ASSEMBLY INSTRUCTIONS
Quadro Loop
Boardroom table
COMPONENTS
A Table top x1
B Leg Quadro x2
C Leg Quadro Loop x2
*
D Beam x1
E Plastic bracket x4
SCREWS
F M8x20MM CSK x2
G M8x20MM Socket head x2
H M6x20MM Socket head x4
I M6x30mm Socket head x4
J Allen key x2
* Colour of the beam is always black,
regardless desk frame colour.
Need help!
Call us on
D
1300 527 665
A
B
C
www.jasonl.com.au
E
F G H I
