • Page 17: Using The Remote Control

    Using the Remote Control To use the remote, point it towards the remote sensor at the front of the soundbar. The remote will not operate if its path is blocked. The remote has a range of up to about 6 metres from the soundbar at an angle of up to 30 degrees to either side of the sensor, as illustrated below.
  • Page 18: Remote Overview

    Remote Overview MODE (POWER): Switch the soundbar on or standby : Mute the sound MODE: Switch between the input : Skip to the next track sources : Start or pause playback : Increase the volume level TREBLE TREBLE +: Increase the treble : Skip to the previous track BASS +: Increase the bass : Decrease the volume level...
  • Page 19: Operation

    Operation General Operation Input Modes Function Action Input Display Press the button on the right HDMI (ARC) side of the soundbar, or press the Turn the soundbar ON (POWER) button on the remote control to switch the soundbar on. Bluetooth ®...
  • Page 20: Bluetooth

    Select 'BAUHN ASBWS-0321' from the list of found devices. If a mobile phone on which you are playing music Note: Only one playback unit can be connected to receives a call, the music will be interrupted.
  • Page 21: Bluetooth ® Playback

    ® Bluetooth Playback Function Action Increase the Volume Press the button on the soundbar or on the remote. Decrease the Volume Press the button on the soundbar or on the remote. Play/Pause Press on the remote. Skip/Rewind Press on the remote to skip/rewind tracks. Un-pair a Bluetooth ®...
  • Page 22: Troubleshooting

    Troubleshooting If you have problems with the soundbar, check below for advice. If you don't find a solution here, contact After Sales Support on 1300 886 649. Problem Solution • Ensure that the power adaptor is properly connected. No power •...
  • Page 23 Problem Solution • Make sure the input source is set to ARC; the LED will display 'ARC'. • Make sure your TV or external device supports ARC function and connect the HDMI cable to the ARC port of the TV or external device. •...
  • Page 24 Problem Solution • Make sure the LED screen is displaying 'AUX'. Turn up the volume on the soundbar. No sound in AUX IN mode • Turn up the volume on the external device and make sure it’s not paused or muted. •...
  • Page 25: Specifications

    Bluetooth pairing W: www.tempo.org operation range – Up to 10 metres E: info@tempo.org distance Distributed by Tempo (Aust) Pty Ltd, Bluetooth pairing BAUHN ASBWS-0321 PO Box 6056, Frenchs Forest DC 2086 name Bluetooth pairing 0000 password Bluetooth version SPECIFICATIONS | 25...
  • Page 26: Compliance And Responsible Disposal

    Compliance and Responsible Disposal Compliance Packaging This product complies with the Australian Safety The packaging of your product has been selected from environmentally friendly Standard AS/NZS 60065 to ensure the safety of the materials and can usually be recycled. Please ensure product.
  • Page 27: Warranty Information

    Warranty Information The product is guaranteed to be free from defects in workmanship and parts for a period of 12 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion, solely at our option with no charge for parts and labour.
  • Page 28: Repair And Refurbished Goods Or Parts Notice

    Repair and Refurbished Goods or Parts Notice Unfortunately, sometimes faulty products are manufactured, which need to be returned to the supplier for repair. Please be aware that if your product is capable of retaining user-generated data (such as files stored on a computer hard drive, telephone numbers stored on a mobile telephone, songs stored on a portable media player, games saved on a games console or files stored on a USB memory stick) during the process of repair, some or all of your stored data may be lost.
  • Page 29 Notes...
  • Page 30 Notes...
  • Page 31 Notes...
  • Page 32 Online support Visit www.bauhn.com.au for software updates to keep your soundbar up-to-date, as well as the latest User Manual for information on the updated features. Warranty returns Should you for any reason need to return this product for a warranty claim, make sure to include all accessories with the product.
