ITEM NO. 014-HG-42001
The instruction booklet contains IMPORTANT
safety information. Please read it in full and
keep it for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Harper 014-HG-42001 and is the answer not in the manual?

Questions and answers

Related Manuals for Belleze Harper 014-HG-42001

Summary of Contents for Belleze Harper 014-HG-42001

  • Page 1 Harper Chest FOLLOW US: CONTACT INFO: ITEM NO. 014-HG-42001 The instruction booklet contains IMPORTANT support@belleze.com @bellezefurniture safety information. Please read it in full and 1-800-682-6376 keep it for future reference. www.belleze.com...
  • Page 2 Scan this QR Code to view our online tutorial Estimated time for assembly: 240 mins Weight limitations are as follows: Maximum Load 80 lb Maximum Load 20 lb...
  • Page 3 Assemble the furniture on an empty carton, carpet, or rug to prevent scratches or damage. For safety, please keep pets and children away from the assembly area. Ensure the product is fully assembled before use. If you are missing any hardware or products, do not use it until you have restored the missing parts.

  • Page 4: Package Contents

    PACKAGE CONTENTS...
  • Page 5 PACKAGE CONTENTS CODE DESCRIPTION Top Panel Bottom Panel Left Side Panel Right Side Panel Left Cabinet Door Right Cabinet Door Fixed Storage Shelf Panel Adjustable Storage Shelf Panel Back Crossbar Lower Back Panel Back Panel Connection Strip Base Metal Crossbar Upper Back Panel v.05162023...
  • Page 6 PACKAGE CONTENTS 20x + 2x 20x + 2x 32x + 3x 48x + 4x Install all hardware perpendicular to the opening.
  • Page 7 PACKAGE CONTENTS 20x + 2x Install all hardware perpendicular to the opening. v.05162023...
  • Page 8 Required tools for assembly (Not included) Attach cam bolts to the side panels (3,4). Assemble 2 cabinets in total.
  • Page 9 lnsert wood dowels to the xed storage shelf panel (7) and theback crossbar(9). Assemble the xed storage shelf panel(7) and the back crossbar(9) to the right side panel(4). v.05162023...
  • Page 10 Attach the left side panel (3) to the xed storage shelf panel (7) and the back crossbar(9).
  • Page 11 Attach the magnetic catch to the underside of the top panel (1). Attach cam bolts to the underside of the top panel（1）. v.05162023...
  • Page 12 Attach the top panel on top of the carbinet assembly.
  • Page 13 Place the cabinet upside down, and slide in the back panels (10,14) and the back panel connection (11) strip. v.05162023...
  • Page 14 Attach the bottom panel（2）. Attach the base metal crossbar (12) to the bottom panel (2).
  • Page 15 Attach legs (13) to the side the ends of the metal crossbar (12). Secure the back panels in place. v.05162023...
  • Page 16 Attach the cam lock decorative cover on top of the cam locks. Insert the shelf pegs and put the adjustable storage shelf panel inside the cabinet.
  • Page 17 Attach door hinges to the cabinet doors (5,6). Attach the magnetic catch plates to the cabinet doors. v.05162023...
  • Page 18 Attach door handles to the cabinet doors.
  • Page 19 Attach cabinet doors to the cabinet. Adjust the position of the cabinet doors. Up and down In and out adjustment Side to side adjustment adjustment by by loosening the screws using the front loosening the screws on the hinge arm. adjustment screw on on the mounting plate.
  • Page 20 Attach cabinet to the wall. device to prevent the furniture from tipping over. • Mark the drill position on the wall with a pencil. • Drill a small hole on the marked position. • Insert a wall anchor into the drilled hole. •...
  • Page 21 Warning Only place items on top of the product if they meet the recommended size and weight limits. Climbing on, stepping on, or placing overweighted objects on the product may cause property damage and/or injuries. Items placed onto this product must be resting on a support surface without hanging over the edges.

  • Page 22: Maintenance

    FURNITURE CARE AND MAINTENANCE Medium - Density Fiberboard Thank you for your purchase. We want your item to last as long as possible. To ensure the product gives you years of longevity, please follow the recommendations in this care and maintenance guide. MAINTENANCE •...
  • Page 23 © All copyright of this document belongs to BELLEZE . This document may not be printed, translated, reproduced, or distributed in whole or in part without written permission from BELLEZE. v.05162023...

  • Page 24: Warranty

    WARRANTY BELLEZE products come with a 1-year warranty from the date of delivery. Register your product on our website to enjoy our limited lifetime warranty! AFTER-SALE SERVICE Contact us at 1-800-682-6376 or email us at support@belleze.com We will send you replacement.
