Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts that may have come loose
inside the carton during shipment.
TOOLS REQUIRED : NO TOOLS REQUIRED
PART LIST
DUAL POWER
A
RECLINER
B
PLASTIC LEG 1
PLASTIC
C
WASHER
WALL PLUG
D
TRANSFORMER
ASSEMBLY INSTRUCTIONS
HLLC 9064-50HP DUAL POWER RECLINER
DUAL POWER
RECLINER
1
4
4
1
Step 1: Attaching the four legs
Attention:The Legs、Washers and wall plug transformer are packed
together in the box,it is show by red ribbon.
* Check that the screw holes under the seat are aligned, Firstly put the
Washer, then turn the foot screw until it is tightened. As show in the
below picture
C
B
A
B C
SKU:13990646
C
B
C
B
