Manufactured for Rooms To Go
TOOLS REQUIRED:SCREWDRIVER (Not Included)
NO
Description
Lvst Body
A
B
LAF Backrest
C
RAF Backrest
D
Wood Leg
Cross-head Bolt
E
M8 x 30mm Thread
HNCL
9650-LS
LOVESEAT
LIST OF PARTS
QTY
Item
1
1
1
4
12
1
LOVESEAT
SKU#14296506,14296518,14297015
B
A
Legs and hardwares located in the zip pocket
C
