Summary of Contents for Bauhn SoundMax
- Page 1 SoundMax Soundbar Model Number: USMSB-1117 INSTRUCTION MANUAL info@tempo.org 1300 886 649 Model: USMSB-1117 Product Code: 702719 06/2020...
-
Page 2: Welcome
Welcome Congratulations on choosing to buy a BAUHN product. ® All products brought to you by BAUHN are manufactured to the highest standards ® of performance and safety and, as part of our philosophy of customer service and satisfaction, are backed by our comprehensive 3 Year Warranty. -
Page 3: Table Of Contents
Contents Welcome General Safety Instructions Warranty Details Remote Control Product Overview Controls and Connections Installation Instructions Troubleshooting Specifications Repair and Refurbished Goods or Parts Notice Correct Disposal info@tempo.org 1300 886 649 Model: USMSB-1117 Product Code: 702719 06/2020... -
Page 4: General Safety Instructions
General Safety Instructions Read this manual thoroughly before first use and keep it in a safe place for future reference. Follow instructions and take notice of all warnings to reduce risk of fire or electric shock. This product complies with Australian Safety standard AS/NZS 60065 to ensure the safety of the product. - Page 5 General Safety Instructions (Cont.) Usage conditions and restrictions • Instructions: Follow the instructions in this manual when installing and adjusting this equipment. Only adjust those controls that are covered in this instruction manual, as improper adjustment of other controls may result in damage. If this happens, unplug the equipment and have it serviced by appropriately qualified personnel.
-
Page 6: Warranty Details
SoundMax Soundbar REGISTER YOUR PURCHASE AT www.aldi.com.au/en/about-aldi/product-registration TO KEEP UPDATED WITH IMPORTANT PRODUCT INFORMATION The product is guaranteed to be free from defects in workmanship and parts for a period of 36 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion. -
Page 7: Remote Control
Remote Control POWER: Switch the unit between on and standby mode. MUTE: Silences the Soundbar VOL+: Increase the volume level. VOL-: Decrease the volume level. PREVIOUS: Press to go to the previous track in both Bluetooth and Wi-Fi mode. NEXT: Press to go to the next track in both Bluetooth and Wi-Fi mode. - Page 8 Remote Control (Cont.) Using the remote control • The remote control has a range of up to 3 metres from the soundbar. Point the remote control directly towards the sensor at the front of the soundbar. • Make sure no obstacles are blocking its path. The remote control will not operate if the path of its sensor is blocked.
-
Page 9: Product Overview
Product Overview Front view Side view (ARC) Rear view HDMI Input HDMI Output COAX IN R-AUX-L OPTICAL DC-IN Source LED Power LED HDMI Input IR Sensor 10 HDMI Output (ARC) 11 COAX IN 12 AUX IN VOL+ 13 OPTICAL IN VOL- 14 DC IN Source... - Page 10 Product Overview (Cont.) LED Indicators and Buttons Power Button Press the Power button once to turn On, press again to turn Off. Power LED The following Power LED light indications will tell you which state the Soundbar is in. Power LED Status LED Light Indications Power ON...
- Page 11 Product Overview (Cont.) Wi-Fi Button: For device pairing, press and hold the Wi-Fi button on the unit or remote control. The function of this button depends on which mode the Soundbar is in. See below: State Change mode To set the unit in searching mode and connect it to the Wi-Fi network, Wi-Fi Mode select Wi-Fi mode...
-
Page 12: Controls And Connections
Controls and Connections Back Panel Connections (ARC) HDMI Input HDMI Output COAX IN R-AUX-L OPTICAL DC-IN HDMI Input HDMI Output HDMI Output COAX IN AUX IN OPTICAL IN DC IN (ARC) Power in • Only connect the power supply provided. Power connection •... - Page 13 Controls and Connections (Cont.) HDMI Output (ARC) • Make sure the HDMI cable you use supports the ARC function. • HDMI-CEC may be called different names by different manufacturers. Please refer to your TV's instruction manual for details on setting up HDMI-CEC and ARC. ARC mode is used for connecting the Soundbar to the TV via HDMI, utilising the audio relay channel.
- Page 14 Controls and Connections (Cont.) COAX Press the Source button either on the Remote Control or on the Soundbar to change the input to COAX. The Source LED will change to YELLOW • Use a coaxial cable (provided) to connect the TV to the Soundbar. •...
-
Page 15: Installation
NOTE: This App is subjected to change due to updates without prior notice. For iOS Devices • Open the App store and search for the SoundMax App. • Install the App to your iOS device. • When you open the App for the first time, it will search for available SoundMax units connected to the home Wi-Fi network. - Page 16 If you cannot see a SoundMax speaker SSID, press the Wi-Fi button on the SoundMax speaker to put it into Wi-Fi mode, then press and hold the Wi- Fi button until the LED indicator flashes rapidly. Go back to your smartphone or tablet Wi-Fi settings and connect again.
- Page 17 Installation (Cont.) Connect your SoundMax Device to your Home Network (Cont.) Screen 1 Screen 2 Screen 3 Screen 4 Screen 5 info@tempo.org 1300 886 649 Model: USMSB-1117 Product Code: 702719 06/2020...
- Page 18 When you have two units with the same model number, you need to configure them separately. Simply turn on one of the SoundMax units, connect it to your Wi-Fi network and then turn it off. Next, perform the same process for the second unit.
-
Page 19: Instructions
Your SoundMax Soundbar has the ability to play music wirelessly through the SoundMax App. You can play the music that you have stored on your iOS or Android device, or you can stream music from TuneIn, iHeartRadio or Spotify. Swipe right twice from the Device List screen on the App to access the menu. - Page 20 3. Play a song and select Devices Available. 4. Select your Soundmax Soundbar and start listening. NOTE: In order to use Spotify on your SoundMax Soundbar unit, you need to subscribe to a premium Spotify account. This product incorporates Spotify software which is subject to 3rd party licences found here: https://developer.spotify.com/esdk-third-party-licenses/...
- Page 21 ‘Country’ and then the ‘Region’ to select localised radio stations. Factory Reset To factory reset your SoundMax Soundbar speakers, open the App on your Smartphone or Tablet and select Settings . Then select “Speaker Info” and choose “Restore Factory Settings”.
- Page 22 You can use two SoundMax units to create a wireless stereo experience. In order to do this you need to connect your SoundMax speakers together following the steps for “Adding to an existing SoundMax”. Then go to the ‘Device List’ menu on the App and change the left speaker...
- Page 23 2. If already paired to a device, press the Wi-Fi button on the remote control to unpair from the currently paired unit. 3. Activate your Bluetooth enabled device and select the search mode. “SoundMax Soundbar” will appear on your Bluetooth device list.
- Page 24 Instructions (Cont.) TIPS • If you are prompted for a password, enter "0000". • If there is an existing connection, press the Wi-Fi button on the remote control to re- activate the pairing mode, the connection will be disconnected. The blue will flash slowly.
-
Page 25: Troubleshooting
Troubleshooting To keep the warranty valid, never try to repair the system yourself. If you encounter problems when using this unit, check the following points before requesting service. Problem Solution Increase the volume. No sound Re-select the audio input channel. Ensure cables are correctly connected. - Page 26 Soundbar is not operating properly Check your network connections. The SoundMax Soundbar player may need to be restarted. Disconnect the power cord for 30 seconds, and then reconnect. Wait for the SoundMax speakers to restart. If you have any interference with your Wi-Fi network you should connect the NAS drive that contains your music library to your home network router using an Ethernet cable.
- Page 27 • When you make a change to your network configuration, you may need to power cycle the SoundMax unit by unplugging the power cord and then plugging it back in and turn it back on. info@tempo.org...
-
Page 28: Specifications
Specifications Technical Specifications 2 x 1" tweeter, 8 ohm Speaker 2 x 3" woofer, 8 ohm 2 x 40*120mm full frequency speaker, 8 ohm Frequency Response 65Hz ~ 20KHz (-10dB) >75 dB (A Weighted) <10% Amplifier Integrated Class-D Digital Amplifier Speaker Output (RMS) 18W x 2CH + 36W Supported Streaming Services... -
Page 29: Repair And Refurbished Goods Or Parts Notice
Soundmax Soundbar Repair and Refurbished Goods or Parts Notice Unfortunately, from time to time, faulty products are manufactured which need to be returned to the supplier for repair. Please be aware that if your product is capable of retaining user-generated data... -
Page 30: Correct Disposal
Correct Disposal Responsible disposal of the packaging The packaging of this product has been selected from environmentally friendly materials and can usually be recycled. Please ensure these are disposed of correctly. Plastic wrapping can be a suffocation hazard for babies and young children, please ensure all packaging materials are out of reach and are safely disposed of. - Page 31 This page has been left blank intentionally. info@tempo.org 1300 886 649 Model: USMSB-1117 Product Code: 702719 06/2020...
- Page 32 Warranty returns Should you for any reason need to return this product for a warranty claim, make sure to include all accessories with the product. Product does not work? If you encounter problems with this product, or if it fails to perform to your expectations, make sure to contact our After Sales Support Centre on 1300 886 649 before returning it to the store for a refund.
