Summary of Contents for PDK Red Aux 8
- Page 1 Quick Start Guide View the user manual here: www.prodatakey.zendesk.com PN : A8 www.prodatakey.com 801.317.8802 Copyright © 2023 ProdataKey Inc. All rights reserved. Pdk, Pdk io, and the Red logos are trademarks of ProdataKey Inc. REV 03082023...
-
Page 2: Package Contents
1. Package Contents Battery Leads (1) Jumpers (8) Red Aux 8 Auxiliary Controller (1) Can Lock (1) Transformer (1) 14 VDC, 5 Amp Diodes (8) - Page 3 2. Elevator Floors POWER HEART LINK Elevator Control Panel 12-24VDC Elevator Control Panel - Wire each floor trigger to the Aux 8 relay ports using an 18/2 wire. Common - Connect one wire from the elevator control panel into common on the relay input.
- Page 4 Select the floors that will be accessible for all members of the group Save the Group Assigning Permission to Floors Add permissions within People or Groups within pdk.io Create a new Rule for a person or group Click on the tab titled “elevator”...
-
Page 5: Input Connection
Examples include door position sensors and push buttons. Aux input - The input reports in pdk.io as a DPS (A) input. When initiated, a rule can be set up to trigger events or outputs based on this input trigger... - Page 6 5. Wet Contact Output POWER HEART Piezo Alarm LINK 12-24VDC Aux Device - An Aux device can be connected to the door controller to be triggered based on specific events in the system. The most typical trigger is a door prop alarm. Connect the device as shown above. Jumper Block(s) Use to designate (+) or (-) board voltage out of NO and NC.
- Page 7 6. Dry Contact Output POWER HEART LINK Aux Device alarm panel, lighting HVAC, etc. 12-24VDC Device - A variety of devices can be wired into any of the Aux 8’s relay ports to trigger a specific action. Examples include alarm panel integration, lighting, and HVAC.
-
Page 8: Communication Connection
Ethernet - All Red controllers come with a built-in RJ45 connection for network connectivity. Once connected the Red controller is Self-Discoverable from pdk.io using IPV6. Alternatively, you may use IPV4 or assign a static IP using pdk.io if desired. POWER... -
Page 9: Power Connection
8. Power Connection 12-24VDC t t e DC Input - Input 12-24 VDC power using an 18/2 wire. For high voltage applications, use the High Voltage Converter (PN: HVC) Backup Battery - The enclosure will fit most 12V 8 Ah batteries. Connect the battery to the controller using the supplied battery leads. -
Page 10: Reference Guide
For UL-listed installations, all cable runs must be less than 30 meters (98.5’) Amperage Limits - The Aux 8 delivers an amperage limit of 4 amps for all electrified hardware plugged into the board Part Number - A8 PDK Technical Support Phone: 801.317.8802 option #2 Email: support@prodatakey.com...
