Landscape Forms Gretchen Picnic Table Instructions

Instructions
7/2007
Gretchen Picnic Table
Components:
(2) table/seat supports
(1) Table top
(2) Seats
Hardware:
(12) 1/4" x 3/4" Phillips self-tapping screws for table top
(4) 3/8-16 x 1-1/2" Hex head machine screw with washers for seats
(1) 1/4-20 x 2-1/4" Phillips head machine screw and lock nut for umbrella (sold separately)
Glides for freestanding support or anchor tabs for surface mount support are factory installed
Tools Required:
#3 Phillips screw driver for table top
9/16" Wrench or socket and ratchet for tightening seat screws
Assembly:
1. Turn table top upside down on a non-marring surface. Foam shipping blocks work well.
2. Place support A (has 5" ring at center) upside down on table top. Insert 6 screws loosely.
3. Hold support B upside down and carefully lower it over support A. Place bar of support B into notch in ring on
support A. Insert remaining 6 screws loosely.
Slip tubes on seat bottoms into the support tubes. Align support holes with the seat stem threaded hole and
4.
install the 3/8-16 hex head cap screws and washers.
Note: Screws are coated with dry thread locking compound that cures in 24 hours.
Wiggle seats and tighten as necessary until seat is securely fastened
5. Tighten all 12 screws on table top to support "A"&"B" until they seat against the steel support, then turn 1/4
turn further.
SUPPORT "A"
SUPPORT "B"
Assembly Installation Operation
.
Page 1 of 2
