Gomax CV-35CAK User Manual

12g/6g/3g/hd-sdi to hdmi 2.0 converter with usb-c 10gbps video capture & audio extractor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CV-35CAK
12G/6G/3G/HD-SDI to HDMI 2.0 Converter with USB-C
10Gbps Video Capture & Audio Extractor
User Manual

TABLE OF CONTENTS

INTRODUCTION ....................................................................................................................... 1
FEATURES ............................................................................................................................... 1
PACKAGE CONTENTS ............................................................................................................ 2
SPECIFICATIONS .................................................................................................................... 3
PANEL DESCRIPTIONS ........................................................................................................... 5
CONNECTION DIAGRAM ........................................................................................................ 6
VIDEO STREAMING ................................................................................................................. 8
TROUBLESHOOTING ............................................................................................................ 16
USB PIN DEFINITION ............................................................................................................. 17
WARRANTY ............................................................................................................................ 18
rev: 240531
Made in Taiwan











Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CV-35CAK and is the answer not in the manual?

Questions and answers

Related Manuals for Gomax CV-35CAK

Summary of Contents for Gomax CV-35CAK

  • Page 1: Table Of Contents

    TABLE OF CONTENTS CV-35CAK INTRODUCTION ........................1   FEATURES ..........................1   PACKAGE CONTENTS ......................2   SPECIFICATIONS ........................3   12G/6G/3G/HD-SDI to HDMI 2.0 Converter with USB-C PANEL DESCRIPTIONS ......................5   10Gbps Video Capture & Audio Extractor CONNECTION DIAGRAM ......................6  ...

  • Page 2: Introduction

    The conversion from SDI to HDMI is entirely digital, ensuring no loss in b) Radeon Pro 555 (2GB of VRAM) transformation for both audio and video. The CV-35CAK includes a low-jitter SDI local loop-out and c) 16GB 2400MHz DDR4 Memory high-quality analog stereo output, providing users with flexibility.

  • Page 3: Specifications

    Windows 7 /8.1 /10/11, Mac and Linux OS SPECIFICATIONS OS Support Mechanical Model Name CV-35CAK Housing Metal enclosure Model Technical Dimensions Role of usage SDI to HDMI Converter Package [L x W x H] Carton Input/loopout Video [SDI][ 11.88 Gbps, 11.88/1.001 Gbps]...

  • Page 4: Panel Descriptions

    PANEL DESCRIPTIONS CONNECTION DIAGRAM 1. SDI IN: 12G/6G/3G/HD-SDI Input 2. SDI LOOPOUT: 12G/6G/3G/HD-SDI loopout 3. LED INDICATOR: SDI input signal indicator LED [Blue] Device power on (no input signal) [Green] Input detects SDI signal 4. +5V DC: 5V DC power jack 5.

  • Page 5: Video Streaming

    Supported Resolutions VIDEO STREAMING Create a Video Streaming Users can create video streams on the streaming service platform. The below steps show how to complete the 12G-SDI Output video streaming settings from Twitch and YouTube. 4K2K @50/59.94/60Hz SMPTE ST-2082 6G-SDI Output Twitch 4K2K @23.98/24, 25, 29.97, 30Hz SMPTE ST-2081...
  • Page 6 3. Go back to Twitch and select "Channel" from your account drop-down menu. YouTube Browse the YouTube website (https://www.youtube.com/) and log in, then lick "Go live" from the "Create" icon menu at the top right of the screen. * If your account is using YouTube for the first time to create a video stream, you need to wait 24 hours to enable the function.
  • Page 7 Stream and record videos with OBS 3. You will see "Stream key" from the “STREAM SETTINGS” below. Copy the "Stream key" and paste it into the "Stream Key" field in the OBS, then click "Start Streaming" in the software. OBS is popular USB capture freeware and has excellent compatibility. Please start with OBS if users are not * Please refer to steps 4-6 of the OBS software control program.
  • Page 8 First, find the "Scenes" window, click "+" in the lower left corner, and then enter the name of the scene to 4. Click "Settings" and then select "Stream" to perform streaming settings. Users can choose service create a new scene. providers, including Twitch, YouTube, etc.

  • Page 9: Troubleshooting

    7. On the other hand, users can also click "Start Recording" to record videos with OBS. Besides, you can click TROUBLESHOOTING "Settings" and then select "Output" to set “Recording Path” and “Recording Format”. Our USB device has done comprehensive tests before shipment. Most of the incompatibilities we have experienced are not from the USB capture device itself, but from the sophisticated software and hardware combination of PC or laptop.

  • Page 10: Usb Pin Definition

    USB PIN DEFINITION WARRANTY The SELLER warrants the CV-35CAK 12G/6G/3G/HD-SDI to HDMI 2.0 Converter with USB-C 10Gbps Video Capture & Audio Extractor to be free from defects in the material and workmanship for 1 year from the date of purchase from the SELLER or an authorized dealer. Should this product fail to be...
