- Page 1 HUB-66U 6-Port RS-232/422/485 USB-to-serial converter User Manual rev: 160205 Made in Taiwan...
-
Page 2: Table Of Contents
However, like all electronic equipments, the HUB-66U should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. -
Page 3: Introduction
6-Port RS-232/422/485 USB-to-serial converter provides user to connect 6 RS-232 or RS-232/422/485 devices to the laptop or workstation through the USB port. HUB-66U is compatible with new and legacy serial devices, and are perfect for mobile, instrumentation, and point-of-sale applications. With HUB-66U, user can control up to 6 devices with RS-232/422/485 connector through one USB port on the lap or PC. -
Page 4: Specifications
SPECIFICATIONS Model Name HUB-66U Technical Role of usage 6 Port USB to Serial Converter Compliance USB 1.1/2.0 compliant Speed 480 Mbps (Hi-Speed USB) and 12 Mbps (Full-Speed USB) [1] Human body model—±19kV [air-gap discharge] & ±12kV [contact discharge] ESD protection [2] Core chipset —... -
Page 5: Panel Descriptions
PANEL DESCRIPTIONS Power LED: Power on/off indicator RS-232 TX LED: Port is sending data to connected device RS-232 RX LED: Port is receiving data to connected device +5V DC: Connect to a 5V power supply unit USB: Connect to the USB port of PC RS-232 PORT 1 ~ 6: .Connect to serial port devices with a DSUB-9 female-female or male-female cable LED: FW update indicator. -
Page 6: Hardware Installation
HARDWARE INSTALLATION 1. Connect the HUB-66U to your PC 2. Connect your serial device to the HUB-66U 3. Plug in 5V DC power supply unit to the power jack of HUB-66U CONNECTION DIAGRAM... -
Page 7: Rs-232 Pin Defintion
RS-232 PIN DEFINTION 1. DB 9 Male RS-232/422/485 PIN DEFINTION RS-232 RS-422/ 4-wire RS-485 2-wire RS-485 TxD-(A) TxD+(B) RxD+(B) Data+(B) RxD-(A) Data-(A) 2. RS-232 CABLE PIN DEFINTION Connector 1 Connector 2 Function Signal ground... -
Page 8: Driver Installation
DRIVER INSTALLATION Step 1. Use cable (USB to USB) to connect with the computer and Hub-66U. After connection, it will show 6 unknown virtual COM Port in the device manager. Port 1 Port 2 Port 3 Port 4 Port 5 Port 6 Step 2. - Page 9 Step 3. Browse the driver file on the computer and install it. Step 4. When alert window pops out, please select the “Install this driver software anyway”.
- Page 10 After finishing the installation, the order of COM port in the device manager is different from the device (Hub-66U). Step 6. Operate the Hub-66U software to test the order of COM port. (a) Select any COM port (take COM port 7 as an example). (b) Input some string or number and click the “Send” button.
- Page 11 You can click the right button of mouse to select the content of virtual COM port to re-arrange the COM port number. *Before this step, please remember to close the Hub-66U software. Or it will occupy the COM port that we cannot change the order.
-
Page 12: Operation Software
OPERATION SOFTWARE 1. Select COM Port 2. Open the selected COM Port 3. Close the selected COM Port 4. Set the Baud Rate/ Parity/ Databits/ StopBits 5. Set the RS-232 or RS-485 mode to each port 6. Received data information 7. -
Page 13: Warranty
SELLER will NOT be liable for direct, indirect, incidental, special, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. Also, the technical information contained herein regarding the HUB-66U features and specifications is subject to change without further notice.
