- Page 1 3G/HD/SD-SDI to HDMI,VGA & Audio Scaler Converter with Local Loopout User Manual rev: 131219 Made in Taiwan...
-
Page 2: Table Of Contents
However, like all electronic equipments, the CV-305VS should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. -
Page 3: Introduction
3G/HD/SD-SDI signal to digital HDMI, analog PC video(VGA) or component video(YPbPr) through an adapter with analog audio. The conversion guarantees no loss transformation for video. The CV-305VS also provides one low jitter for SDI local loopout. -
Page 4: Specifications
SPECIFICATIONS Model Name CV-305VS Technical Role of usage SDI to HDMI & VGA Converter SDI standards SD-SDI, HD-SDI & 3G-SDI Input Video bandwidth 2.970Gpbs, 2.970/1.001Gbps [3G] 1080p @50/59.94/60Hz (4:2:2) [HD] 720p @50/59.94/60Hz, 1080i @50/59.94/60Hz, 1080p @24/30Hz Input Video support [SD] NTSC @59.94Hz, PAL @50Hz... -
Page 5: Panel Description
PANEL DESCRIPTION Front Panel SDI INPUT: 3G/HD/SD-SDI Input SDI LOCAL LOOPOUT: 3G/HD/SD-SDI local loopout DIP SWITCH: For firmware update ON []: firmware update mode OFF []: normal mode LED INDICATOR: [green]: signal indicator LED [red]: power indicator LED. IR SENSOR: IR sensor for receiving the IR commands from IR remote PUSH BUTTON [LEFT]: Down Button [MID]: Up Botton... -
Page 6: Connection Diagram
CONNECTION DIAGRAM... -
Page 7: Osd Menu
OSD MENU Out Res. RGB, YCbCr444, Output Mode YCbCr422 1.Output Setup Disable, White, Cross, Hatch, Color, Gray, Default Pattern Windows, H-Ramp, W-HRamp, W-VRamp, Diagonal Contrast 0~255 of Contrast Level Brightness 0~255 of Brightness Level Saturation 0~255 of Saturation Level 0~255 of Hue Level 2.Image B/W Extension Off, On... -
Page 8: Operation Approach
OPERATION APPROACH Method A: Push-in Button Down Menu/Enter Method B: IR Remote Control Button Function FREEZE Freeze video ASPECT RATIO Aspect ratio change BLANK Blank video EXIT Exit OSD ENTER Enter key Up key LEFT Left key RIGHT Right key DOWN Down key MENU... - Page 9 Method C: IR Remote Control through Mini-USB port COM Port Selection COM Port Detection Button Output Setup Button Image Button Adjustment Button System Button Input / Output Resolution Info Refresh Input / Output Resolution Info Button Output Quick Selection Button 1.
- Page 10 3. Output Setup Button 4. Image Button 5. Adjustment Button...
- Page 11 6. System Button 1) In-Sync Info: To view the current input resolution 2) Factory Reset Button 3) Firmware Update Button The steps of firmware update: a) Unplug Mini-USB connector from device b) Set the Dip Switch to ON [] c) Connect the device to PC via USB to mini-USB cable d) Click the FW Update button on software e) Click “Load File”...
-
Page 12: Limited Warranty
The SELLER will NOT be liable for direct, indirect, incidental, special, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. Also, the technical information contained herein regarding the CV-305VS features and specifications is subject to change without further notice.
