CV-503ZKM
HDMI 2.0 & 12G SDI to
12G/6G/3G/HD/SDI Converter with
Audio Embedder
User Manual
The CV-503ZKM
Embedder
certified for international use. However, like all electronic equipment, the CV-503ZKM should be
used with care. Please read and follow the safety instructions to protect yourself from possible injury
and to minimize the risk of damage to the unit.
● Follow all instructions and warnings marked on this unit.
● Do not attempt to service this unit yourself, except where explained in this manual.
● Provide proper ventilation and air circulation and do not use near water.
● Keep objects that might damage the device and assure that the placement of this unit is on a
stable surface.
● Use only the power adapter and power cords and connection cables designed for this unit.
● Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device
before cleaning.
TABLE OF CONTENTS
INTRODUCTION ................................................................................................................ 1
FEATURES ........................................................................................................................ 1
PACKAGE CONTENTS ................................................................................................... 1
SPECIFICATIONS .............................................................................................................. 2
PANEL DESCRIPTION ...................................................................................................... 3
CONNECTION DIAGRAM .................................................................................................. 4
SUPPORTED SDI RESOLUTIONS .................................................................................... 6
LIMITED WARRANTY ........................................................................................................ 7
REFERENCE ..................................................................................................................... 8
rev: 160726
Made in Taiwan
HDMI 2.0 & 12G SDI to 12G/6G/3G/HD/SD-SDI Converter with Audio
has been tested for conformance to safety regulations and requirements, and has been
Advertisement
Table of Contents
Related Manuals for Gomax CV-503ZKM
Summary of Contents for Gomax CV-503ZKM
-
Page 1: Table Of Contents
However, like all electronic equipment, the CV-503ZKM should be used with care. Please read and follow the safety instructions to protect yourself from possible injury HDMI 2.0 &... -
Page 2: Introduction
Plus, with up to 8 channels audio support, 7.1 channel or 5.1 channel audio becomes available. Auto 12G/6G/3G/HD/SD-SDI detection The CV-503ZKM provides one low jitter SDI output up to 12G and three other SDI outputs up to 3G Input video bandwidth 18Gbps [HDMI] 12Gbps[SDI] simultaneously to either support 12G UHD output and 4 3G FHD outputs. -
Page 3: Panel Description
PANEL DESCRIPTION CONNECTION DIAGRAM 1. 12G SDI to 4 12G(QL) SDI OUT1: 12G(QL)/6G(QL)/3G/HD/SD-SDI output SDI OUT2: 12G(QL)/6G(QL)/3G/HD/SD-SDI output SDI OUT3: 12G(QL)/6G(QL)/3G/HD/SD-SDI output SDI OUT4: 12G/6G/12G(QL)/6G(QL)/3G/HD/SD-SDI output SDI IN: 12G/6G/3G/HD/SD-SDI input Slide Switch: Select HDMI or SDI input [Left] Select SDI input 2. -
Page 4: Supported Sdi Resolutions
SUPPORTED SDI RESOLUTIONS 3. HDMI 2.0 to 12G SDI 12G-SDI Output 4K2K* @50/59.94/60Hz SMPTE ST-2082 6G-SDI Output 4K2K* @23.97/24, 25, 30Hz SMPTE ST-2081 3G-SDI Output 1080p @ 50/ 59.94 / 60Hz SMPTE 424M, SMPTE 425M HD-SDI Output 720p @ 50Hz SMPTE 296M -3 720p @ 60 / 59.94Hz SMPTE 296M -1, -2... -
Page 5: Limited Warranty
SELLER will NOT be liable for direct, indirect, incidental, special, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. Also, the technical information contained herein regarding the CV-503ZKM features and specifications is subject to change without further notice.
